Manually moving the wipers across the
windshield may damage them.
*
[SV24000( ALL)03/01]
Wiper blade replacement
*
[SV24100( ALL)09/95]
If the wiper blades still do not work properly
after you clean them, you may need to replace
the wiper blade assembly or the blade element.
When replacing the wiper blade assembly, blade
refill, or wiper arm always use a Motorcraft part
or equivalent. To replace the blades, follow the
instructions that come with them.
%
*
[SV24200( ALL)03/95]
Tires
*
[SV24300( ALL)03/95]
Look at your tires each time you fill your fuel
tank. If one tire looks lower than the others,
check the pressure in all of them. Always follow
these precautions:
*
[SV24500( ALL)03/95]
q
Keep your tires inflated to the recommended
pressures.
*
[SV24600( ALL)02/95]
q
Stay within the recommended load limits (see
Load limitsin the Index).
*
[SV24700( ALL)02/95]
q
Make sure the weight of your load is evenly
distributed.
*
[SV24800( ALL)10/89]
q
Drive at safe speeds.
*
[SV24900( ALL)01/95]
If you do not take these precautions, your tires
may fail or go flat.
*
[SV24950( ALL)07/95]
Ford Motor Company recommends obeying
posted speed limits.
*
[SV25000( ALL)05/95]
RWARNING
Driving too fast for conditions creates the
possibility of loss of vehicle control.
Driving at very high speeds for extended
periods of time may result in damage to
vehicle components.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

264 %
*
[SV25200( ALL)05/95]
At least once a month, check the pressure in all
your vehicle's tires, including the spare. Use an
accurate tire pressure gauge. Check the tire
pressure when tires are cold, after the vehicle
has been parked for at least one hour or has
been driven less than 3 miles (5 km). You can
find proper cold pressure and load limits of
recommended size tires on the Safety
Compliance Certification Label.
*
[SV25400( ALL)05/95]
RWARNING
Improperly inflated tires can affect vehicle
handling and can fail suddenly, possibly
resulting in loss of vehicle control.
%*
[SV25500( ALL)02/95]
Tire Rotation
*
[SV25600( ALL)04/95]
Because your vehicle's front and rear tires
perform different jobs, they often wear
differently. To make sure your tires wear evenly
and last longer, rotate them as indicated in the
following diagram.
*
[SV25700( ALL)01/95]
For tire rotation intervals, see theMaintenance
Schedule. If you notice that the tires wear
unevenly, have them checked.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

265 [SV25900(M )03/93]
half page art:0010378-C
Rotating the tires
%*
[SV26500( ALL)04/95]
Replacing the Tires
*
[SV26600( ALL)05/95]
Replace any tires that show wear bands. When
your tire shows a wear band, it has only 1/16
inch (2 mm) of tread left.
% [SV26700( ALL)05/94]
one inch art:0001318-A
A worn-out tire
*
[SV26800( ALL)01/95]
Because your vehicle's tires may wear unevenly,
you may need to replace them before a wear
band appears across the entire tread. Some spots
wear more heavily than others.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

266
*
[SV26850( ALL)01/95]
RWARNING
When replacing full size tires, never mix
radial, bias-belted, or bias-type tires. Use
only the tire sizes that are listed on the
tire pressure decal. Make sure that all tires
are the same size, speed rating, and
load-carrying capacity. Use only the tire
combinations recommended on the decal.
If you do not follow these precautions,
your vehicle may not drive properly and
safely.
*
[SV27100( ALL)01/95]
Tires that are larger or smaller than your
vehicle's original tires may also affect the
accuracy of your speedometer.
%*
[SV28100( ALL)02/95]
Information About Tire Quality Grades
*
[SV28200( ALL)01/95]
New vehicles are fitted with tires that have their
Tire Quality Grade (described below) molded
into the tire's sidewall. These Tire Quality
Grades are determined by standards that the
United States Department of Transportation has
set.
*
[SV28250( ALL)01/95]
Tire Quality Grades apply to new pneumatic
tires for use on passenger cars. They do not
apply to deep tread, winter-type snow tires,
space-saver or temporary use spare tires, tires
with nominal rim diameters of 10 to 12 inches or
limited production tires as defined in Title 49
Code of Federal Regulations Part 575.104(c)(2).
*
[SV28300( ALL)01/95]
U.S. Department of Transportation Ð Tire
quality grades:The U.S. Department of
Transportation requires Ford to give you the
following information about tire grades exactly
as the government has written it.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

267 %
*
[SV28399( ALL)01/95]
Treadwear
*
[SV28400( ALL)01/95]
The treadwear grade is a comparative rating
based on the wear rate of the tire when tested
under controlled conditions on a specified
government test course. For example, a tire
graded 150 would wear one and one-half (1 1/2)
times as well on the government course as a tire
graded 100. The relative performance of tires
depends upon the actual conditions of their use,
however, and may depart significantly from the
norm due to variations in driving habits, service
practices and differences in road characteristics
and climate.
*
[SV28499( ALL)01/95]
Traction A B C
*
[SV28500( ALL)01/95]
The traction grades, from highest to lowest, are
A, B, and C, and they represent the tire's ability
to stop on wet pavement as measured under
controlled conditions on specified government
test surfaces of asphalt and concrete. A tire
marked C may have poor traction performance.
Warning: The traction grade assigned to this tire
is based on braking (straightahead) traction tests
and does not include cornering (turning)
traction.
*
[SV28599( ALL)01/95]
Temperature A B C
*
[SV28600( ALL)01/95]
The temperature grades are A (the highest), B,
and C, representing the tire's resistance to the
generation of heat and its ability to dissipate
heat when tested under controlled conditions on
a specified indoor laboratory test wheel.
Sustained high temperature can cause the
material of the tire to degenerate and reduce tire
life, and excessive temperature can lead to
sudden tire failure. The grade C corresponds to
a level of performance which all passenger car
tires must meet under the Federal Motor Vehicle
Safety Standard No. 109. Grades B and A
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

268represent higher levels of performance on the
laboratory test wheel than the minimum
required by law. Warning: The temperature
grade for this tire is established for a tire that is
properly inflated and not overloaded. Excessive
speed, underinflation, or excessive loading, either
separately or in combination, can cause heat
buildup and possible tire failure.
%*
[SV28700( ALL)04/95]
Snow Tires and Chains
[SV28801(M )08/93]
The 15 in. and 16 in. tires on your vehicle have
all-weather treads that provide traction in rain
or snow. However, during the winter months in
some climates, you may need to use snow tires
and occasionally chains for your tires.
*
[SV28900( ALL)05/95]
RWARNING
Snow tires must be the same size and
grade as the tires you currently have on
your vehicle.
[SV28910(M )05/95]
For your Mustang GT models equipped with 17
in. tires, to achieve the best traction during snow
and ice conditions, purchase 245/45ZR17 mud
and snow tires.
*
[SV29000( ALL)02/95]
Use chains on the tires only in an emergency or
if the law requires them where you live. If you
choose to use chains on your vehicle's tires, be
aware of the following:
*
[SV29100( ALL)01/95]
q
Make sure the chains are the right size for
your tires. Use only SAE Class ªSº chains.
Other types may damage your vehicle.
[SV29110(M )05/95]
q
Use only Cable Type chains if your vehicle is
equipped with the P225/55ZR16 or
245/45ZR17 tires. Use of SAE Class ªSº
chains or other types may damage your
vehicle.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

269
*
[SV29200( ALL)01/95]
q
Put the chains on tightly with the ends held
down securely. Verify that no chain touches
any wiring, brake lines, or fuel lines. Follow
the chain manufacturer's instructions.
*
[SV29300( ALL)01/95]
q
Drive slowly. If you can hear the chains rub
or bang against your vehicle, stop the vehicle
and tighten the chains. If you continue to
hear the chains rub or bang against your
vehicle, remove the chains to prevent damage
to your vehicle.
*
[SV29400( ALL)10/94]
q
Avoid fully loading your vehicle if possible.
*
[SV29500( ALL)05/94]
q
Remove tire chains at the first opportunity
after using them on snow and ice. Do not use
the chains on dry roads.
%*
[SV29600( ALL)04/95]
Cleaning the Wheels
*
[SV29700( ALL)05/95]
Wash the wheels with the same detergent you
use to wash your vehicle's body. Do not use
acid-based wheel cleaners, steel wool, abrasives,
fuel, or strong detergents. These substances will
damage protective coatings. Use tar and road oil
remover to remove grease and tar.
*
[SV29800( ALL)09/95]
NOTE: Before going to a car wash, find out if
the brushes are abrasive.
%
*
[SV30450( ALL)01/95]
Automatic Transmission Fluid
*
[SV30475( ALL)01/95]
Under normal circumstances, you do not need to
check the fluid level of the transmission, since
your vehicle does not use up transmission fluid.
Refer to theMaintenance Schedule and Record
booklet for replacement intervals. However, if
the transmission is not working properly Ð for
instance, the transmission may slip or shift
slowly, or you may notice some sign of fluid
leakage Ð the fluid level should be checked.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

270 %
*
[SV30550( ALL)02/95]
Checking the Automatic Transmission
Fluid
*
[SV30560( ALL)05/95]
It is preferable to check the transmission fluid
level at normal operating temperature
150ÊF-170ÊF (66ÊC-77ÊC),after approximately 20
miles (30 km) of driving. However, if necessary,
you can check the fluid level without having to
drive 20 miles (30 km) to obtain a normal
operating temperature if outside temperatures
are above50ÊF (10ÊC).
[SV30575( ALL)03/94]
With the vehicle on a level surface, start the
engine and, while fully applying the brake
pedal, move the transmission shift selector
through all of the gear ranges allowing sufficient
time for each position to engage.Securely latch
the transmission shift selector in the P (Park)
position, fully set the parking brake and leave
the engine running.
[SV30625(MBC )03/93]
NOTE: Your vehicle should not be driven if
the fluid level is below the low cold
reading on the dipstick.
*
[SV30650( ALL)02/95]
Wipe off the dipstick cap, pull the dipstick out
and wipe the indicator end clean. Put the
dipstick back into the filler tube and make sure
it is fully seated. Pull the dipstick out and read
the fluid level.
[SV30675(MBC )10/95]
When checking fluid at normal operating
temperature150ÊF-170ÊF (66ÊC-77ÊC), thefluid
level should be within the hot notched area on
the dipstick. When the vehicle has not been
driven, and the fluid is at room temperature
50ÊF-95ÊF (10ÊC-35ÊC), thefluid level should be
within the cold notched area.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996
