1996 FORD MUSTANG air conditioning

57 [ST14000( ALL)12/94]
If the engine is idling while you are stopped in
an open area for long periods of time, open the
windows at least one inch (2.5 cm). Also, the
heating or air conditioning system should be set
to any function except MAX A/C or AUTO.
[ST14100(M )12/88]
q
If you use the heater, set the fan speed on
MEDIUM or HIGH with the function control
knob at any desired position.
[ST14150(M )12/88]
q
If you use the air conditioner, set the fan
speed on MEDIUM or HIGH with the
function control knob at any position except
OFF and the temperature control lever at
mid-position.
%
*
[ST17100( ALL)03/95]
If the Engine Cranks but Does
Not Start or Does Not Start After
a Collision
[ST17110( ALL)07/95]
Fuel System Shut-off Switch
[ST17200( ALL)07/95]
If the engine cranks but does not start or does
not start after a collision, the fuel system shut-off
switch may have been triggered. The shut-off
switch is a device intended to stop the fuel
system when your vehicle has been involved in
a substantial jolt.
[ST17410(M )12/94]
Once the shut-off switch is triggered, you must
reset the switch by hand before you can start
your vehicle. The switch is on the left side of the
trunk near the left tail lamp.
File:04rcstm.ex
Update:Wed Mar 27 09:28:42 1996

80 %
*
[IP00400( ALL)06/95]
The main controls for the climate control system,
clock, and radio are on the instrument panel.
%*
[IP00500( ALL)09/95]
NOTE: Any cleaner or polish that increases the
gloss (shine) of the upper part of the
instrument panel should be avoided.
The dull finish in this area is to help
protect the driver from undesirable
windshield reflection.
%
*
[IP00600( ALL)06/95]
The Climate Control Systems
[IP00700( ALL)03/91]
Your vehicle has one of two different climate
control systems. The two systems are:
[IP00710(M )06/93]
q
an optional heating and air conditioning
system
[IP01100(M )03/94]
q
a standard heating only system
*
[IP01400( ALL)06/95]
If you are not sure which system your vehicle
has, see the diagrams on the following pages.
% [IP01405(M )08/93]
The Optional Heating and Air
Conditioning System
[IP01410(M )08/93]
You can heat the inside of your vehicle, defrost
the windshield, and turn on the air conditioning
with the three knobs in the center of the
instrument panel:
[IP01415(M )08/93]
q
FAN
[IP01420(M )08/93]
q
TEMP
[IP01425(M )08/93]
q
SELECT
File:06rcipm.ex
Update:Wed Mar 27 09:30:23 1996

81 [IP01430(M )05/95]
quarter page art:0010180-H
The knobs that control the optional heating and air
conditioning system
[IP01435(M )08/93]
The heating system in the optional heating and
air conditioning system operates the same as the
heater only system. SeeThe Heater Only System.
[IP01440(M )05/95]
To cool your vehicle quickly in warm weather,
turn the SELECT knob to MAX A/C, turn the
TEMP knob all the way to the end of the blue
range (full left) and turn the FAN knob to HI.
MAX A/C uses recirculated air and is the most
fuel efficient way to cool your vehicle and can
also be used in heavy traffic to prevent exhaust
fumes from entering the vehicle. MAX A/C can
also be used in high humidity areas for more
efficient operation.
[IP01445(M )08/93]
If the interior of your vehicle is very warm,
drive for the first few minutes with the windows
open. This forces most of the hot, stale air out of
the vehicle and allows the air conditioning to
work faster.
% [IP01450(M )05/95]
To cool your vehicle using outside air, turn the
SELECT knob to NORM A/C, turn the TEMP
knob all the way to the end of the blue range
(full left) and turn the FAN knob to the desired
speed between LO and HI. NORM A/C
provides quieter system operation than MAX
A/C.
File:06rcipm.ex
Update:Wed Mar 27 09:30:23 1996

Index 317
Index
A
ABS warning light
(see Anti-lock brake system)....... 65
Accessory position on the ignition..... 49
Accessory power source,
power point outlet.......... 130
Additives, engine oil.......... 249
Air bag supplemental restraint system
and child safety seats........ 24,30
description............... 22
disposal................ 28
driver air bag........... 22,25
indicator light............. 67
operation............... 25
passenger air bag............ 25
proper seating............. 23
service and information labels...... 25
tone generator............. 28
wearing safety belts........... 22
Air cleaner filter
location............... 239
specifications............. 299
Air conditioning, manual heating and air
conditioning system........... 80
Alarm, activating remote personal.... 111
Alcohol, in fuel............. 244
Antenna, radio (see Electronic
sound system)..........141, 173
Antifreeze (see Engine coolant)...... 252
Anti-lock brake system (ABS)
description.............. 186
see also Brake............ 186
warning light.............. 65
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996

Index 321
Cleaning your vehicle (continued)
engine compartment......... 242
exterior............... 5±6
exterior lamps............. 86
fabric................ 125
headlamps............... 86
instrument panel............ 80
instrument panel lens.......... 89
interior............... 125
interior lamps............. 89
mirrors............... 127
plastic parts.............. 7
polishing................ 6
rustproofing.............. 7
safety belts............... 21
tail lamps............... 86
upholstery and interior trim...... 125
washing............... 5±6
waxing................ 6
wheels................ 269
Climate control system
air conditioning............ 80
heating................ 80
heating only system........... 82
Clock.................. 89
Clutch
adjusting............... 272
fluid................. 272
fluid reservoir............ 272
operation while driving........ 182
recommended shift speeds....... 184
shifting the gears........... 183
specifications............. 300
Cold engine starting............ 53
Combination lap and shoulder belts . . . 9, 11
Compact disc player (see Electronic sound
system)............... 155
Console, description........... 129
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996

Index 327
Gearshift (continued)
floor-mounted............ 183
locking the gearshift.......... 49
manual operation........... 182
positions.............177, 183
shifting the gears.........177, 183
shift-lock............... 178
upshifting.............. 184
GVWR (Gross Vehicle Weight Rating) . . . 192
calculating.............. 192
definition.............. 192
driving with a heavy load....... 192
location............... 192
H
Hazard flashers.............. 94
Headlamps
aiming................ 288
bulb specification........... 292
checking alignment.......... 288
cleaning................ 86
daytime running lights......... 84
flashing................ 92
high beam............... 92
replacing bulbs..........288±290
turning on and off........... 85
Head restraints............. 116
Heating
heater only system........... 82
heating and air conditioning system . . . 80
High beams
indicator light............. 70
operation............. 84,92
Hitch................. 195
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996
