1996 FORD F150 engine

258
%*
[RE03600( ALL)03/95]
Changing a Tire
*
[RE03700( ALL)01/95]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
*
[RE03800( ALL)03/95]
The Conventional Spare Tire
*
[RE03900(BEF )01/95]
If you have the conventional spare tire, you can
use it as a spare or as a regular tire. This spare
tire is identical to the other tires that come with
your vehicle, although the wheel may not match.
*
[RE04275(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[RE04280(BEF )10/94]
Extended use of other than matching size spare
tires on a Traction-Lok axle could result in a
permanent reduction in effectiveness. This loss of
effectiveness does not affect normal driving and
should not be noticeable to the driver.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

263
*
[RE15350(B F )06/94]
If you have a four-wheel drive vehicles with
manual locking hubs, put transfer case lever in
2H, 4H, or 4L.
*
[RE15375(B F )05/95]
When one of the back wheels is off the ground,
the transmission alone will not prevent the
vehicle from moving or slipping off the jack,
even if the vehicle is in P (Park) or 1 (First). To
prevent the vehicle from moving when you
change a tire, be sure the parking brake is set,
then block the wheel (both directions) that is
diagonally opposite (other side and end of the
vehicle) to the tire that is being changed.
*
[RE15400(B F )05/95]
RWARNING
If the vehicle slips off the jack, you or
someone else could be seriously injured.
[RE15435(B F )05/95]
When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if the
automatic transmission is in P (Park) or the
manual transmission is in gear.
*
[RE15440(B F )05/95]
RWARNING
Do not leave the vehicle unattended with
the transfer case in the N (Neutral)
position. Always set the parking brake
fully and turn off the ignition when
leaving the vehicle.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

265
*
[RE16800(BEF )12/91]
3. Use the tapered end of the lug nut wrench
to unscrew wheel ornaments attached by
retaining screws. Remove any wheel trim.
Insert the tapered end of the lug nut wrench
behind wheel covers or hubcaps and twist
off.
*
[RE16900(BEF )10/89]
4. Loosen the wheel nuts by pulling up on the
handle of the lug nut wrench about one-half
turn (counterclockwise). Do not remove the
wheel lug nuts until you raise the tire off the
ground.
%*
[RE16950(BEF )05/95]
Removing and Replacing the Tire
[RE17100(B F )02/95]
1. Insert the jack handle into the jack and use
the handle to slide the jack under the
vehicle.
*
[RE17175(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[RE17200(BEF )05/95]
RWARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

275
*
[RE24390( F )02/89]
twelve pica chart:0020320-A
*
[RE24397(BEF )02/95]
If the Engine Cranks But Does
Not Start or Does Not Start After
a Collision
*
[RE24400(BEF )04/95]
The Fuel Pump Shut-off Switch
*
[RE24500(BEF )03/95]
If the engine cranks but does not start or if you
have had a collision, the fuel pump shut-off
switch may have been triggered. The shut-off
switch is a device that stops the fuel pump
when your vehicle has been involved in a
substantial jolt.
*
[RE24600(BEF )01/95]
For information on how to check and reset the
fuel pump shut-off switch, seeFuel pump shut-off
switchin the Index.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

289
%*
[HS06400( ALL)05/95]
Getting Help Outside the U.S.
and Canada
*
[HS06500( ALL)05/95]
Before you export your vehicle to a foreign
country, contact the appropriate foreign embassy
or consulate to make sure local regulations do
not prevent you from registering your vehicle.
Officials at the embassy can also help you decide
whether you should import your vehicle to that
country.
*
[HS06600( ALL)05/95]
Officials at the embassy or consulate can tell you
where to get unleaded fuel. If you cannot get
unleaded fuel or can get only fuel with an
anti-knock index that is lower than your vehicle
needs, contact a district or owner relations office
before you leave the U.S. or Canada.
*
[HS06700( ALL)05/95]
Use of leaded fuel in your vehicle without a
proper conversion may damage the effectiveness
of your emissions control system and may cause
engine knocking or serious engine damage. Ford
Motor Company is not responsible for any
damage that is caused by use of improper fuel.
*
[HS06800( ALL)05/95]
You may also have difficulty importing your
vehicle back into the U.S. if you use leaded fuel.
*
[HS06900( ALL)05/95]
If your vehicle must be serviced while you are
traveling or living in Central or South America,
the Caribbean, or the Middle East, contact the
nearest Ford dealership. If the dealership cannot
help you, write to:
*
[HS07000( ALL)05/95]
one inch art:0095024-A
File:lthsf.ex
Update:Thu May 9 15:20:42 1996

293
Accessories
*
[AC00400( ALL)03/95]
Ford Accessories for Your Vehicle
*
[AC00500( ALL)04/95]
A wide selection of accessories is available
through your local authorized dealer. These fine
accessories have been engineered specifically to
fulfill your automotive needs. They are custom
designed to complement the style and
aerodynamic appearance of your Ford-built
vehicle. In addition, each accessory is made from
high quality materials and meets or exceeds
Ford's rigid engineering and safety specifications.
That is why Ford brand accessories are
warranted for up to 3 years or 36,000 miles
(60,000 km), whichever comes first. See your
dealer for complete warranty information and
accessory availability.
File:ltacf.ex
Update:Thu May 9 15:14:47 1996

296
*
[AC02100( ALL)01/95]
NOTE: Mobile communications systems may
harm the operation of your vehicle,
particularly if they are not properly
designed for automotive use or are not
properly installed. For example, when
operated, such systems may cause the
engine to stumble or stall. In addition,
such systems may themselves be
damaged or their operation affected by
operating your vehicle. (Citizens band
[CB] transceivers, garage door openers,
and other transmitters whose power
output is 5 watts or less will not
ordinarily affect your vehicle's
operation.)
*
[AC02200( ALL)05/95]
NOTE: Because we have no control over the
installation, design, or manufacture of
such systems, Ford cannot assume
responsibility for any adverse effects or
damage that may result if you use this
equipment.
*
[AC02400( ALL)02/89]
ten pica chart:0020464-A
File:ltacf.ex
Update:Thu May 9 15:14:47 1996

301
Servicing Your F-Series
%*
[SV00300( ALL)03/95]
Service Made Easy
*
[SV00400(BEF )01/95]
Ford has two goals for servicing your vehicle.
*
[SV00500(BEF )01/95]
1. When we can, we design parts that do not
need to be serviced.
*
[SV00600(BEF )01/95]
2. We want to make servicing your vehicle as
easy as possible. To help you:
*
[SV00700(BEF )01/95]
q
We highlight do-it-yourself items in yellow in
the engine compartment so that you can find
them easily.
*
[SV00800(BEF )01/95]
q
When possible, we design parts Ð such as
the headlamp bulbs Ð that can be replaced
without tools.
*
[SV00900(BEF )05/94]
q
We give you a Maintenance Schedule that
makes tracking routine service for your
vehicle easy. The maintenance schedule is
located in theMaintenance Schedule and Record
booklet.
*
[SV01000( ALL)01/95]
This chapter tells you about the basic parts that
you need to check and service regularly.
*
[SV01100( ALL)02/95]
If your vehicle needs professional servicing, your
dealership can provide the parts and service
required. Check yourWarranty Information Booklet
to find out which parts and services are covered.
Also see theCustomer Assistancechapter of this
Owner Guide.
*
[SV01300( ALL)03/95]
Ford Motor Company recommends that the
Owner Maintenance Checks listed in the
Maintenance Schedule and Recordbooklet be
performed for the proper operation of your
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996
