If your vehicle is over 8500 GVWR and the
above conditions do not apply, change the
engine oil and oil filter every 6 months or 5,000
miles (8,000 km), whichever comes first.
*
[SV16800( ALL)04/95]
Refer to theMaintenance Schedule and Record
booklet for additional information.
*
[SV16900( EF )03/94]
NOTE: Refer to thePower Stroke Diesel Engine
Owner's Guide Supplementfor oil
viscosity, filter application and oil and
filter change intervals.
%*
[SV17250( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[SV17275( ALL)05/95]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[SV17280( ALL)05/95]
Protect your skin by washing with soap and
water.
*
[SV17300( ALL)03/95]
Engine Coolant
*
[SV17400( ALL)02/95]
Checking the engine coolant
*
[SV17700( ALL)10/89]
Your vehicle's engine coolant protects the engine
from overheating in the summer and from
freezing in the winter. Check the level of the
engine coolant at least once a month, but
preferably each time you stop for fuel. Simply
look at the engine coolant recovery reservoir
located in the engine compartment. To locate
this reservoir, see the diagram of your vehicle's
engine underEngine typesin this chapter.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

325
*
[SV17750( ALL)03/95]
If the engine coolant has not been checked for a
long period of time the engine coolant reservoir
may eventually empty. If the engine coolant
reservoir empties, check the engine coolant level
in the radiator. Read the following warnings
before removing the radiator cap. If it is
necessary to fill the radiator, refer to theEngine
Coolant Refill Procedurein this chapter for
instructions.
*
[SV17950(BEF )01/95]
Adding engine coolant
*
[SV18000(B F )07/94]
quarter page art:0020354-A
Adding engine coolant
*
[SV18150(B F )05/90]
quarter page art:0020360-C
Adding engine coolant
*
[SV18400( ALL)05/95]
RWARNING
Do not put engine coolant in the container
for the windshield washer fluid.
*
[SV18420( ALL)05/95]
If sprayed to clean the glass, engine coolant or
antifreeze could make it difficult to see through
the windshield.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

326
*
[SV18500( ALL)05/95]
RWARNING
Never remove the coolant recovery cap
while the engine is running or hot.
*
[SV18600( ALL)05/95]
RWARNING
Follow these steps to minimize risk of
personal injury.
*
[SV18700( ALL)03/95]
1. Before you remove the cap, turn the engine
off and let it cool. Even when the engine is
cool, be careful when you remove the
radiator cap.
*
[SV18800( ALL)03/95]
2. When the engine is cool, wrap a thick cloth
around the cap and turn it slowly
counterclockwise to the first stop.
*
[SV18900( ALL)03/95]
3. Step back while the pressure releases.
*
[SV19000( ALL)04/95]
4. When you are sure that all the pressure has
been released, use the cloth to press, turn,
and remove cap.
*
[SV19100( ALL)03/95]
5. Stand away from the radiator opening. Hot
steam may blow out or hot engine coolant
may even splash out.
*
[SV19500( ALL)01/93]
Freezing Protection
*
[SV19600( ALL)03/91]
The factory-installed solution of Ford Premium
Cooling System Fluid and water will protect
your vehicle tos35ÊF (s37ÊC).Check the freeze
protection rating of the engine coolant at least
once a year, just before winter.
*
[SV19701( ALL)02/95]
Add engine coolant only to the recovery
reservoir.If the coolant level is low, add to the
reservoir a 50/50 mixture of water and the type
of engine coolant that Ford specifies. You may
add water by itself only in an emergency, but
you should replace it with a 50/50 mixture as
soon as possible.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

327
*
[SV19801( ALL)02/95]
Ford Premium Cooling System Fluid is an
optimized formula that will protect all metals
and rubber elastomers used in Ford engines for
four years or 50,000 miles (80,000 km). It is not
necessary and not recommended to use
supplemental coolant additives in your gasoline
powered vehicle. These additives may harm
your engine cooling system. Follow the
recommended service interval for changing your
engine coolant.
*
[SV19851( ALL)04/94]
NOTE: When you change or add engine
coolant, it is important to maintain
your engine coolant concentration
between 40%(-11ÊF [-24ÊC]) and 60%
(-62ÊF [-52ÊC]),depending on your local
climate conditions. Below 40% you will
lose freeze protection and above 60%
your engine may overheat on a warm
day.
*
[SV19950( ALL)03/95]
NOTE: Do not use an engine coolant that does
not meet all 14 requirements of Ford
Specification ESE-M97B44-A. The use
of an improper coolant may void your
warranty for the engine cooling system.
Use only a premium nationally
recognized brand name engine coolant.
*
[SV19960( ALL)05/95]
Ford Motor Company expressly authorizes the
Ford Rotunda engine coolant recycling process
and chemicals. Use only Ford Rotunda recycled
engine coolant or an equivalent recycled engine
coolant that is certified by the supplier to meet
Ford specification ESE-M97B44-A.
%*
[SV19980( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

328
*
[SV20001( ALL)01/95]
Use Ford Premium Cooling System Fluid or an
equivalent engine coolant that meets Ford
Specification ESE-M97B44-A. Do not use alcohol
or methanol antifreeze and do not use engine
coolant mixed with alcohol or methanol
antifreeze. If you do not use the proper coolant,
the aluminum radiator on your vehicle will
corrode.
*
[SV20100( ALL)01/95]
Leave the engine coolant in all year. Make sure
that the coolant will not freeze at the
temperature level in which you drive during
winter months. Keep a mixture of engine coolant
in your engine that has a protection rating of at
least-34ÊF (-37ÊC), orwhatever protection rating
is appropriate for the climate in which you live.
*
[SV20125( ALL)03/95]
To find out how much engine coolant mixture
your vehicle's coolant system can hold, seeRefill
capacities for fluidsin the Index.
*
[SV20151( ALL)01/95]
You may add water by itself only in an
emergency, but you should replace it with a
50/50 or appropriate mixture as soon as
possible.
*
[SV20200( ALL)01/95]
Have your dealer check the engine cooling
system for leaks if you have to add a quart
(liter) of engine coolant more than once a month.
%*
[SV20500( ALL)11/94]
Checking hoses
*
[SV20600( ALL)10/89]
Inspect all engine and heater system hoses for
deterioration, leaks and loose clamps before
adding or replacing engine coolant. Make
whatever repairs or replacements that are
necessary using Motorcraft parts or their
equivalents.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

329
*
[SV20700( ALL)05/95]
Engine coolant drain and flush
*
[SV20800( ALL)10/89]
To drain your vehicle's engine coolant:
*
[SV20900( ALL)03/94]
1. Turn off the engine and let it cool. Fully
depressurize the engine cooling system by
covering the radiator cap with a thick cloth
and turning it slowly counterclockwise to the
first stop. Step back while the pressure
releases.
*
[SV20950( ALL)05/90]
2. Remove the cap.
*
[SV21000(B FM)05/90]
3. Attach a small hose to the drain tube at the
bottom of the radiator.
*
[SV21200( ALL)05/90]
4. Let the engine coolant drain into a suitable
container. Disconnect the lower radiator hose
at the radiator connector and drain any
remaining engine coolant into a container.
*
[SV21225( ALL)05/94]
5. Reconnect the lower radiator hose and close
the radiator drain cock.
*
[SV21250( ALL)10/94]
Proper procedures for flushing the cooling
system can be found in theTruck Service Manual.
*
[SV21300( ALL)02/95]
Engine coolant refill procedure
*
[SV21400( ALL)10/89]
After you have drained the engine cooling
system:
*
[SV21500( ALL)01/89]
1. Fill the radiator with a 50/50 mixture of the
specified engine coolant concentrate and
water. Allow several minutes for trapped air
to escape (bubble out) and for engine coolant
to flow through the radiator.
*
[SV21900( ALL)03/94]
2. Replace the radiator cap to its fully installed
position, then back off to the first stop. This
will prevent high pressure from building up
in the cooling system during this part of the
fill procedure.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

330
*
[SV22100( ALL)10/89]
3. Start and idle the engine until the thermostat
opens and the radiator upper hose becomes
warm.
*
[SV22200( ALL)05/95]
4. Shut off the engine and allow the engine to
cool. Cover the radiator cap with a thick
cloth and cautiously remove it. Step back
while the pressure releases.
*
[SV22500( ALL)10/89]
5. Finally, check the radiator and add more
engine coolant if needed, following the
procedures noted above. Reinstall the
radiator cap securely, when finished.
*
[SV22525( ALL)05/90]
6. If more engine coolant is necessary, fill the
overflow reservoir to the appropriate level
marked on the bottle.
*
[SV22700(BEF )03/95]
Windshield Washer Fluid and
Wipers
*
[SV22800(BEF )03/95]
Washer Fluid
*
[SV22900(BEF )01/95]
Check the level of the windshield washer fluid
every time you stop for fuel. The reservoir for
the windshield washer fluid is located in the
engine compartment.
*
[SV23200(BEF )03/95]
Adding washer fluid
*
[SV23300(BEF )05/95]
RWARNING
Do not put windshield washer fluid in the
container for the engine coolant.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

335
*
[SV26450(BEF )03/95]
Traction-Lok Rear Axle (If equipped)
*
[SV26460(BEF )03/95]
This axle provides added drive away traction on
slippery surfaces, particularly when one or more
wheels are on a surface with poor traction.
*
[SV26470(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
%*
[SV26500( ALL)02/95]
Tire Rotation
*
[SV26600( ALL)03/95]
Because your vehicle's front and rear tires
perform different jobs, they often wear
differently. To make sure your tires wear evenly
and last longer, rotate them at the mileage
shown in theMaintenance Schedule and Record
booklet which came with your vehicle.
*
[SV26625( F )03/93]
For F-250 (over 8500 GVWR [3,855 kg]), F-350
and Super Duty vehicles, rotate the tires at 5,000
miles (8,000 km), then at 15,000 miles
(24,000 km), and then every 15,000 miles
(24,000 km) thereafter.
*
[SV26660( EF )03/94]
If your light truck has dual rear wheels, you can
rotate the front tires side to side without
disturbing the rear tires.
*
[SV26700(BEF )07/92]
Rotate the tires according to the following
diagram. If you notice that the tires wear
unevenly, have them checked. If your light truck
has a temporary spare tire, do not include it in
the tire rotation pattern.
*
[SV26750(BEF )03/90]
In situations where the tires differ from front to
rear (snow/traction), simply rotate using a side
to side pattern.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996
