Choosing the Right Fuel
*
[SV07550( EF )05/94]
NOTE: Read the7.3L Diesel Engine Owner
Guide Supplementfor information
regarding correct fuel requirements for
your diesel-powered vehicle.
*
[SV07600( ALL)05/95]
Use only UNLEADED FUEL in your vehicle.
Using leaded fuel is prohibited by federal law.
Your warranty may not apply if your vehicle is
damaged because you used the wrong fuel.
*
[SV07700( ALL)05/95]
Vehicle inspection programs may detect
misfueling. Under these circumstances, you may
be required by law to make costly repairs at
your own expense.
*
[SV08710( ALL)04/95]
Octane recommendations
*
[SV08725( ALL)04/95]
Your vehicle is designed to use regular
unleaded fuel with an octane rating of 87.In
most cases, it is not necessary to use a fuel with
an octane rating higher than 87. At service
stations, the octane rating is displayed on a label
on the pumps.
*
[SV08900( ALL)05/95]
one inch art:0060001-C
Typical octane rating label
*
[SV09050( ALL)05/95]
In some parts of the country, ªregularº grade
fuels are sold with octane ratings of 86 or even
less, especially in high altitude areas. We
recommend that you do not use these fuels.
Always use a fuel with an octane rating of 87,
even if it is sold as a ªmidgradeº or ªpremium.º
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

314
*
[SV09200( ALL)05/95]
Do not be concerned if your vehicle sometimes
knocks lightly when you drive up a hill or when
you accelerate. However, if a fuel with the
recommended octane rating knocks heavily
under all driving conditions or knocks lightly
driving at cruising speed on level roads, see
your dealer or a qualified service technician.
Persistent, heavy knocking can damage the
engine.
*
[SV09435( ALL)05/95]
Fuel quality
*
[SV09450( ALL)05/95]
If you are experiencing starting, rough idle or
hesitation problems when the engine is cold, it
may be caused by fuel with low volatility. Try a
different brand of fuel. If the condition persists,
see your dealer or a qualified service technician.
*
[SV09452( ALL)05/95]
Using a high-quality fuel makes your vehicle
more responsive and maintains its good fuel
economy and emissions by:
*
[SV09455( ALL)05/95]
q
protecting your fuel system from rusting.
*
[SV09460( ALL)05/95]
q
preventing the fuel lines from freezing.
*
[SV09465( ALL)05/95]
q
improving vehicle starting and warm-up.
*
[SV09470( ALL)05/95]
q
protecting the fuel system from vapor lock in
very hot weather, which causes the engine to
hesitate or stall and makes restarts difficult.
*
[SV09475( ALL)05/95]
q
minimizing deposits in fuel injectors,
combustion chambers, and on intake valves.
*
[SV09480( ALL)05/95]
q
preventing your fuel system from ªgumming
upº when your vehicle is not used for long
periods of time.
*
[SV09485( ALL)05/95]
q
preventing your engine from knocking and
pinging.
*
[SV09500( ALL)05/95]
It should not be necessary to add any
aftermarket products to your fuel tank if you
continue to use a high-quality fuel.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

318 %
*
[SV11300( ALL)05/95]
Running Out of Fuel
*
[SV11400( ALL)05/95]
If your vehicle runs out of fuel, try to stop on
level ground away from traffic. Add at least two
gallons (8 liters) of fuel to start your vehicle
again. If your vehicle is not on level ground,
you may need as much as five gallons (20 liters)
of fuel to start it.
*
[SV11500( ALL)05/95]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
%*
[SV11600( ALL)05/95]
Fuel Economy
*
[SV11700( ALL)05/95]
Fuel economy is an estimate of the efficiency of
your vehicle and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
*
[SV11750( ALL)05/95]
Do not calculate fuel economy during your
vehicle's break-in period. This would not be an
accurate estimate of how much fuel your vehicle
will normally use.
*
[SV11800( ALL)05/95]
To calculate fuel economy:
*
[SV11900( ALL)05/95]
1. Fill the tank completely and record the inital
odometer reading.
*
[SV12000( ALL)05/95]
2. Every time you buy fuel record the
amount (in gallons or liters) purchased.
*
[SV12200( ALL)05/95]
3. After at least three to five tankfuls, fill the
fuel tank and record the final odometer
reading.
*
[SV12225( ALL)05/95]
4. Use these equations to calculate your fuel
economy.
*
[SV12250( ALL)05/95]
q
English: MPG = (total miles)/(gallons used).
*
[SV12275( ALL)05/95]
q
Metric: L/100K = (liters used) x 100/(total
kilometers)
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

319
*
[SV12300(BEF )05/95]
Comparisons With EPA Fuel Economy
Estimates
*
[SV12400(BEF )05/95]
EPA fuel economy figures are obtained from
laboratory tests under simulated road conditions
and may not reflect the actual conditions you
experience or your style of driving. The EPA
fuel economy estimate is not a guarantee that
you will achieve the fuel economy shown.
*
[SV12450( F )03/93]
NOTE: There are no EPA fuel economy
estimates for vehicles over 8500 lbs.
(3,855 kg) GVW.
*
[SV12500( ALL)05/95]
Improving Fuel Economy
*
[SV12600( ALL)05/95]
Fuel economy is affected by a number of
variables which can reduce efficiency. You can
improve fuel economy by understanding these
variables and minimizing their effect.
*
[SV12700( ALL)05/95]
The following decrease fuel economy:
*
[SV12800( ALL)05/95]
q
Lack of regular, scheduled maintenance
*
[SV12900( ALL)05/95]
q
Driving with your foot on the brake
*
[SV13000( ALL)05/95]
q
Sudden stops
*
[SV13100( ALL)05/95]
q
Excessive speed
*
[SV13200( ALL)05/95]
q
Extended engine idling
*
[SV13300( ALL)05/95]
q
Heavy loads
*
[SV13400( ALL)05/95]
q
Underinflated tires
*
[SV13500(BEF )05/95]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
*
[SV13550(BEF )05/95]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

320
*
[SV13600( ALL)02/95]
Engine Oil Recommendations
*
[SV13610( ALL)04/95]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
ESE-M2C153-E and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[SV13655( ALL)03/95]
one third page art:0060020-D
The API Certification Mark
*
[SV13670( ALL)01/95]
Neveruse:
*
[SV13680( ALL)01/95]
q
ªNon-Detergentº oils
*
[SV13690( ALL)04/95]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[SV13700( ALL)01/95]
q
Additional engine oil additives, oil treatments
or engine treatments
[SV13705( EF )04/95]
For vehicles with 5.8L engines.
*
[SV13710(BEF )03/95]
Engine oils with anSAE 5W-30viscosity are
PREFERREDfor your vehicle. They provide the
best engine performance, fuel economy and
engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[SV13725( ALL)03/95]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

321
*
[SV13730( EF )01/93]
For vehicles with 4.9L, 5.0L or 7.5L engines
[SV13740( ALL)04/95]
Engine oils with anSAE 10W-30viscosity are
PREFERREDfor your vehicle which provide the
best engine protection for all climates down to
-5ÊF (-20ÊC). SAE5W-30 engine oils may also be
used down to-15ÊF (-25ÊC).
[SV13745( ALL)02/95]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
*
[SV13775( ALL)01/95]
Checking and Adding Engine Oil
*
[SV13800( ALL)03/95]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
*
[SV13900( ALL)03/95]
Checking the engine oil level:
*
[SV14000( ALL)02/95]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[SV14050(B F )03/95]
2. Set the parking brake, making sure that the
gearshift is securely latched in P (Park)
(automatic transmission) or 1 (First) (manual
transmission).
*
[SV14100( ALL)02/95]
3. Open the hood. Protect yourself from engine
heat.
*
[SV14200( ALL)03/95]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[SV14300( ALL)01/95]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

322
*
[SV14400( ALL)05/94]
quarter page art:0010364-D
Engine oil dipstick
*
[SV14500( ALL)02/95]
6. Carefully, pull the dipstick out again. If the
oil level is below the ªADD 1 QT.º line, add
engine oil as necessary. If the oil level is
beyond the letter ªFº in FULL, engine
damage or high oil consumption may occur
and some oil must be removed from the
engine.
*
[SV14600( ALL)01/95]
7. Put the dipstick back in and make sure it is
fully seated.
*
[SV14800( ALL)01/95]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[SV15000( ALL)03/95]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

323 %
*
[SV16300( EFM)01/95]
Changing the Engine Oil and the Oil Filter
*
[SV16500( ALL)04/95]
Change the engine oil and oil filterper the
following, whichever occurs first.
*
[SV16600(BEF )04/95]
one third page art:0060618-C
Oil change intervals
*
[SV16625( ALL)03/95]
NOTE: Idling the engine for extended periods
will accumulate more hours of use on
your vehicles than is actually indicated
by the mileage odometer.
Consequently, the odometer reading
can be often misleading when
determining the right time to change
your engine oil and filter.
*
[SV16650(BEF )03/95]
If you are using your Ford vehicle in a manner
which allows it to remain stationary while the
engine is running for long periods (door to door
delivery, taxi, police, power/utility company
trucks, or similar duty), then Ford recommends
you increase the frequency of oil and filter
changes to an interval equivalent to 200
ENGINE HOURS of use. Since most vehicles are
not equipped with hourmeters, it may be
necessary for you to approximate your idle time
and plan oil/filter changes accordingly.
