1996 FORD F150 engine

200
*
[DR20500(B F )11/89]
After driving through mud, clean off residue
stuck to rotating driveshafts and tires. Excess
mud stuck on tires and rotating driveshafts
causes an imbalance which could damage drive
components.
*
[DR20525(B F )07/94]
NOTE: If the transmission and transfer case is
submerged in water, their fluids should
be checked and changed, if necessary.
*
[DR20550( F )05/90]
NOTE: Refer to the Diesel Engine Owner's
Guide Supplement for driving through
deep water information.
*
[DR20600( F )05/89]
Additional Special Driving
Instructions for 4-Wheel Drive
Vehicle Operators
*
[DR20701(B F )11/89]
Driving on Hill or Slope Terrain
*
[DR20800(B F )08/94]
When driving on a hill, it may be necessary to
travel diagonally up or down. Avoid driving
crosswise or turning on steep slopes, you could
lose traction and slip sideways. Drive straight
up, straight down or avoid the hill completely.
Know the conditions on the other side of a hill
before driving over the crest.
*
[DR20900(B F )11/89]
When climbing a steep hill, start in a lower gear,
rather than finding it necessary to downshift
from a higher gear after the ascent has started.
This reduces strain on the engine and the
possibility of stalling.
*
[DR21000(B F )11/89]
When descending a steep hill avoid sudden
braking. Rapid pumping of the brake pedal will
help slow the vehicle and still maintain steering
control.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

204
*
[DR23250( ALL)11/89]
If during normal operation the brake pedal
seems ªlowº, it may indicate the need for a
brake system inspection and/or service. You
should have your brakes checked as soon as
possible.
*
[DR23300( ALL)02/95]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes annoyingly loud or increases
significantly in frequency of occurrence, return
the vehicle to your dealer for inspection.
*
[DR23400(BEF )11/89]
RWARNING
Modifications to the suspension spring
rates and/or vehicle ride height may
adversely affect vehicle stopping ability.
*
[DR23500(BEF )07/92]
If Brakes Pull
*
[DR23600(BEF )07/92]
q
Check tire pressure
*
[DR23700(BEF )07/92]
q
Perform the self-adjustment procedure
described underIf Brakes Do Not Grip Well or
Pedal is ªLow.º
*
[DR23800(BEF )05/95]
If pull occurs during the first 500 miles
(800 km), make 10 moderately fast stops from
40 mph (65 km/h) and then perform the
self-adjustment procedure above. It may be
necessary to repeat this operation to properly
seat new brake linings and pads.
*
[DR24000( ALL)01/93]
Stopping Distances
*
[DR24100( ALL)11/89]
Stopping distances vary with different loads and
driving conditions. Use caution when
encountering new conditions and acquaint
yourself with vehicle performance. Take full
advantage of engine braking power when
slowing down.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

206
*
[DR24920(B FM)07/91]
one third page art:0020893-A
Parking Brake
*
[DR24950(B F )03/95]
RWARNING
When parking, do not use the gearshift in
place of the parking brake. Turn the key
to LOCK whenever you leave your
vehicle. Always set the parking brake
fully and make sure that the gearshift is
securely latched in P (Park) (automatic
transmission) or in 1 (First) (manual
transmission). Never leave your vehicle
unattended while it is running. If you do
not take these precautions, your vehicle
may move unexpectedly and injure
someone.
[DR24970(B F )05/95]
When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if the
automatic transmission is in P (Park) or the
manual transmission is in gear.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

209
*
[DR26625(BEF )12/91]
Speed limiter
*
[DR26652(BEF )03/94]
All models are equipped with an electronic
engine control system (EEC) which limits the
maximum engine speed and thus road speed in
top gear. Vehicle operation is normal since the
controlled maximum speed is above posted
highway speeds in North America.
%*
[DR26701( ALL)01/95]
Driving in Bad Weather
%*
[DR26750( ALL)01/95]
Slippery roads
*
[DR26801( ALL)03/95]
Drive cautiously on wet or snowy roads:
*
[DR26850( ALL)03/95]
q
Do not quickly move the steering wheel
unless necessary.
*
[DR26901( ALL)01/95]
q
Drive slower than you normally would.
*
[DR26951( ALL)01/95]
q
Give your vehicle more distance to stop.
*
[DR27025( ALL)07/94]
q
To stop on ice, shift to Neutral below 10 mph
(16 km/h) and gently pump brakes. (Except
with 4WAL)
*
[DR27050( ALL)02/93]
q
Consider using one of the lower gears.
*
[DR27101(B F )05/91]
q
For 4x4 vehicles, engage 4WD, and try to
drive slowly away.
*
[DR27150(B F )05/95]
RWARNING
To avoid losing control on slippery roads,
do not downshift into Low with the
automatic transmission when moving
faster than 20 mph (32 km/h). Do not
downshift into First with the manual
transmission when moving faster than
5 mph (8 km/h).
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

210
*
[DR27350(B F )06/94]
RWARNING
The rear antilock brake system may not
prevent brake lock-up on extremely
slippery surfaces. Rear brake lock-up may
also occur while driving in four-wheel
drive because the transfer case couples the
front and rear axles together.
*
[DR27450(BEF )03/95]
Traction-Lok Rear Axle (If equipped)
*
[DR27501(BEF )03/95]
This axle provides added drive away traction on
slippery surfaces, particularly when one or more
wheels are on a surface with poor traction.
*
[DR27550(BEF )03/93]
Extended use of other than matching size tires
on a Traction-Lok rear axle could result in a
permanent reduction in effectiveness. This loss of
effectiveness does not affect normal driving and
should not be noticeable to the driver.
*
[DR27601(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
%*
[DR27651( ALL)01/95]
High water
*
[DR27675( ALL)06/92]
Never attempt to cross water that is fast flowing
or of unknown depth.
*
[DR27701( ALL)05/90]
Do not drive through flooded areas unless you
are sure that the water is below the bottom of
the wheel hubs.
*
[DR27750( ALL)04/94]
If you must drive through high water, drive
slowly. You may have limited traction or wet
brakes, so allow extra stopping distance because
your vehicle will not stop as quickly as usual.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

211
*
[DR27801( ALL)01/95]
After you drive through the standing water,
apply your brakes gently several times as your
vehicle moves slowly. This helps to dry the
brakes.
*
[DR27820( ALL)07/94]
NOTE: If the transmission and transfer case is
submerged in water, their fluids should
be checked and changed, if necessary.
*
[DR27825( ALL)03/93]
NOTE: All rear axle lube quantities must be
replaced every 100,000 miles
(160,000 km) or if the axle has been
submerged in water. Otherwise, the
lube should not be checked or changed
unless a leak is suspected or repair
required.
*
[DR27850( ALL)11/89]
Rocking the vehicle
*
[DR27901(B F )05/90]
For 4x4 vehicles, engage 4WD LOW, when the
vehicle gets stuck and try to drive away.
*
[DR27950( ALL)05/95]
If your vehicle gets stuck (for example, in mud
or snow), you may rock it out of the spot. Shift
in a steady rhythm between forward and reverse
gears. Allow the transmission to fully engage,
then press lightly on the accelerator. Do not rock
the vehicle for more than a few minutes. This
may overheat the engine and transmission,
causing damage to both. In addition, other
vehicle systems and components may also be
damaged.
*
[DR27975( ALL)05/95]
RWARNING
Do not spin the wheels at over 35 mph
(56 km/h). The tires may fail and injure a
passenger or bystander.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

214
*
[DR28750( ALL)01/93]
Vehicle/Trailer Loads
*
[DR28801( ALL)06/92]
All vehicles may tow a Class I trailer provided
the Gross Combined Weight (GCW) is less than
or equal to the GVWR shown on the Safety
Compliance Certification Label. For heavier
trailer applications, refer to the towing
information found later in this chapter.
*
[DR28950(BEF )02/95]
Trailer Towing (may require trailer tow
option package)
*
[DR29001( ALL)03/91]
Towing a trailer puts additional loads on your
vehicle's engine, transmission, axle, brakes, tires
and suspension. For your safety and for the
good of your vehicle, use the right equipment
for the type of trailer you tow.
[DR29010(B F )05/95]
If your trailer is equipped with electric brakes,
auxiliary battery, or back-up lamps, the optional
7 wire trailer towing electrical hook-up will be
required on the vehicle.
*
[DR29025( ALL)09/92]
Your trailer towing capability will vary based on
the standard and optional equipment on your
vehicle. Refer to the followingVehicle
Loading/Towing Informationand the Trailer
Towing Tables to determine the specific towing
capability of your vehicle.
*
[DR29050( ALL)02/92]
q
Stay within the load limits when you tow.
*
[DR29101( ALL)01/95]
q
Carefully and thoroughly prepare your
vehicle for towing, making sure to use the
right equipment and to attach it properly.
(SeePreparing to Towin this chapter.)
*
[DR29151( ALL)01/95]
q
Use extra caution when driving your vehicle
while you tow. (SeeDriving while you towin
this chapter.)
*
[DR29201( ALL)01/95]
q
Service your vehicle more frequently if you
tow a trailer. (SeeServicing your vehicle if you
towin this chapter.)
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

219
*
[DR31050( ALL)06/92]
Passenger car type tires when installed on light
trucks and multipurpose passenger vehicles are
rated at 10% lower load carrying capacity due to
the differences in vehicle usages.
*
[DR31101(BEF )07/92]
The vehicle must not be loaded to both the front
and rear GAWR because the GVWR will be
exceeded. The GAWR of the front and rear axles
exceed the GVWR when added together to allow
flexibility in fore and aft loading of cargo.
*
[DR31110( ALL)06/92]
With the tires inflated to the specified pressure
the total weight of your vehicle must not exceed
the GVWR and GAWR specified on the Safety
Compliance Certification Label. This includes full
fuel tank(s), vehicle equipment, and occupants as
well as the cargo load.
*
[DR31120( ALL)06/92]
GCWR (Gross Combined Weight Rating)
*
[DR31130( ALL)06/92]
GCWR is the maximum combined weight of the
towing vehicle (including passengers and cargo)
and the loaded trailer. The GCWR is specified
by the manufacturer to indicate the combined
maximum loaded weight that the vehicle is
designed to tow.
*
[DR31140( ALL)06/92]
Maximum Trailer Weight Rating
*
[DR31150( ALL)06/92]
The maximum weight of a trailer the vehicle is
permitted to tow. The maximum trailer weight
rating is specified by the manufacturer and is
determined by subtracting the vehicle curb
weight for each engine/transmission
combination, any required option weight for
trailer towing and the weight of the driver from
the GCWR for the towing vehicle.
*
[DR31160( ALL)06/92]
Maximum Trailer Weight
*
[DR31170( ALL)06/92]
The maximum weight of a trailer the loaded
vehicle is permitted to tow. The maximum
weight of the trailer is determined by subtracting
the weight of the loaded towing
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
