1996 FORD F150 engine

184
*
[DR14700( F )03/94]
4.9L, 5.8L & 7.5L Engine with 5-Speed H.D.
Manual Overdrive Transmission (4x2 and
4x4) over 8500 GCW (ZF Transmission)
[DR14800( F )02/95]
twenty pica chart:0020143-C*
[DR14850( F )11/89]
NOTE: Refer to the Diesel Engine Owner's
Guide Supplement for shift speed
information on vehicles equipped with
7.3L diesel engines.
*
[DR15100(B F )03/95]
When you slow down or climb a steep hill,
always downshift before the engine starts to lose
power. Downshifting reduces the chance of
stalling and gives your vehicle better acceleration
to increase speed again.
*
[DR15200(B F )03/95]
When you drive down steep hills, downshifting
helps you keep a safe speed and helps prevent
unnecessary wear on the brakes.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

185
*
[DR15300(B F )03/95]
When you come to a stop, do not downshift
through each gear. Disengage the clutch and use
the brake as necessary. Downshifting through
the gears decreases your vehicle's fuel economy.
*
[DR15400(B F )05/95]
RWARNING
Continued use of a damaged or worn
clutch, prolonged clutch slippage or
downshifting at excessive speeds can
result in a failure of the engine,
transmission or clutch components.
*
[DR15500(B F )03/91]
Transmission Function
*
[DR15600(B F )03/91]
Upshift at the speeds specified in the chart
available for your engine and transmission. All
forward gears are synchronized allowing you to
shift into them with your vehicle in motion. The
clutch pedal should be fully depressed when
shifting.
*
[DR15625(B F )04/94]
NOTE: Shifting during extremely low rpm's
can result in a momentary audible
rattle which disappears as vehicle
rpm's are increased. Shifting at higher
speeds will eliminate this sound.
*
[DR15700(B F )03/95]
Parking
*
[DR15800(B F )01/95]
To park your vehicle, apply the service brake
pedal, and shift into N (Neutral) while still
maintaining pressure on the service brake. Set
the parking brake fully. Shift into first and turn
off the ignition.
*
[DR15900(B F )05/95]
RWARNING
Do not park your vehicle in Neutral, it
may move unexpectedly and injure
someone. Use 1 (First) gear and set the
parking brake fully.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

186 [DR15903(B F )05/95]When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if the
automatic transmission is in P (Park) or the
manual transmission is in gear.
*
[DR15906(B F )05/95]
RWARNING
Do not leave the vehicle unattended with
the transfer case in the N (Neutral)
position. Always set the parking brake
fully and turn off the ignition when
leaving the vehicle.
*
[DR15915( ALL)01/95]
Steering Your Vehicle
%*
[DR15945( ALL)01/95]
Your vehicle comes with power steering. Power
steering uses energy from the engine to help
steer your vehicle.
%*
[DR15950( ALL)04/95]
If the amount of effort needed to steer your
vehicle changes at a constant vehicle speed, have
the power steering system checked. If the power
steering system breaks down (or if the engine is
turned off), you can steer the vehicle manually
but it takes more effort.
*
[DR15960( ALL)01/95]
Never hold the steering wheel to the extreme
right or left for more than five seconds if the
engine is running. This can damage the power
steering pump.
*
[DR15985( ALL)05/90]
NOTE: After any severe impact such as
striking large potholes, sliding into
curbs on icy roads, or a collision
involving the front end, observe the
steering wheel alignment. If the spokes
of the steering wheel seem to be in a
different position while going straight
down the road, have the front
suspension and steering checked for
possible damage.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

187
*
[DR16101(B F )03/95]
Four-Wheel Drive (4WD)
System (If equipped)
*
[DR16130(B F )08/94]
When you select the 4WD mode, your light
truck uses all four wheels to power itself. This
increases traction, enabling you to drive your
4x4 over terrain and road conditions two-wheel
drive vehicles cannot.
*
[DR16160(B F )10/94]
Power is supplied to all four wheels through a
transfer case that allows you to select four-wheel
drive when necessary. Methods for engaging and
disengaging 4WD and low range will depend on
which system your vehicle has.
*
[DR16190(B F )01/95]
4x4 Systems Ð Lever Operated
*
[DR16220(B F )06/94]
The lever operated transfer case can be placed
into four positions. The 2H position is the
two-wheel drive position in which power is
delivered only to the rear axle. The 4H position
provides four-wheel drive with power delivered
to the front and rear axles for increased traction.
The 4L position provides four-wheel drive with
power delivered to the front and rear axles
when the above average power is required at
reduced speeds. In the N (neutral) position, there
is no power delivered to either axle.
[DR16225(B F )05/95]
When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if the
automatic transmission is in P (Park) or the
manual transmission is in gear.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

189
*
[DR16310(B F )01/95]
Four-wheel drive operation (4H or 4L) on dry
pavement is not recommended. Operating the
vehicle in four-wheel drive on dry pavement
will increase tire wear, decrease fuel economy,
and make four-wheel drive disengagement
difficult for the transfer case.
*
[DR16340( F )06/93]
NOTE: All transfer cases on F-350 4x4 trucks
are equipped with an opening for a
power take-off (PTO). If this opening
is used for a transfer case mounted
PTO, additional transfer case lubricant
is required. Refer to the Refill
Capacities section for lubricant fill
requirements. Vehicles equipped with
an E4OD automatic transmission and a
7.3L diesel engine will require exhaust
modification for PTO clearance. For
vehicles equipped with an E4OD
automatic transmission: If a transfer
case mounted PTO is operated with the
transfer case shift lever in neutral, a
Vehicle Speed Sensor Self-test error
may be set in the Powertrain Control
Module (PCM) causing the
transmission to function abnormally,
and the Transmission Control Indicator
Light (TCIL) may flash on and off
repeatedly. Normal transmission
function should return when the
transfer case has been engaged and the
vehicle is driven. If the TCIL continues
to flash or the transmission continues
to operate abnormally contact your
Ford dealer as soon as possible.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

192one continuous motion without pausing in the N
(neutral) position. Pausing in the neutral position
can result in gear clash and difficult shifting. If,
while shifting between 4H and 4L, the transfer
case gets stuck in the N (neutral) position or is
difficult to shift into either 4H or 4L, it may be
necessary to let the vehicle roll slightly and/or
turn off the engine (particularly on vehicles
equipped with automatic transmissions).
*
[DR16880(B F )03/91]
To shift into and out of N (neutral)
*
[DR16910( F )05/91]
To shift into N (neutral), stop the vehicle and
engage the parking brake. Place the automatic
transmission into NEUTRAL or depress the
clutch on manual transmission vehicles. From
either the 4H or 4L position, push the transfer
case shift knob down (toward the ground) and
at the same time move the transfer case shift
lever to the N (neutral) position. The N (neutral)
position should only be used for vehicle towing
or transfer case mounted PTO use (transfer case
PTO opening available on F-350 only).
*
[DR16955(B F )12/91]
NOTE: Dash mounted four wheel drive
indicator lights are off when your
vehicle is in neutral.
*
[DR17001(B F )05/91]
To shift from N (Neutral) to either 4H or 4L,
stop the vehicle and engage the parking brake.
Place the automatic transmission into NEUTRAL
or depress the clutch on manual transmission
vehicles. Push the transfer case knob down
(toward the ground) and at the same time move
the transfer case shift lever to the desired
position. If it is difficult to shift into either 4H or
4L, it may be necessary to let the vehicle roll
slightly and/or turn off the engine (particularly
on vehicles equipped with automatic
transmissions).
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

194
*
[DR17270(B F )06/94]
Operating in 2H with the hubs in the LOCK
position increases fuel consumption, noise,
vibration, and wear. For prolonged 2H operation
on dry pavement, set the manual locking hubs
to the FREE position.
*
[DR17301(B F )06/94]
To shift between 4H and 4L:
*
[DR17330(B F )05/91]
Stop the vehicle and place the automatic
transmission into NEUTRAL or depress the
clutch on manual transmission vehicles. Push the
transfer case shift knob down (toward the
ground) and at the same time pull or push the
lever straight forward or rearward (depending
on the desired position 4H or 4L) in order to
shift the transfer case. This shift should be with
one continuous motion without pausing in the N
(neutral) position. Pausing in the neutral position
can result in gear clash and difficult shifting. If,
while shifting between 4H and 4L, the transfer
case gets stuck in the N (neutral) position or is
difficult to shift into either 4H or 4L, it may be
necessary to let the vehicle roll slightly and/or
turn off the engine (particularly on vehicles
equipped with automatic transmission).
*
[DR17390(B F )06/94]
To shift to N (neutral) from either 4H or 4L
*
[DR17420( F )05/91]
To shift into N (neutral), stop the vehicle and
engage the parking brake. Place the automatic
transmission into NEUTRAL or depress the
clutch on manual transmission vehicles. From
either the 4H or 4L position, push the transfer
case shift knob down (toward the ground) and
at the same time move the transfer case shift
lever to the N (neutral) position. The N (neutral)
position should only be used for vehicle towing
or transfer case mounted PTO use (transfer case
PTO opening available on F-350 only).
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

195
*
[DR17490(B F )12/91]
NOTE: Dash mounted four wheel drive
indicator lights are off when your
vehicle is in neutral.
*
[DR17540(B F )01/95]
To shift from N (Neutral) to either 4H or 4L,
stop the vehicle and engage the parking brake.
Place the automatic transmission into N
(Neutral) or depress the clutch on manual
transmission vehicles. Push the transfer case shift
lever to the desired position. If it is difficult to
shift into either 4H or 4L, it may be necessary to
let the vehicle roll slightly and/or turn off the
engine (particularly on vehicles equipped with
automatic transmissions).
*
[DR17570(B F )06/94]
4x4 SYSTEMS-TOUCH DRIVE
*
[DR17601(B F )06/94]
The Touch Drive 4x4 system functions in three
modes. In Two Wheel Drive mode, power is
delivered only to the rear axle at normal road
speed. The 4H position provides four-wheel
drive with power delivered to the front and rear
axles for increased traction. The 4L position
provides four-wheel drive with power delivered
to the front and rear axles when the above
average power is required at reduced speeds.
*
[DR17630(B F )06/94]
Four wheel drive operation (4x4 or 4x4 LOW
RANGE) on dry pavement is not recommended.
Operating the vehicle in four-wheel drive on dry
pavement will increase noise, vibration, tire
wear, decrease fuel economy, and make
four-wheel drive disengagement difficult for the
transfer case.
%*
[DR17660(B F )06/94]
Touch Drive system indicator lights
*
[DR17690(B F )03/91]
A 4x4 indicator light and a LOW RANGE
indicator light are located at the lower right of
the instrument cluster. In addition, two small
amber lights are located near the Touch Drive
system buttons. The amber light to the left of the
4x4 button will light up at the same time as the
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
