Driving With a Heavy Load
*
[DR28101(BEF )01/95]
There are limits to the amount of weight your
vehicle can carry or tow. The total weight of
your vehicle, plus the weight of the passengers
and cargo, should never be more than the Gross
Vehicle Weight Rating (GVWR). Also, the weight
that your vehicle carries over the front axle and
rear axle should never be more than the Gross
Axle Weight Rating (GAWR) for the respective
axle.
*
[DR28150(BEF )01/95]
The weight limits of your vehicle's tires affect
the GVWR or GAWR limitations. Usage of
replacement tires with higher weight limit than
originals does not increase GVWR or GAWR.
Usage of lower capacity replacement tires may
lower GVWR and GAWR limitations.
*
[DR28201(BEF )02/95]
RWARNING
If the GVWR or the GAWR specified on
the Safety Compliance Certification Label
is exceeded, your vehicle may be damaged
or you may lose control and injure
someone.
*
[DR28250(B F )03/91]
Heavy duty front suspension package
(option)
*
[DR28301(B F )03/91]
This optional front suspension package is
designed to handle the additional loads that will
be imposed on the vehicle by adding aftermarket
equipment, such as a snowplow. Refer to the
Safety Compliance Certification Label for details.
*
[DR28350( F )03/91]
Securing loads in cargo area
*
[DR28450( F )03/91]
To prevent damage to the pickup box and cab,
secure any movable cargo pieces using ropes or
straps and the tie down holes in the stake
pockets of the steel pickup box or the tie-down
bars in the flareside pickup box.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

215
*
[DR29350( ALL)05/94]
Do not tow a trailer until your vehicle has been
driven at least 500 miles (800 km).
*
[DR29401( ALL)06/92]
Vehicle Loading/Towing
Information
*
[DR29450(BEF )03/91]
Your vehicle's load capacity is designated by
weight, not volume, so you cannot necessarily
use all available space with large or heavy loads.
Maximum safe vehicle weights as well as tire,
rim sizes and inflation pressures are specified for
your vehicle at the assembly plant on the Safety
Compliance Certification Label. The Certification
Label is located on the left front door lock facing
or the door latch post pillar.
*
[DR29501( ALL)12/91]
Trucks, unlike passenger cars, are basically
custom vehicles designed to carry a load. Most
owners start with a base vehicle and add
production and dealer installed and/or
aftermarket components to suit their tastes and
purposes. Even trucks that are purchased for
personal transportation only are likely to have
considerable optional equipment, such as step
bumpers and light bars, for example.
*
[DR29525( ALL)05/95]
RWARNING
Passengers should not be allowed to ride
in the cargo area. Persons not riding in a
seat with a fastened seat belt are much
more likely to suffer serious injury in a
collision. Cargo should always be secured
to prevent it from shifting and causing
damage to the vehicle or harm to
passengers.
*
[DR29551( ALL)03/91]
Each additional item of equipment affects how
much cargo a vehicle can carry. If a vehicle is
overloaded, performance will suffer and service
concerns may arise.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

276
*
[RE24700( ALL)05/95]
Towing Your Vehicle
[RE24885( F)]
If you need to have your vehicle towed, contact
a professional towing service or, if you are a
member, your roadside assistance center.
The recommended method to tow your vehicle
is with flatbed or wheel lift equipment.
However, slingbelt towing is acceptable.On
vehicles equipped with an air dam,the towbar
will deform the rubber air dam.On vehicles
equipped with a rear valance panel instead of a
rear bumper,do not tow the vehicle from the
rear with slingbelt equipment.
[RE24925(ALL )02/95]
half page art:0001463-AFile:ltref.ex
Update:Thu May 9 15:24:41 1996

280
*
[RE27400(B F )11/92]
q
When towing your vehicle with the rear
wheels on the ground or all four wheels on
the ground and the driveshafts connected, do
not exceed 35 mph (56 km/h) or
transmission damage could result. If a
distance of 50 miles (80 km) is exceeded,
disengage the automatic locking hubs and
disconnect the rear driveshaft from the axle
and secure. (Max speed 55 mph [88 km/h]
with driveshafts disconnected.)
*
[RE27500(BEF )03/91]
RWARNING
Never use a tow bar that attaches to the
bumper when you tow your vehicle. This
could damage the bumper and cause an
accident.
