1996 FORD ASPIRE Owners Manual

39 [SR21401(ALL)05/94]
Install the hardware for anchoring the tether
following the instructions in the tether anchorage
hardware kit. When attaching the anchor bracket
to the anchor, position the anchor bracket
straight up.
%*
[SR24110(ALL)07/95]
Safety Belts for Children
*
[SR24120(ALL)07/95]
Children who are too large for child safety seats
should always wear safety belts. (See instructions
with your child seat, or contact its manufacturer,
to determine maximum size of child that will
safely fit in the seat.)
*
[SR24130(ALL)07/95]
RWARNING
If safety belts are not properly worn and
adjusted as described, the risk of serious
injury to the child in a collision will be
much greater.
*
[SR24140(ALL)07/95]
If the shoulder belt portion of one of the lap and
shoulder belts can be positioned so that it does
not cross or rest in front of the child's face or
neck, the child should wear the lap and shoulder
belt. Moving the child closer to the center of the
vehicle may help provide a good shoulder belt
fit.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996

40
*
[SR24150(ALL)07/95]
To improve the fit of lap and shoulder belts on
children who have outgrown child safety seats,
Ford recommends use of a belt-positioning
booster seat that is labelled as conforming to all
Federal motor vehicle safety standards.
Belt-positioning booster seats raise the child and
provide a shorter, firmer seating cushion that
encourages safer seating posture and better fit of
lap and shoulder belts on the child. A
belt-positioning booster should be used if the
shoulder belt rests in front of the child's face or
neck, or if the lap belt does not fit snugly on
both thighs, or if the thighs are too short to let
the child sit all the way back on the seat cushion
when the lower legs hang over the edge of the
seat cushion. You may wish to discuss the
specific needs of your child with your
pediatrician.
*
[SR24160(ALL)07/95]
RWARNING
Do not use a belt-positioning booster with
a lap-only belt.
*
[SR24170(ALL)07/95]
Lap belts and the lap belt portion of lap and
shoulder belts should always be worn snugly
and below the hips, touching the child's thighs.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996

41
Starting Your Aspire
*
[ST01700(ALL)03/95]
Ignition
*
[ST01800(ALL)01/95]
Understanding the Positions of the Ignition
[ST01900(ALL)01/95]
The ignition has four positions. They are: LOCK,
ACC, ON, and START.
[ST02000(ALL)05/93]
one third page art:0032158-A
Ignition lock cylinder (manual transaxle)
[ST02050(ALL)05/93]
one third page art:0032159-A
Ignition lock cylinder (automatic transaxle)
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

42
*
[ST02100(ALL)09/93]
LOCK locks the steering wheel. It also locks the
gearshift lever in P (Park) (automatic transaxle).
*
[ST02200(ALL)01/95]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
*
[ST02300(ALL)05/95]
If your key is stuck in the LOCK position and
will not turn, move your steering wheel left or
right until the key turns freely.
[ST02325(ALL)09/93]
If your vehicle has a manual transaxle, you must
push the key toward the steering column to
rotate the switch to the LOCK position.
%*
[ST02350(ALL)03/95]
ACC (accessory) allows some of your vehicle's
electrical accessories such as the radio and the
windshield wipers to operate while the engine is
not running.
*
[ST02400(ALL)05/95]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
*
[ST02500(ALL)03/95]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

43
*
[ST02505(ALL)09/93]
Shift-lock System
*
[ST02510(ALL)07/95]
For your safety, the optional automatic transaxle
has a shift-lock system, which prevents shifting
the transaxle out of the P (Park) position without
depressing the brake pedal when the ignition
key is in the ON position.
*
[ST02515(ALL)07/89]
To shift the transaxle out of the P (Park)
position:
*
[ST02521(ALL)05/90]
1. Depress and hold the brake pedal.
*
[ST02526(ALL)11/93]
2. Start the engine.
[ST02528(ALL)02/92]
3. Push in the thumb lock button and move the
gearshift lever.
[ST02529(ALL)07/93]
4. SeeEmergency Override Systemlater in this
section for more information.
*
[ST02535(ALL)09/93]
NOTE: When the ignition key is in the ACC
or LOCK position, the transaxle cannot
be shifted from the P (Park) position.
If the brake pedal is repeatedly
depressed and released when the
ignition is in the ON position and the
selector lever is in the P (Park)
position, a chattering near the gearshift
lever may be heard. This is not a
malfunction.
*
[ST02538(ALL)03/94]
NOTE: Your vehicle's gearshift lever is
securely latched in P (Park) if you
cannot move it without pushing in the
thumb button. Keep the brake pedal
depressed while moving your gearshift
lever.
*
[ST02540(ALL)09/93]
To make the system more effective, the ignition
key cannot be removed unless the gearshift
selector lever is in the P (Park) position.
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

44 [ST02650(ALL)07/93]Emergency Override System
[ST02720(ALL)09/93]
Your vehicle has a cap covering the override
mechanism for the shift-lock feature. If you have
to use the override procedure to move the
gearshift lever out of the P (Park) position,
follow these instructions:
*
[ST02740(ALL)06/95]
1. Remove the shift-lock override cap with a 1ª
or longer screwdriver.
*
[ST02760(ALL)03/93]
2. Insert the screwdriver into the shift-lock
override opening and push the screwdriver
handle down.
[ST02780(ALL)12/93]
two third page art:0032202-C
Operating the shift-lock override mechanism
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

45
*
[ST02820(ALL)06/93]
3. Push and hold the thumb button.
[ST02830(ALL)09/93]
4. Move the gearshift lever.
*
[ST02832(ALL)07/95]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledServicing Your Aspirein
this Owner Guide for instructions on checking
and replacing fuses.
*
[ST02835(ALL)05/95]
RWARNING
DO NOT DRIVE YOUR VEHICLE UNTIL
YOU VERIFY THAT THE BRAKELAMPS
ARE WORKING.
%*
[ST02850(ALL)03/95]
Ignition Key Chime
*
[ST02875(ALL)10/90]
If the driver or passenger door is open while the
key is still in the ignition, a warning chime
sounds.
%*
[ST02900(ALL)02/95]
Removing the Key From the Ignition
*
[ST03000(ALL)09/93]
1. Put the gearshift selector lever in P (Park)
(automatic transaxle) or 1 (First) (manual
transaxle).
*
[ST03100(ALL)01/95]
2. Set the parking brake fully.
[ST03450(ALL)12/93]
3. Push the key in (manual transaxle) and turn
it to the LOCK position.
*
[ST03500(ALL)03/95]
4. Remove the key.
*
[ST03700(ALL)06/95]
RWARNING
Always set the parking brake fully and
make sure that the gearshift is securely
latched in P (Park) (automatic transaxle) or
in 1 (First) (manual transaxle).
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

46
*
[ST03900(ALL)01/93]
RWARNING
Do not leave children, unreliable adults,
or pets alone in your vehicle. They could
accidentally injure themselves or others
through inadvertent operation of the
vehicle. Further, on hot, sunny days,
temperatures in a closed vehicle could
quickly become high enough to cause
severe and possibly fatal injuries to
people as well as animals.
*
[ST04100(ALL)03/95]
Fuel-Injected Engines
*
[ST04200(ALL)03/95]
When starting a fuel-injected engine,the most
important thing to remember is to avoid
pressing down on the accelerator before or
during starting. Only use the accelerator when
you have problems getting your vehicle started.
SeeStarting Your Enginein this chapter for
details about when to use the accelerator while
you start your vehicle.
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996
