File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

219 [SV36400(ALL)05/93]
half page art:0032218-A
Fuse panel cover
[SV36500(ALL)05/93]
one third page art:0032219-A
Fuse panel in the instrument panel
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

220 [SV36550(ALL)07/95]
thirty-four pica chart:0032232-C
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

221 [SV36575(ALL)07/95]
fourteen pica chart:0032237-C
%*
[SV36600(ALL)06/95]
Checking and Replacing Fuses
[SV36800(ALL)05/95]
1. Find the fuse panel and remove the cover.
[SV36900(ALL)05/95]
2. Find the position of the fuse you want to
check.
[SV37000(ALL)05/95]
3. To remove the fuse, use the fuse puller
provided (located on the cover of the interior
fuse panel).
*
[SV37100(ALL)05/95]
quarter page art:0030248-B
Fuse puller tool and fuse
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

222 [SV37200(ALL)05/95]4. Look through the transparent side of the
fuse to see if the metal wire inside is
separated. If it is, replace the fuse with one
of the same amperage only. You can use the
amp rating number on the fuse as well as
the color to identify the correct replacement.
*
[SV37300(ALL)05/95]
RWARNING
Always replace a fuse with one that has
the specified amperage rating. Using a
fuse with a higher amperage rating can
cause severe wire damage and could start
a fire.
[SV37350(ALL)05/95]
5. Reinstall the fuse puller on the inside of the
fuse panel cover.
[SV37400(ALL)05/95]
6. Install the fuse panel cover.
*
[SV37500(ALL)05/93]
Even after you replace a fuse, it will continue to
blow if you do not find what caused the
overload. If the fuse continues to blow, have
your electrical system checked.
*
[SV37525(ALL)03/94]
The following chart indicates the colors and
amperage ratings of standard fuses.
[SV37550(ALL)03/94]
twelve pica chart:0032119-AFile:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

223 [SV37600(ALL)05/93]
Circuit Breaker
[SV37700(ALL)05/93]
The climate control systems require high
amperage. If the rated amperage is exceeded, a
protective circuit breaker will open.
[SV37800(ALL)07/93]
If the circuit is broken by the circuit breaker,
turn all heater and air-conditioner switches off
and restore the circuit by pushing the reset
button located in the interior fuse panel. If the
circuit breaks again, have it inspected by your
dealer.
[SV37900(ALL)07/93]
one third page art:0032233-B
Reset button for circuit breaker
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

224
*
[SV38800(ALL)03/95]
Lights and Bulb Replacement
*
[SV38900(ALL)01/95]
It is a good idea to check the operation of the
following lights frequently:
*
[SV39000(ALL)01/95]
q
headlamps
[SV39050(ALL)02/95]
q
high mount brakelamp
*
[SV39100(ALL)01/95]
q
tail lamps
*
[SV39200(ALL)01/95]
q
brakelamps
*
[SV39300(ALL)01/95]
q
hazard flasher
*
[SV39400(ALL)01/95]
q
turn signals
*
[SV39500(ALL)01/95]
q
side markers
*
[SV39600(ALL)01/95]
q
license plate lamp
*
[SV39700(ALL)02/95]
q
fog lamps
*
[SV39800(ALL)01/95]
The alignment of your headlamps should be
checked if:
*
[SV39900(ALL)01/95]
q
oncoming motorists frequently signal you to
turn off your vehicle's high beams when you
do not have the high beams on
*
[SV40000(ALL)01/95]
q
the headlamps do not seem to give you
enough light to see clearly at night
*
[SV40100(ALL)01/95]
q
the headlamp beams are pointed substantially
away from a position slightly down and to
the right
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

225
*
[SV40200(ALL)03/95]
Headlamp Bulb
*
[SV40400(ALL)01/95]
The headlamps on your vehicle use replaceable
bulbs. When the lamp burns out, simply replace
the bulb, rather than the whole lamp.
*
[SV40500(ALL)05/95]
RWARNING
Handle a halogen headlamp bulb carefully
and keep out of children's reach. Grasp
the bulb only by its plastic base and do
not touch the glass. The oil from your
hand could cause the bulb to break the
next time the headlamps are operated.
*
[SV40600(ALL)01/95]
Do not remove the burned-out bulb unless you
can immediately replace it with a new one. If a
bulb is removed for an extended period of time,
contaminants may enter the headlamp housing
and affect its performance.
*
[SV40700(ALL)03/95]
Removing the headlamp bulb
*
