1996 FORD ASPIRE Owners Manual

104
*
[FV27200(ALL)03/95]
Hatchback
*
[FV27400(ALL)05/95]
Opening and Closing the Hatchback
[FV27700(ALL)11/90]
1. Put the key into the lock on the hatchback
lid.
[FV27800(ALL)04/95]
one third page art:0032198-C
Unlocking the hatchback lid with the key
[FV28000(ALL)09/93]
2. Turn the key to the right until a click is
audible and then pull up on the handle
(above the license plate) until the hatchback
lid opens.
[FV28150(ALL)09/93]
3. Remove the key before you close the
hatchback lid.
*
[FV28200(ALL)05/95]
4. Using both hands, shut the hatchback
completely. Do not slam it.
*
[FV28300(ALL)05/95]
5. Pull up on the hatchback to make sure it is
securely latched.
File:08icfvf.ex
Update:Wed Jan 24 14:51:07 1996

105 [FV28400(ALL)04/95]
one third page art:0032199-B
Lifting the hatchback lid
*
[FV28500(ALL)07/93]
To prevent premature wear or damage to the
hatchback lift cylinders and attaching hardware,
the hatchback must be fully closed before you
drive your vehicle.
*
[FV28600(ALL)05/95]
RWARNING
If you drive with the hatchback lid open,
you will draw dangerous exhaust fumes
into your vehicle.
*
[FV28610(ALL)07/95]
If you must drive like this, keep the vents open
so outside air comes into the vehicle.
File:08icfvf.ex
Update:Wed Jan 24 14:51:07 1996

106 [FV28700(ALL)07/95]Luggage compartment lamp (If equipped)
[FV28800(ALL)05/93]
The luggage compartment hatchback has a lamp
for your convenience. It has two positions, On or
Off.
[FV28900(ALL)05/93]
one third page art:0032209-B
Luggage compartment lamp
File:08icfvf.ex
Update:Wed Jan 24 14:51:07 1996

107
Electronic Sound Systems
*
[AS21330(ALL)04/95]
full page art:0060586-C
Electronic Stereo Radio
File:09icasf.ex
Update:Wed Jan 24 14:52:32 1996

108
*
[AS21360(ALL)04/95]
full page art:0060587-C
Electronic Stereo Radio with Cassette
File:09icasf.ex
Update:Wed Jan 24 14:52:32 1996

109
*
[AS21380(ALL)05/95]
Electronic Stereo and Stereo
Cassette Radios
*
[AS21400(ALL)06/95]
Using the Controls on Your New Radio
*
[AS21500(ALL)02/95]
How to turn the radio on and adjust the
volume
*
[AS21600(ALL)06/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS22050(ALL)05/95]
Press the right (+) side of the ªVOLUMEº
button to increase the volume. Press the left (s)
side of the button to decrease the volume.
Illuminated bars in the display show the relative
volume level.
*
[AS22075(ALL)07/95]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off (with the
ªPOWERº button), the volume will
remain in the position it was set at
when radio power was turned off.
*
[AS22100(ALL)06/95]
Selecting the AM or FM frequency band
*
[AS22210(ALL)07/95]
Push the ªAM/FMº button to select the desired
frequency band. Pushing the button more than
once will alternate between AM, FM1 and FM2.
These functions are used with the station
memory buttons described underHow to tune
radio stations.
*
[AS22300(ALL)05/95]
How to tune radio stations (Stereo Radio)
*
[AS22400(ALL)05/95]
There are three ways for you to tune in to a
particular station. You can manually locate the
station by using the ªTUNEº button, ªSEEKº the
station or select the station by using the memory
preset buttons, which you can set to any desired
frequency.
File:09icasf.ex
Update:Wed Jan 24 14:52:32 1996

110 %
*
[AS22450(ALL)05/95]
How to tune radio stations (Stereo Cassette
Radio)
*
[AS22475(ALL)02/95]
There are four ways for you to tune in to a
particular station. You can manually locate the
station by using Automatic Music Search
(ªAMSº), ªSEEKº the station, ªSCANº to the
station or select the station by using the memory
buttons, which you can set to any desired
frequency.
*
[AS22650(ALL)05/95]
q
Using the ªAMSº function to manually tune
your radio (Stereo Cassette Radio)
*
[AS22674(ALL)06/95]
You can change the frequency up or down
one increment at a time by first pressing the
ªAMSº button (display shows ªTUNEº) then
within approximately five seconds pressing
and releasing either the right
aor left
b
side of the ªSEEKº button. To change
frequencies quickly, press andhold down
either the right or left side of the ªSEEKº
button.
*
[AS22700(ALL)02/95]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
*
[AS22800(ALL)04/95]
q
Using the ªSEEKº function
*
[AS22900(ALL)06/95]
This feature on your radio allows you to
automatically select listenable stations up or
down the frequency band. Press the right
a
side of the ªSEEKº button to select the next
listenable station up the frequency band.
Press the left
bside of the button to select
the next listenable station down the
frequency band. By holding the button down,
listenable stations can be passed over to reach
the desired station.
File:09icasf.ex
Update:Wed Jan 24 14:52:32 1996

111
*
[AS23150(ALL)02/95]
q
Using the ªSCANº function (Stereo Cassette
Radio)
*
[AS23175(ALL)06/95]
Press the ªSCANº button to enter the scan
mode. The radio will begin scanning up the
frequency band, stopping on each listenable
station for approximately a five-second
sampling. This continues until you press the
ªSCANº button a second time.
*
[AS23200(ALL)04/95]
q
Setting the Station Memory Preset buttons
*
[AS23300(ALL)05/95]
Your radio is equipped with 5 station
memory buttons. These buttons can be used
to select up to 5 preset AM stations and 10
preset FM stations (5 in FM1 and 5 in FM2).
*
[AS23400(ALL)06/95]
Follow the easy steps below to set these buttons
to the desired frequencies:
*
[AS23500(ALL)07/95]
1. Select a band, then select a frequency.
*
[AS23700(ALL)06/95]
2. Press one of the memory preset buttons and
hold the button until the sound returns. That
station is now held in memory on that
button.
*
[AS23800(ALL)06/95]
3. Follow the two steps above for each station
memory preset button you want to set.
*
[AS23900(ALL)04/95]
NOTE: If the vehicle's battery is disconnected,
the clock and station memory preset
buttons (if programmed in auto mode)
will need to be reset.
File:09icasf.ex
Update:Wed Jan 24 14:52:32 1996
