1996 FORD ASPIRE Owners Manual

6 [IN05575(ALL)12/93]
half page art:0032235-BSafety Compliance Certification label location
*
[IN05800(ALL)05/95]
The label contains the name of the manufacturer,
the month and year of manufacture, the
certification statement and the Vehicle
Identification Number. The label also contains
Gross Vehicle Weight Rating and Gross Axle
Weight Ratings, wheel and tire data and
information codes for additional vehicle data.
For further information about the Safety
Compliance Certification Label and the
information contained on it, refer to the Index.
%*
[IN05850(ALL)06/95]
Federal Highway Administration
Regulation
*
[IN05875(ALL)06/95]
Regulations such as those issued by the Federal
Highway Administration or issued pursuant to
the Occupational Safety and Health Act (OSHA),
and/or state and local laws and regulations may
require additional equipment for the way you
intend to use the vehicle. It is the responsibility
of the registered owner to determine the
File:02icinf.ex
Update:Wed Jan 24 14:28:18 1996

7
applicability of such laws and regulations to
your intended use for the vehicle, and to
arrange for the installation of required
equipment. Your Ford dealer has information
about the availability of many items of
equipment which may be ordered for your
vehicle.
*
[IN06000(ALL)01/95]
Breaking Your Vehicle In
*
[IN06100(ALL)03/95]
Your new vehicle goes through an adjustment or
break-in period during the first 1,000 miles
(1,600 km) that you drive it. During the break-in
period, you need to pay careful attention to how
you drive your vehicle.
%*
[IN06300(ALL)01/95]
q
Avoid sudden stops.Because your vehicle
has new brake linings, you should take these
steps:
*
[IN06400(ALL)01/95]
Ð Watch traffic carefully so that you can
anticipate when to stop.
*
[IN06500(ALL)01/95]
Ð Begin braking well in advance.
*
[IN06600(ALL)01/95]
Ð Apply the brakes gradually.
*
[IN06700(ALL)01/95]
The break-in period for new brake linings
lasts for 100 miles (160 km) of city driving or
1,000 miles (1,600 km) of highway driving.
%*
[IN06800(ALL)01/95]
q
Use only the type of engine oil that Ford
recommends.SeeEngine oil recommendations
in the Index. Do not use special ªbreak-inº
oils.
File:02icinf.ex
Update:Wed Jan 24 14:28:18 1996

8
*
[IN07100(ALL)04/95]
Cleaning the Outside of Your
Vehicle
*
[IN07200(ALL)04/95]
Washing and Polishing Your Vehicle
*
[IN07300(ALL)04/95]
Wash the outside of your vehicle, including the
underside, with a mild detergent.
*
[IN07400(ALL)06/95]
DO NOT:
*
[IN07500(ALL)04/95]
q
Wash your vehicle with hot water
*
[IN07600(ALL)04/95]
q
Wash your vehicle while it sits in direct
sunlight
*
[IN07700(ALL)04/95]
q
Wash your vehicle while the body is hot
*
[IN07800(ALL)07/95]
Pollen, bird droppings and tree sap can damage
the paint, especially in hot weather. Wash your
vehicle as often as necessary to keep it clean.
*
[IN07900(ALL)07/95]
Take similar precautions if your vehicle is
exposed to chemical industrial fallout.
*
[IN08000(ALL)07/95]
Paint damage resulting from fallout is not
related to a defect in paint materials or
workmanship and therefore is not covered by
warranty. Ford, however, believes that continual
improvement in customer satisfaction is a high
priority. For this reason, Ford has authorized its
dealers to repair, at no charge to the owner, the
surfaces of new vehicles damaged by
environmental fallout within 12 months or 12,000
miles (20,000 km) of purchase, whichever comes
first. Customers may be required to bring their
vehicle in for inspection by a Ford
representative.
*
[IN08100(ALL)04/95]
Polish your vehicle to remove harmful deposits
and protect the finish.
File:02icinf.ex
Update:Wed Jan 24 14:28:18 1996

9
*
[IN08200(ALL)04/95]
Cleaning Chrome and Aluminum Parts
[IN08300(ALL)05/95]
Wash chrome and aluminum parts with a mild
detergent. Do not use steel wool, abrasive
cleaners, fuel or strong detergents.
*
[IN08400(ALL)04/95]
Cleaning Plastic Parts
*
[IN08500(ALL)04/95]
Some of your vehicle's exterior trim parts are
plastic. Clean with a tar and road oil remover if
necessary. Use a vinyl cleaner for routine
cleaning.
*
[IN08600(ALL)04/95]
Do not clean plastic parts with thinners, solvents
or petroleum-based cleaners.
%*
[IN08700(ALL)04/95]
If you have your vehicle rustproofed, remove
oversprayed rustproofing with a tar and road oil
remover. If rustproofing is not removed from
plastic and rubber parts, it can cause
deterioration.
File:02icinf.ex
Update:Wed Jan 24 14:28:18 1996

11
Safety Restraints
*
[SR00500(ALL)04/95]
Important Safety Belt Information
*
[SR00600(ALL)03/95]
The use of safety belts helps to restrain you and
your passengers in case of a collision. In most
states and in Canada the law requires their use.
*
[SR00700(ALL)01/95]
Safety belts provide best restraint when:
*
[SR00800(ALL)01/95]
q
the seatback is upright
*
[SR00900(ALL)01/95]
q
the occupant is sitting upright (not slouched)
*
[SR01000(ALL)01/95]
q
the lap belt is snug and low on the hips
*
[SR01100(ALL)01/95]
q
the shoulder belt is snug against the chest
*
[SR01200(ALL)01/95]
q
the knees are straight forward
*
[SR01350(ALL)07/95]
To help you remember to fasten your safety belt,
a warning light may come on and a chime may
sound. SeeSafety Belt Warning Light and Chimein
theWarning Lights and Gaugeschapter.
*
[SR02000(ALL)07/95]
See the following sections in this chapter for
directions on how to properly use these safety
belts. Also seeSafety Restraints for Childrenin this
chapter for special instructions about using
safety belts for children.
%*
[SR02100(ALL)05/95]
RWARNING
Make sure that you and your passengers
wear safety belts. Always drive and ride
with your seatback upright and the lap
belt snug and low across the hips.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996

12
*
[SR02200(ALL)06/95]
RWARNING
Never wear the shoulder belt under the
arm. Never swing it around the neck over
the inside shoulder. Never use a single
belt for more than one person or across
more than one seating position. Each
seating position in your vehicle has a
specific safety belt assembly which is
made up of one buckle and one tongue
that are designed to be used as a pair.
Failure to follow these precautions could
increase the risk and/or severity of injury
in a collision.
[SR02400(ALL)07/95]
RWARNING
Never drive or ride with a twisted or
jammed safety belt. If you cannot untwist
or unjam the safety belt, see the nearest
qualified technician immediately.
*
[SR02800(ALL)07/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
*
[SR02825(ALL)07/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SR02850(ALL)05/95]
Lock the doors of your vehicle before driving to
lessen the risk of the door coming open in a
collision.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996

13
*
[SR03400(ALL)05/95]
Combination Lap and Shoulder
Belts
*
[SR03500(ALL)06/95]
While your vehicle is in motion, the combination
lap and shoulder belt adjusts to your movement.
However, if you brake hard, turn hard, or if
your vehicle receives an impact of 5 mph
(8 km/h) or more, the lap/shoulder belt locks
and helps reduce your forward movement.
*
[SR03600(ALL)05/95]
After you get into your vehicle, close the door
and lock it. Then adjust the seat to the position
that suits you best.
[SR03700(ALL)07/95]
To fasten the belt, pull the combination
lap/shoulder belt from the retractor so that the
shoulder portion of the belt crosses your
shoulder and chest. Be sure the belt is not
twisted. If it is, remove the twist. Insert the belt
tongue into the proper buckle until you hear a
snap and feel it latch. Make sure the tongue is
securely fastened to the buckle by pulling on
tongue.
[SR03800(ALL)05/93]
one third page art:0032150-A
Fastening the safety belt
*
[SR03850(ALL)06/95]
Adjust the lap part of the belt by pulling up on
the shoulder belt until the lap belt fits snugly
and as low as possible around your hips.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996

14
*
[SR03860(ALL)06/95]
NOTE: Be sure to read and understand
Important Safety Belt Informationat
the beginning of this chapter.
[SR05300(ALL)07/95]
one third page art:0032252-B
Unfastening the combination lap/shoulder belts Ð front
and rear outboard seating positions
*
[SR05400(ALL)05/95]
While the belt retracts, guide the tongue to its
original position to prevent it from striking you
or the vehicle.
[SR09320(ALL)05/95]
Passenger Seat Lap/Shoulder Belt
Retractors (Dual Locking Modes)
*
[SR09330(ALL)06/95]
Your vehicle is equipped with a dual locking
mode retractor on the shoulder belt portion of
the combination lap/shoulder safety belt for all
passengers.
[SR09340(ALL)05/95]
Dual locking mode retractors operate in two
ways:
*
[SR09350(ALL)06/95]
Vehicle sensitive (emergency) locking mode
[SR09360(ALL)05/95]
In this operating mode, the shoulder belt
retractor will allow the occupant freedom of
movement, locking tight only on hard braking,
hard cornering, or impacts of approximately
5 mph (8 km/h) or more. The retractor can also
be made to lock by pulling on the belt.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996
