1996 FORD ASPIRE Owners Manual

178 [SV05600(ALL)07/95]
full page art:0032216-CThe 1.3L engine
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

179 %
*
[SV05650(ALL)07/95]
Cleaning the Engine
*
[SV05700(ALL)07/95]
A clean engine is more efficient because the
engine is able to cool properly. A build up of
grease and dirt acts as an insulator, keeping the
engine warmer than normal.
*
[SV05750(ALL)07/95]
q
Extreme care must be used if a power washer
is used to clean the engine. The high pressure
fluid could penetrate sealed parts and
assemblies causing damage or malfunctions.
*
[SV05800(ALL)07/95]
q
In order to avoid possible cracking of the
engine block or fuel injection pump, do not
spray a hot engine or injection pump with
cold water.
*
[SV05850(ALL)07/95]
q
The alternator, distributor and air intake must
be covered. Covering these components will
help prevent water damage.
*
[SV05900(ALL)07/95]
Never wash or rinse the engine while it is
running. Water getting into the engine may
cause internal damage.
%
*
[SV06100(ALL)03/95]
Filling the Fuel Tank
[SV06400(ALL)05/93]
Your fuel hatch door is located on the driver's
side. To open the fuel door, simply pull the
hatch open.
[SV06500(ALL)07/95]
one third page art:0032224-B
Fuel hatch and fuel cap
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

180
*
[SV07540(ALL)07/95]
If you lose the fuel cap, replace it with an
authorized Motorcraft or equivalent part.
%*
[SV07550(ALL)05/95]
RWARNING
If you do not use the proper fuel cap, the
pressure in the fuel tank can damage the
fuel system or cause it to work improperly
in a collision.
*
[SV07560(ALL)05/95]
NOTE: If you replace your fuel cap with an
aftermarket fuel filler cap, the customer
warranty may be void for any damage
to the fuel tank and/or fuel system.
*
[SV07575(ALL)05/95]
RWARNING
If the fuel cap is venting vapor or if you
hear a hissing sound, wait until it stops
before completely removing the cap.
*
[SV07576(ALL)05/95]
NOTE: If you replace your fuel cap with an
aftermarket fuel filler cap, the customer
warranty may be void for any damage
to the fuel tank and/or fuel system.
*
[SV07577(ALL)05/95]
A venting fuel tank is not an abnormal
condition. It may be caused by:
*
[SV07578(ALL)05/95]
q
too volatile a fuel for the weather conditions.
Service stations sometimes sell winter grade
fuel in the summer.
*
[SV07579(ALL)05/95]
q
extended periods of idling with the engine
RPM increased above the normal idle range.
*
[SV07580(ALL)05/95]
q
parking the vehicle in full sunlight for
extended periods on extremely hot days.
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

181 [SV07590(ALL)05/95]
RWARNING
Do not overfill the fuel tank. The pressure
in an overfilled tank may cause leakage
and lead to fuel spray and fire.
*
[SV07595(ALL)05/95]
Before you fill your vehicle with fuel, extinguish
all lit cigarettes, other smoking materials, and
any open flames.
*
[SV07600(ALL)05/95]
To fill the tank properly:
*
[SV07610(ALL)05/95]
1. Remove the fuel cap. Proceed to add fuel to
the tank only if your vehicle is on level
ground.
[SV07620(ALL)05/95]
2. Make sure that you pump unleaded fuel and
put the nozzle all the way inside the fuel
filler pipe. The fuel tank is normally full
after three automatic shutoffs of the nozzle.
[SV07630(ALL)05/95]
3. If you spill any fuel on the body of your
vehicle, clean it off immediately. The fuel
may dull or soften the paint if you do not
wash it off.
[SV07640(ALL)05/95]
4. Replace the fuel cap tightly when you are
finished. Turn it clockwise until you hear at
least three clicks.
*
[SV07650(ALL)05/95]
5. Push the fuel door closed.
*
[SV07670(ALL)06/95]
Choosing the Right Fuel
*
[SV07680(ALL)06/95]
Use only UNLEADED FUEL in your vehicle.
Using leaded fuel is prohibited by federal law.
Your warranty may not apply if your vehicle is
damaged because you used the wrong fuel.
*
[SV07690(ALL)06/95]
Vehicle inspection programs may detect
misfueling. Under these circumstances, you may
be required by law to make costly repairs at
your own expense.
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

182 %
*
[SV08750(ALL)04/95]
Octane recommendations
*
[SV08800(ALL)06/95]
Your vehicle is designed to use regular
unleaded fuel with an octane rating of 87.At
service stations, the octane rating is displayed in
a label on the pumps.
*
[SV08900(ALL)06/95]
one inch art:0060001-C
Typical octane rating label
*
[SV08950(ALL)07/95]
In some parts of the country, ªregularº grade
fuels are sold with octane ratings of 86 or even
less, especially in high altitude areas. We
recommend that you do not use these fuels.
Always use a fuel with an octane rating of 87,
even if it is sold as a ªmidgradeº or ªpremium.º
%*
[SV09200(ALL)06/95]
Do not be concerned if your vehicle sometimes
knocks lightly when you drive up a hill or when
you accelerate. However, see your dealer or a
qualified service technician if persistent, heavy
knocking occurs because this can damage the
engine.
%*
[SV09250(ALL)05/95]
Fuel quality
*
[SV09475(ALL)06/95]
If you are experiencing starting, rough idle or
hesitation problems when the engine is cold, it
may be caused by fuel with low volatility. Try a
different brand of fuel. If the condition persists,
see your dealer or a qualified service technician.
*
[SV09477(ALL)06/95]
Using a high-quality fuel makes your vehicle
more responsive and maintains its good fuel
economy and emissions by:
*
[SV09479(ALL)06/95]
q
protecting your fuel system from rusting.
*
[SV09481(ALL)06/95]
q
preventing the fuel lines from freezing.
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

183
*
[SV09485(ALL)06/95]
q
protecting the fuel system from vapor lock in
very hot weather, which causes the engine to
hesitate or stall and makes restarts difficult.
*
[SV09487(ALL)06/95]
q
minimizing deposits in fuel injectors,
combustion chambers, and on intake valves.
[SV09489(ALL)04/95]
q
preventing your fuel system from ªgumming
upº when your vehicle is not used for long
periods of time.
*
[SV09491(ALL)06/95]
q
preventing your engine from knocking and
pinging.
*
[SV09495(ALL)06/95]
It should not be necessary to add any
aftermarket products to your fuel tank if you
continue to use a high-quality fuel.
*
[SV09600(ALL)04/95]
Gasolines for clean air
*
[SV09900(ALL)06/95]
Fuels in certain areas of the country are required
to contain oxygenates to improve air quality.
Common oxygenates are ethanol or grain alcohol
(blended at no more than 10%), methanol or
wood alcohol (blended at no more than 5% with
cosolvents and additives), and MTBE or methyl
tertiary butyl ether (blended at no more than
15%).
*
[SV09950(ALL)06/95]
Reformulated fuel is also required in certain
areas of the U.S. These fuels are designed to
further reduce the emissions from your vehicle.
*
[SV10000(ALL)06/95]
Generally, you should not experience difficulties
operating your vehicle on fuels containing
oxygenates. We encourage you to use these
fuels.
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

184
*
[SV10185(ALL)06/95]
Safety Information Relating to Automotive
Fuels
*
[SV10195(ALL)05/95]
RWARNING
Automotive fuels can cause serious injury
or death if misused or mishandled.
*
[SV10200(ALL)07/95]
q
Turn vehicle off when refueling
*
[SV10210(ALL)07/95]
q
Do not smoke when refueling. Fuels are
extremely flammable.
*
[SV10220(ALL)07/95]
q
Do not siphon any fuel by mouth.
*
[SV10230(ALL)07/95]
RWARNING
Gasoline or gasoline blended with
methanol can cause blindness and
possible death when swallowed. If any
fuel is swallowed, call a physician or
poison control center immediately.
*
[SV10240(ALL)07/95]
q
Avoid breathing vapors while refueling.
*
[SV10250(ALL)07/95]
q
If fuel is splashed on the skin, wash with
soap and water.
*
[SV10260(ALL)07/95]
q
If fuel is splashed in the eyes, remove contact
lenses (if worn), flush with water for 15
minutes, and seek medical attention.
*
[SV10270(ALL)07/95]
Gasoline and gasoline blends may contain small
amounts of carcinogens, such as benzene.
Long-term exposure to unleaded gasoline vapors
has caused cancer in laboratory animals.
*
[SV10280(ALL)07/95]
If you are taking the medication ªAntabuseº or
other forms of disulfiram for the treatment of
alcoholism, vapor or skin contact with a
gasoline-methanol blend may cause the same
kind of adverse reaction as drinking an alcoholic
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

185
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
%*
[SV11300(ALL)05/95]
Running Out of Fuel
*
[SV11310(ALL)07/95]
NOTE: Avoid running out of fuel because this
situation may have an adverse effect on
modern powertrain components.
*
[SV11320(ALL)07/95]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
%*
[SV11600(ALL)05/95]
Fuel Economy
*
[SV11700(ALL)06/95]
Fuel economy is an estimate of the efficiency of
your vehicle and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
*
[SV11800(ALL)05/95]
To calculate fuel economy:
*
[SV11900(ALL)06/95]
1. Fill the tank completely and record the
initial odometer reading.
*
[SV12000(ALL)06/95]
2. Every time you buy fuel record the
amount (in gallons or liters) purchased.
*
[SV12150(ALL)07/95]
3. After at least three to five tankfuls, fill the
fuel tank and record the final odometer
reading.
[SV12200(ALL)07/95]
4. Divide the total number of miles that you
have driven by the total number of gallons
that your vehicle has used. In metric,
multiply the number of liters used by 100
and divide the answer by the number of
kilometers traveled. This will give you the
number of liters used per 100 km.
