1996 FORD ASPIRE Owners Manual

170 [AC01700(ALL)05/93]
thirty-six pica chart:0032277-A
File:14icacf.ex
Update:Wed Jan 24 14:53:58 1996

171 [AC01800(ALL)05/93]
thirty-six pica chart:0032278-A
File:14icacf.ex
Update:Wed Jan 24 14:53:58 1996

172 [AC01900(ALL)05/93]
thirty-six pica chart:0032279-A
File:14icacf.ex
Update:Wed Jan 24 14:53:58 1996

173
Servicing Your Aspire
*
[SV00300(ALL)03/95]
Service Made Easy
*
[SV00400(ALL)01/95]
Ford has two goals for servicing your vehicle.
*
[SV00500(ALL)01/95]
1. When we can, we design parts that do not
need to be serviced.
*
[SV00600(ALL)01/95]
2. We want to make servicing your vehicle as
easy as possible. To help you:
*
[SV00700(ALL)01/95]
q
We highlight do-it-yourself items in yellow in
the engine compartment so that you can find
them easily.
*
[SV00800(ALL)01/95]
q
When possible, we design parts Ð such as
the headlamp bulbs Ð that can be replaced
without tools.
*
[SV00900(ALL)05/94]
q
We give you a Maintenance Schedule that
makes tracking routine service for your
vehicle easy. The maintenance schedule is
located in theMaintenance Schedule and Record
booklet.
*
[SV00925(ALL)01/95]
This chapter tells you about the basic parts that
you need to check and service regularly.
[SV00930(ALL)02/95]
If your vehicle needs professional servicing, your
dealership can provide the parts and service
required. Check yourWarranty Information Booklet
to find out which parts and services are covered.
Also see theCustomer Assistancechapter of this
Owner Guide.
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

174
*
[SV01000(ALL)03/95]
Ford Motor Company recommends that the
Owner Maintenance Checks listed in the
Maintenance Schedule and Recordbooklet be
performed for the proper operation of your
vehicle. In addition to the conditions listed in
theOwner Maintenance Checklist, be alert for any
unusual noise, vibration, or other indication that
your vehicle may need service. If you do notice
something unusual, see that your vehicle is
serviced promptly.
*
[SV01100(ALL)09/93]
Use only recommended fuels, lubricants, fluids,
and service parts that meet Ford Motor
Company specifications. Motorcraft parts are
designed and built to provide the best
performance in your vehicle. Using these parts
for replacement is your assurance that Ford-built
quality stays in your vehicle.
[SV01200(ALL)05/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[SV01600(ALL)06/95]
Precautions When Servicing Your
Vehicle
*
[SV01700(ALL)06/95]
Be especially careful when inspecting or
servicing your vehicle. Here are some general
precautions for your safety:
%*
[SV01800(ALL)03/95]
q
Do not work on a hot engine. The engine
cooling fan may come on unexpectedly.
Always turn the engine off and let it cool.
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

175
*
[SV01850(ALL)05/95]
RWARNING
The cooling fan is automatic and may
come on at any time. Always disconnect
the negative terminal of the battery before
working near the fan.
*
[SV01900(ALL)06/95]
q
If you must work with the engine running,
avoid wearing loose clothing or jewelry that
could get caught in moving parts. Take
appropriate precautions with long hair.
*
[SV02000(ALL)06/95]
q
Do not work on a vehicle in an enclosed
space with the engine running, unless you are
sure you have enough ventilation.
*
[SV02100(ALL)06/95]
q
Never get under a vehicle while it is
supported by a jack only. If you must work
under a vehicle, use safety stands.
*
[SV02200(ALL)06/95]
q
Keep all lit cigarettes and other smoking
materials away from the battery and all
fuel-related parts.
*
[SV02700(ALL)03/95]
Working with the engine off:
[SV02750(ALL)02/95]
1. Set the parking brake fully and make sure
the gearshift is securely latched in P (Park)
(automatic transaxle) or 1 (First) gear
(manual transaxle).
*
[SV02800(ALL)06/95]
2. Remove the key from the ignition after you
turn the engine off.
*
[SV02850(ALL)06/95]
3. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

176
*
[SV02900(ALL)03/95]
Working with the engine on:
*
[SV03000(ALL)03/95]
1. Set the parking brake fully and make sure
the gearshift is securely latched in P (Park)
(automatic transaxle) or Neutral (manual
transaxle).
*
[SV03050(ALL)03/95]
2. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[SV03200(ALL)02/95]
RWARNING
Do not start your engine with the air
cleaner removed and do not remove it
while the engine is running.
*
[SV03400(ALL)03/95]
Opening the Hood
%*
[SV03500(ALL)01/95]
1. Inside the vehicle, pull the hood release
handle located under the bottom left corner
of the instrument panel.
%*
[SV03600(ALL)02/95]
2. Go to the front of the vehicle and release the
auxiliary latch that is located under the hood
at the center of the vehicle.
[SV03700(ALL)03/93]
3. Lift the hood and set the prop rod in the
hole in the hood.
*
[SV03800(ALL)11/90]
When you close the hood, make sure the prop
rod is in its retainer and that the hood latches
securely.
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

177 [SV04200(ALL)07/93]
half page art:0032215-B
Hood release handle, hood latch and prop rod
[SV04500(ALL)05/93]
Your Engine Type
[SV05200(ALL)09/93]
Your vehicle has a 1.3L (81 CID), fuel injected,
overhead cam, four-cylinder engine.
[SV05300(ALL)02/92]
The following page shows you a diagram of the
engine and where to find items you should
regularly service.
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996
