1996 FORD ASPIRE Owners Manual

137
Roadside Emergencies
*
[RE00400(ALL)03/95]
Jump-Starting Your Vehicle
[RE00600(ALL)09/93]
Your vehicle's battery may become discharged
(ªdieº) if you leave the lights or any electrical
equipment on after you turn the engine off. If
this happens, you may be able to jump-start
from a booster battery to start your vehicle.
*
[RE00700(ALL)02/95]
RWARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
*
[RE00800(ALL)02/95]
RWARNING
To protect yourself when charging a
battery, always shield your face and eyes.
Make sure that you can breathe fresh air.
%*
[RE00900(ALL)06/95]
RWARNING
Applying too much pressure on the ends
when lifting a battery could cause acid to
spill. Lift the battery with a carrier or
with your hands on the opposite corners.
%*
[RE01000(ALL)05/95]
RWARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
File:12icref.ex
Update:Wed Jan 24 14:52:09 1996

138
*
[RE01010(ALL)07/95]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[RE01100(ALL)06/95]
RWARNING
Do not push-start your vehicle. You could
damage the catalytic converter. For further
information, seeJumper Cablesin the
Index.
*
[RE01200(ALL)03/95]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to
jump-start and connecting the jumper cables in
the order they are given. If in doubt, call for
road service.
*
[RE01300(ALL)03/95]
Preparing Your Vehicle
*
[RE01400(ALL)03/95]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[RE01500(ALL)03/95]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[RE01600(ALL)04/95]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
File:12icref.ex
Update:Wed Jan 24 14:52:09 1996

139
*
[RE01700(ALL)03/95]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
*
[RE01800(ALL)03/95]
5. Turn on the heater fan in both vehicles.
Press the DEFROST button. Turn off all
other switches and gauges.
%*
[RE01900(ALL)05/95]
Connecting the jumper cables
*
[RE02000(ALL)03/95]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
*
[RE02100(ALL)04/95]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
*
[RE02200(ALL)07/95]
3. Connect one end of the second cable to the
negative (S) terminal of the booster battery
Ð NOT to the discharged battery.
*
[RE02300(ALL)03/95]
4. Connect the other end of that cable to a
good metallic surface on the engine or frame
of the disabled vehicle. The following
illustration shows where you can find a
metallic surface.
*
[RE02400(ALL)07/95]
RWARNING
Do not connect the end of the second
cable to the negative (S) terminal of the
battery to be jumped. A spark may cause
an explosion of the gases that surround
the battery.
File:12icref.ex
Update:Wed Jan 24 14:52:09 1996

140 [RE02700(ALL)05/95]
half page art:0032203-DThe sequence for connecting the jumper cables
*
[RE02800(ALL)03/95]
Jump-Starting
*
[RE02900(ALL)03/95]
1. Make sure that the jumper cables are not in
the way of moving engine parts, then start
the booster vehicle. Run the engine at a
moderate speed.
*
[RE03000(ALL)03/95]
2. Let the discharged battery charge for a few
minutes and then start the disabled vehicle.
It may take a couple of tries before the
vehicle starts. If the vehicle does not start
after several attempts, there may be a
different problem.
*
[RE03100(ALL)03/95]
3. When both vehicles are running, let them
idle for a few minutes to charge the
discharged battery.
File:12icref.ex
Update:Wed Jan 24 14:52:09 1996

141
*
[RE03200(ALL)03/95]
Removing jumper cables
*
[RE03300(ALL)03/95]
1.Always remove the jumper cables in the
reverse order.Remove the negative (S) end
of the jumper cable from the metallic surface
on the engine or frame of the disabled
vehicle.
*
[RE03400(ALL)06/95]
2. Remove the negative (S) cable from the
booster battery.
*
[RE03500(ALL)06/95]
3. Remove the positive (+) cable from the
booster battery.
*
[RE03600(ALL)05/95]
4. Remove the other end of the positive (+)
cable from the discharged battery.
*
[RE03700(ALL)10/95]
After the vehicle is started, let it idle for a while
to let the engine ªrelearnº its idle conditions.
Drive it around for a while with all electrical
accessories turned off to let the battery recharge.
Driveability may be deteriorated slightly until all
drive modes are ªrelearned.ºYou may need to
use a battery charger to fully recharge the
battery.
[RE03750(ALL)02/95]
If you need to replace your battery, seeBattery
in theServicing Your Vehiclechapter.
*
[RE03800(ALL)03/95]
Changing a Tire
*
[RE03900(ALL)01/95]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
File:12icref.ex
Update:Wed Jan 24 14:52:09 1996

142
*
[RE04000(ALL)03/95]
The Temporary Spare Tire
*
[RE04100(ALL)03/95]
You may have a high pressure temporary spare
tire. This spare tire is smaller than a regular tire
and is designed for emergency use only. Use it
only when you get a flat tire and replace it as
soon as you can. This spare tire is marked with
the words ªTEMPORARY USE ONLYº so that
you can easily identify it.
*
[RE04200(ALL)01/93]
RWARNING
If you use the temporary spare tire
continuously or do not follow these
precautions, the tire could fail, causing
you to lose control of the vehicle, possibly
injuring yourself or others.
*
[RE04300(ALL)01/95]
When you drive with the temporary spare tire,
DO NOT:
*
[RE04400(ALL)01/95]
q
exceed 50 mph (80 km/h) under any
circumstances.
*
[RE04500(ALL)01/95]
q
load your vehicle so that it is heavier than
the maximum vehicle load rating listed on
the tire decal.
*
[RE04700(ALL)01/95]
q
use tire chains on this tire.
*
[RE04800(ALL)01/95]
q
try to repair the temporary spare tire or
remove it from its wheel.
*
[RE04900(ALL)01/95]
q
use the wheel for any other type of vehicle.
*
[RE05000(ALL)01/95]
q
drive through an automatic car wash with
this tire. Because the temporary spare tire is
smaller than a conventional tire, it reduces
the ground clearance. Your vehicle may get
caught in the rails and it could be damaged.
File:12icref.ex
Update:Wed Jan 24 14:52:09 1996

143
*
[RE05100(ALL)03/95]
Spare Tire Location
[RE05600(ALL)02/95]
The spare tire and tools are stored in the rear
luggage compartment, under the carpet and
floorboard.
[RE05700(ALL)07/93]
half page art:0032236-B
The location of the temporary spare tire and jacking
equipment
[RE07500(ALL)07/93]
one third page art:0030145-C
The tool kit in the spare tire compartment
File:12icref.ex
Update:Wed Jan 24 14:52:09 1996

144
*
[RE07600(ALL)03/95]
Preparing to Change the Tire
*
[RE07700(ALL)02/92]
1. Make sure that your vehicle will not move
or roll. If you have an automatic transaxle,
put the gearshift in P (Park). If you have a
manual transaxle, put the gearshift in 1
(First). Set the parking brake and block the
wheel that is diagonally opposite the tire
that you are changing.
[RE08000(ALL)02/89]
half page art:0030148-A
Blocking the wheel diagonally opposite the tire being
changed
*
[RE08090(ALL)07/95]
When one of the front wheels is off the ground,
the transaxle alone will not prevent the vehicle
from moving or slipping off the jack, even if the
vehicle is in P (Park) or 1 (First). To prevent the
vehicle from moving when you change one of
the front tires, put a block behind the wheel that
is diagonally opposite to the tire.
