Page 3769 of 4087

LEXUS SC300 1991 Service Repair Manual
A/C COMPRESSOR OIL APPLICATIONSPage 1 of 1
Care must be taken to use only refrigerant oil which is compatible to the vehicles system.
Following are A/C oil application charts for both R±12 and HFC

Page 3770 of 4087

LEXUS SC300 1991 Service Repair Manual
DATE:JULY 19, 1996
Title1992 - 1995 SC 300/400 A/C CONTROL ASSEMBLY SERVICE PARTSPage 1 of 6
To allow repairs to the A/C Control Assembly, service parts are now available. The following
information

Page 3771 of 4087

LEXUS SC300 1991 Service Repair Manual
TROUBLE SHOOTING:
Use the matrix chart below as a guide to repairs. Verify necessary inputs to the A/C Control Assembly from
the vehicle prior to disassembly. Use the repair manual, A/C system sect

Page 3772 of 4087

LEXUS SC300 1991 Service Repair Manual
1992 - 1995 SC 300/400 A/C CONTROL ASSEMBLY SERVICE PARTSPage 3 of 6
AIR CONDITIONING CONTROL DISASSEMBLY (Contd):
b. Remove 2 screws and release the 6 clips to separate the Control Panel from the

Page 3773 of 4087

LEXUS SC300 1991 Service Repair Manual
1992 - 1995 SC 300/400 A/C CONTROL ASSEMBLY SERVICE PARTSPage 4 of 6
INSPECTION PROCEDURE:
1. Bulb Circuit: �
Bulb Inspection ± Perform the following test
on suspect Night Illumination Bulbs. Chec

Page 3774 of 4087

LEXUS SC300 1991 Service Repair Manual
1992 - 1995 SC 300/400 A/C CONTROL ASSEMBLY SERVICE PARTSPage 5 of 6
INSPECTION PROCEDURE (Contd):
3. Indicator Lamp Circuit: �Connect two 1.5 v dry cell
batteries in series. Using the
table, che

Page 3775 of 4087

LEXUS SC300 1991 Service Repair Manual
1992 - 1995 SC 300/400 A/C CONTROL ASSEMBLY SERVICE PARTSPage 6 of 6
MODEL
YEAR
Control Panel
Control Switch
Bulb
PART NUMBER INFORMATION:
PART NAME PART NUMBER MODEL APPLICATION QTY 55902-24010 `92-

Page 3776 of 4087

LEXUS SC300 1991 Service Repair Manual
TSIB
IntroductionA musty odor may be emitted from the air conditioning system of some vehicles which are
usually operated in areas with high temperature and humidity. It is most noticeable when
the a

TSIB
IntroductionA musty odor may be emitted from the air conditioning system of some vehicles which are
usually operated in areas with high temperature and humidity. It is most noticeable when
the air conditioner is first turned ªONº after the vehicle has bee\
n parked for several hours.
The odor could result from one or more of the following conditions:
1. Blockage of the evaporator housing drain pipe, resulting in the build up of cond\
ensation.
2. Microbial growth in the evaporator, arising from dampness in the evaporator housing
where the cooling air flow is dehumidified.
To address excessive air conditioning evaporator odor, check the evaporator housing drain
pipe for blockage. If no problems are found, the evaporator and housing\
should be cleaned
and disinfected using the general procedure given on page 2, and the model \
specific
procedure on the pages indicated in the Table of Contents at the bottom of this page.
Affected While this procedure may be used on any Lexus vehicle, this bulletin giv\
es details
Vehicles specifically for the '92±'96 ES 300, all GS 300, '93±'94 LS 400, all SC 300/400 and the\
LX 450.
Tools &
PART NUMBER DESCRIPTION OF TOOLS & MATERIALS QUANTITY SOURCE
Materials08821±00810±01 Spray Gun Kit 1 OTC 08821±00811±01 Spray Gun (replacement) (1) OTC
08821±00812±01 Spray Gun Nozzle (replacement) (1) OTC
08821±00813±01 Freshener Mixing Container (replacement) (1) OTC
08821±00801±DS Air Conditioning Freshener 1 per vehicle TMS
CAUTION:
Wear safety glasses, protective mask, and gloves while working with the
freshener.
Warranty
OPCODE DESCRIPTION TIME OPN T1 T2
Information
N/A No applicable warranty information ± ± ± ±
Table ofMODEL PAGE MODEL PAGE MODEL PAGE MODEL PAGE
Contents
ES 300 3 GS 300 5 LS 400 7
GENERAL 2
SC 300 9 SC 400 9 LX 450 11
General Procedure applies to all models and model years.
The Specific Model Sections cover only the listed ªaffected models.º
HEATING & AIR CONDITIONING
September 12, 1997
Title:
AIR CONDITIONING EVAPORATOR ODOR
Models:
'92±96 ES 300, '93±'94 LS 400,
All GS 300, SC 300/400, LX 450.
Page 1 of 11
AC001±97
