2023 TOYOTA VENZA HYBRID Owners Manual

811-5. Theft deterrent system
1
For safety and security
■Items to check before lock-
ing the vehicle
To prevent unexpected trigger-
ing of the alarm and vehicle
theft, make sure of the following:
 Nobody is in the vehicle.
 The side windows are closed
before the alarm is set.
 No valuables or other per-
sonal items are left in the
vehicle.
■Setting
Close the doors, hood, and lock
all the doors. The system will be
set automatically after 30 sec-
onds.
The security indicator changes from being on to flashing when
the system is set.
If all doors are closed with hood
open, alarm system can be set.
■Canceling or stopping
Do one of the following to deac-
tivate or stop the alarm:
 Unlock the doors using the
entry function or wireless
remote control.
 Turn the power switch to ACC
or ON, or start the hybrid sys-
tem. (The alarm will be deacti-
vated or stopped after a few
seconds.)
■System maintenance
The vehicle has a maintenance-free
type alarm system.
■Triggering of the alarm
The alarm may be triggered in the
following situations:
(Stopping the alarm deactivates the
alarm system.)
The doors are unlocked using the
mechanical key.
Alarm
The alarm uses light and
sound to give an alert when
an intrusion is detected.
The alarm is triggered in the
following situations when
the alarm is set:
 A locked door is unlocked or
opened in any way other
than using the entry func-
tion or wireless remote con-
trol. (The doors will lock
again automatically.)
 The hood is opened.
Setting/canceling/stop-
ping the alarm system

821-5. Theft deterrent system
If a door is unlocked using the
mechanical key while the alarm is
set, a warning will sound intermit-
tently for approximately 10 seconds.
If the alarm is not canceled or
stopped during this time, the warn-
ing pattern change s and the warn-
ing sounds for a certain period of
time.
●A person inside the vehicle opens
a door or hood, or unlocks the
vehicle using an inside lock but-
ton.
●The 12-volt battery is recharged or
replaced when the vehicle is
locked. ( P.468)
■Alarm-operated door lock
In the following cases, depending
on the situation, th e door may auto-
matically lock to p revent improper
entry into the vehicle:
●When a person remaining in the
vehicle unlocks the door and the
alarm is activated.
●While the alarm i s activated, a
person remaining in the vehicle
unlocks the door.
●When recharging or replacing the
12-volt battery.
NOTICE
■To ensure the system oper-
ates correctly
Do not modify or remove the sys-
tem. If modified or removed, the
proper operation of the system
cannot be guaranteed.

83
2
2
Vehicle status information and indicators
Vehicle status informa-tion and indicators
2-1. Instrument cluster
Warning lights and indica-tors ............................... 84
Gauges and meters (Vehi- cles with 7-inch multi-infor-
mation display) ............. 90
Gauges and meters (Vehi- cles with 12.3-inch multi-
information display) ...... 94
Multi-information display (7- inch multi-information dis-
play) .......................... 100
Multi-information display (12.3-inch multi-informa-
tion display) ............... 111
Head-up display .......... 123
Energy monitor/consump- tion screen................. 128

842-1. Instrument cluster
2-1.Instrument cluster
For the purpose of explanation, the following illustrations display all
warning lights and indicators illuminated.
■Vehicles with 7-inch multi-information display
The units used on the meters and some indicators may differ dep ending on
the target region.
Warning lights and indicators
The warning lights and indicators on the instrument cluster,
overhead console panel and outside rear view mirrors inform
the driver of the status of the vehicle’s various systems.
Instrument cluster

852-1. Instrument cluster
2
Vehicle status information and indicators
■Vehicles with 12.3-inch multi-information display
Type 1
The units used on the meters and some indicators may differ depending on
the target region.
Type 2
The units used on the meters and some indicators may differ dep ending on
the target region.

862-1. Instrument cluster
Type 3
The units used on the meters and some indicators may differ depending on
the target region.
Warning lights inform the driver
of malfunctions in the indicated
vehicle’s systems.
Warning lights
(U.S.A.)
Brake system warning
light
*1 (  P.441)
(Canada)
(Red)
Brake system warning
light
*1 ( P.441)
(Yellow)
Brake system warning
light
*1 ( P.441)
Charging system warning
light
*2 (  P.441)
High coolant temperature
warning light
*2 (  P.442)
Low engine oil pressure
warning light
*2 (  P.442)
(U.S.A.)
Malfunction indicator
lamp
*1 ( P.442)
(Canada)
Malfunction indicator
lamp
*1 ( P.442)
SRS warning light
*1
(  P.442)
(U.S.A.)
ABS warning light*1
(  P.443)
(Canada)
ABS warning light*1
(  P.443)
(Red)
Electric power steering
system warning light
*1
(  P.443)
(Yellow)
Electric power steering
system warning light
*1
(  P.443)

872-1. Instrument cluster
2
Vehicle status information and indicators
*1: These lights turn on when the
power switch is turned to ON to
indicate that a system check is
being performed. They will turn
off after the hybrid system is on,
or after a few seconds. There
may be a malfunction in a sys-
tem if the light does not come on,
or turn off. Have the vehicle
inspected by your Toyota dealer.
*2: This light illuminates on the multi-information display with a
message.
*3: Intuitive parking assist OFF indi-cator turns on wh en the power
switch is turned t o ON while the
Intuitive parking assist function is
on. It will turn off after a few sec-
onds.
(Flashes or illumi- nates)
PCS warning light*1
(  P.443)
(Orange)
LTA indicator ( P.444)
Intuitive parking assist
OFF indicator
*3 (if
equipped) ( P.444)
PKSB OFF indicator
*1 (if
equipped) ( P.444)
RCTA OFF indicator
*1
(  P.445)
Slip indicator light
*1
(  P.445)
Inappropriate pedal opera-
tion warning light
*2
(  P.445)
(Flashes)
Brake hold operated indi-
cator
*1 ( P.446)
(U.S.A.)
(Flashes)
Parking brake indicator
(  P.446)
(Canada)
(Flashes)
Parking brake indicator
( P.446)
Tire pressure warning
light
*1 (  P.446)
Low fuel level warning
light ( P.446)
Driver’s and front passen-
ger’s seat belt reminder
light ( P.447)
Rear passengers’
seat belt reminder
light (P.447)
WARNING
■If a safety system warning
light does not come on
Should a safety system light such
as the ABS and SRS warning light
not come on when you start the
hybrid system, this could mean
that these system s are not avail-
able to help protect you in an acci-
dent, which could result in death
or serious injury. Have the vehicle
inspected by your Toyota dealer
immediately if this occurs.

882-1. Instrument cluster
The indicators inform the driver
of the operating state of the
vehicle’s various systems.
Indicators
Turn signal indicator
( P.212)
(U.S.A.)
Headlight indicator
( P.219)
(Canada)
Tail light indicator
( P.219)
Headlight high beam indi-
cator ( P.221)
Automatic High Beam indi-
cator ( P.222)
Fog light indicator (if
equipped) ( P.225)
Smart key system indica-
tor
*1 (  P.201)
Cruise control indicator
(  P.265)
Dynamic radar cruise con-
trol indicator ( P.265)
Cruise control “SET” indi-
cator ( P.265)
(White)
LTA indicator*2 ( P.256)
(Green)
LTA indicator*2 ( P.239,
256)
(Orange)
(Flashes)LTA indicator*2 (  P.256)
Intuitive parking assist
OFF indicator
*3, 4 (if
equipped) ( P.288)
PKSB OFF indicator
*3, 5 ( i f
equipped) ( P.296)
(Flashes)
Slip indicator light*5
(  P.306)
VSC OFF indicator
*3, 5
(  P.307)
PCS warning light
*3, 5
(  P.239)
BSM outside rear view
mirror indicators
*5, 6
(  P.278)
BSM OFF indicator
*3, 5
(  P.278)
RCTA OFF indicator
*3, 5
(  P.278)
Brake hold standby indica-
tor
*5 (  P.217)
Brake hold operated indi-
cator
*5 (  P.217)
Security indicator
*7
(  P.80, 81)
“READY” indicator
(  P.201)
Low outside temperature
indicator
*8 (  P.98, 91)
EV indicator ( P.71)
(U.S.A.)
Parking brake indicator
( P.213)
(Canada)
Parking brake indicator
( P.213)
