2020 TOYOTA PRIUS PRIME Owners Manual (in English)

PRIUS PRIME_OM_OM47C77U_(U)
2173. Instrument cluster
3
Instrument cluster
■Switching the driving mode ( P. 419)
*: The animation displayed when the driving mode is switched can be turned
off in the “Meter Customize” settings. ( P. 246)
When the driving mode is switched, the
driving mode indicator changes and an
animation
* is displayed on the multi-infor-
mation display.
Also, the background color of the main
display, energy monitor ( P. 221) and
Hybrid System Indicator ( P. 223)
change as follows.
Driving modesBackground color
Normal mode Green
Power modeRed
Eco drive modeBlue

218
PRIUS PRIME_OM_OM47C77U_(U)
3. Instrument cluster
Multi-infor mation display
Information related to each icon
on the upper portion of the multi-
information display can be dis-
played by operating the meter
control switches to select the icon.
Icons are displayed when pressing or of the meter control
switches and turn off shortly after
pressing the switch.
Screens linked with vehicle functions may be automatically disp layed
according to the operation status of the corresponding function s.
A variety of information related to the vehicle can be displayed,
including the operation status of each system and data related
to Eco driving, and the settings of each system can be changed
according to user preference.
Display contents

PRIUS PRIME_OM_OM47C77U_(U)
2193. Instrument cluster
3
Instrument cluster
*: When there is a warning message that can be displayed, the color of
changes to amber.
Menu iconsContentsPages
Drive information The energy monitor that shows the operation
status of the hybrid system, or other informa-
tion such as electricity consumption and fuel
consumption are displayed. P. 220
Clock setting display The clock settings can be changed. P. 237
Navigation system-linked display (if
equipped)
The information related to the navigation sys-
tem is displayed.
P. 238
Audio system-linked displayThe audio system settings can be changed.P. 238
Air conditioning system settings screen
The air conditioning system settings can be
changed.
P. 239
Driving assist system informationThe information related to driving assist sys-
tems such as the LDA (Lane Departure Alert
with steering control) and dynamic radar
cruise control with full-speed range is dis-
played.
P. 243
Warning message display*
The warning messages are displayed.P. 243
Settings displayThe settings of the vehicle functions, meter
display, etc. can be changed.
P. 244

220
PRIUS PRIME_OM_OM47C77U_(U)
3. Instrument cluster
Press or of the meter control switches and select the icon
of the desired item.
The selected icon is highlighted and the display switches to the information
screen.
When split screen display is selected for the main display, the sub-screen
of the main display can also be selected. ( P. 214)
Press or of the meter control switches to switch the con-
tents of the display.
Press on screens where it
is necessary to select or con-
firm an item.
On screens with tab displays,
pressing selects the tab dis-
play, and the screen display can be
changed by pressing or of
the meter control switches.
Press to return to the previous screen.
When is selected, the following information can be displayed by
pressing or of the meter control switches.
● Energy monitor ( P. 221)
● Hybrid System Indicator ( P. 223)
● “Fuel Consumption Record” ( P. 2 3 1 )
● “Drive Monitor” ( P. 2 3 4 )
● “Drive Monitor 2” ( P. 235)
● “Eco-Diary” ( P. 236)
Basic Operations
1
2
Tab display
P
Drive information
4

PRIUS PRIME_OM_OM47C77U_(U)
2213. Instrument cluster
3
Instrument cluster
◆Energy monitor
The energy monitor can be used to check the vehicle drive status,
hybrid system operation status and energy regeneration status.
While charging from the external power source, the flow of electrical
energy while charging is displayed.
When energy is flowing, an arrow appears and a bright point of light
moves to show the direction of the flow of energy. When energy is
not flowing, the bright point of light is not displayed.
● The arrows from the image of the engine to that of the electric
motor (traction motor) or ti res are displayed in red.
● The arrow indicating energy consumption is displayed in yellow,
and the arrow indicating energy regeneration or charging is dis -
played in green. Also, the color around the image of the hybrid
battery (traction battery) is changed.
As an example, all arrows are shown in the illustration, but th e actual
contents of the display will differ.
■
Except when charging
Gasoline engine
Electric motor
(traction motor)
Air conditioning system oper-
ation
*1
Hybrid battery
(traction battery)
Tire
Bright point of light showing the flow of energy
(Display example)
● When the hybrid battery (traction battery) is being charged, th e
bright point of li ght moves towards .
● During driving, the bright point of light moves from or (or
both depending on the s ituation) towards .
*2
●When the air conditioning compres sor is operating, a bright point
of light moves from to .
● During driving, the image of the tires rotates.
*1: It is displayed while the air c onditioning system is operating .
*2: The display may differ depending on the driving status.
1
2
3
4
5
6
4
12
5
43

222
PRIUS PRIME_OM_OM47C77U_(U)
3. Instrument cluster
■While chargingHybrid battery (traction bat-
tery)
Charging connector
(Display example)
When the hybrid battery (tracti on battery) is being charged, a bright
point of light moves from to .
■ When the charging connector is locked (vehicles with smart lid & con-
nector locking system) ( P. 148)
1
2
is displayed in the charging connector
display portion on the energy monitor.
21

PRIUS PRIME_OM_OM47C77U_(U)
2233. Instrument cluster
3
Instrument cluster
◆Hybrid System Indicator
The display changes according to accelerator pedal operation and
displays the current driving st atus and energy regeneration sta tus.
The display contents of the Hybrid System Indicator are differe nt in EV
mode and HV mode.
The Hybrid System Indicator can be displayed on the sub-screen of the
main display ( P. 215) and the head-up display (if equipped)
( P. 252).
■
How to read the display
In EV mode
Charge area
Shows that energy is being recovered via the regenerative charging.
EV driving area
Shows that the vehicle is driven using only the electric motor (traction
motor).
Gasoline engine running area
Shows that the gasoline engine is used as auxiliary power.
Eco area
Shows that the vehicle is being driven in an Eco-friendly manne r.
Changed within the “ECO Accelerator Guidance” range. ( P. 226)
*1
Head-up display
(if equipped)
Sub-screen
Multi-information
display
1
2
3
4

224
PRIUS PRIME_OM_OM47C77U_(U)
3. Instrument cluster
EV indicator*1, 2
The EV indicator comes on when the vehicle is driven using only the
electric motor (traction motor) or the gasoline engine is stopped.
Hybrid battery (traction battery) status
P. 229
Eco score
P. 227
EV driving range
P. 252
● By keeping the indicator within Eco area, more Eco-friendly dri v-
ing can be achieved.
● Charge area indicates regeneration
*3 status. Regenerated
energy will be used to charge the hybrid battery (traction battery).
*1: Not displayed on the sub-screen or head-up display.
*2: The EV indicator function can be turned off in the “Meter Cust omize”
settings. ( P. 246)
*3: When used in this manual, “regeneration” refers to the conversion of
energy created by the movement of the vehicle into electrical e nergy.
5
6
7
8
