2018 PEUGEOT EXPERT Owners Manual

39
Key
The key allows the central locking or unlocking
of the vehicle using the door lock.
It also allows the fuel filler cap to be removed
and refitted and the engine started or switched
of f.
Key, remote control
The remote control buttons are not active
when the ignition is switched on.
Unfolding/Folding the key
If you do not press the button, you risk
damaging the remote control.
What is the purpose of total
or selective unlocking?
F Press this button to unfold or fold the key.Selective unlocking unlocks either the cab

doors, or the doors of the loading area (side
and rear). Total unlocking unlocks all
the vehicle’s doors
(front, side and rear).
The separated unlocking system between
cab and loading area is a security
measure.
It is used to close access to the part of the
vehicle in which you are not.
It allows the central locking or unlocking of the
vehicle using the door lock or from a distance. It also allows the vehicle to be located, the fuel
filler cap to be removed and refitted and the
engine to be started or switched off, as well as
providing protection against theft.
2
Access

40
Unlocking is confirmed by rapid flashing
of the direction indicators for around two
seconds.
At the same time, depending on your
version, the door mirrors unfold.
Programming
By default, selectivity between cab and
loading area is activated.
Total unlocking
Cab and loading area selectivity
disabled.
Using the key
F To fully unlock the vehicle, turn the key to
the front of the vehicle.
F

T
hen pull the handle to open the door.
If your vehicle is so equipped, the alarm is not
deactivated. The opening of a door will trigger
the alarm that will be stopped when ignition is
switched on.
Using the remote control
F To activate this selectivity between cab and loading area ,
switch the ignition on and press
this button for more than two
seconds.
Its indicator lamp comes on.
An audible signal sounds and, depending on
the equipment, a message confirms that the
request has been applied. F

P
ress one of these buttons
(depending on the equipment) to
unlock the vehicle.Using the remote control with
electric sliding side door(s)
F To fully unlock the vehicle without
opening the side door, press this
button.
F
To fully unlock the
vehicle and open the side
door, press and hold this
button until the door has
opened.
F

T

o deactivate this selectivity
and return to total unlocking,
switch the ignition on and press
this button for more than two
seconds.
Its indicator lamp goes off.
Access

41
Selective unlocking
Using the remote control
F To unlock just the cab doors,
press this button once .
If your vehicle is so equipped:
Using the remote control with
electric sliding side door(s)
F To unlock the loading area
alone without opening the side
door, press this button.
F

T
o unlock the loading
area alone and open
the side door, press and
hold this button until the
door has opened.
Unlocking is confirmed by rapid flashing
of the direction indicators for around two
seconds.
At the same time, depending on your
version, the door mirrors unfold.
Unlocking
Using the key
Using the remote control
F To unlock the vehicle, press this button.
F

T

o unlock the vehicle, turn the key to the
front of the vehicle.
F

T

hen pull the handle to open the door.
If your vehicle is so equipped, the alarm is not
deactivated. The opening of a door will
trigger the alarm that will be stopped when the
ignition is switched on.
Cab
and loading area selectivity
activated.
F

P

ress this button to unlock the
loading area alone .
F

T

o unlock the loading area
opening elements (side and
rear), press this button again .
2
Access

42
Locking
Using the key
F To lock the vehicle totally, turn the key to
the rear of the vehicle.
If your vehicle has an alarm, this will not be
activated.
Using the remote control
F To lock the vehicle totally , press
this button.
Ensure that no person or object could
prevent the correct closing of the windows.
Be particularly aware of children when
operating the windows.
If a door is not properly closed
(except the right-hand door with side-
hinged rear doors):
-

w
ith the vehicle stationary and
the engine running, this warning
lamp comes on, accompanied
by an alert message for a few
seconds,
-

w
ith the vehicle moving (speed
above 6
mph (10 km/h)), this
warning lamp comes on,
accompanied by an audible
signal and an alert message for a
few seconds. Driving with the doors locked could make
it difficult for the emergency ser vices to
enter the vehicle in an emergency.
As a safety measure (children on board),
never leave the vehicle without your
remote control with you, even for a short
period.
Using the remote control with
electric sliding side door(s)
F To unlock the vehicle
and open the side door,
press and hold this
button until the door has
opened.
Unlocking is confirmed by rapid flashing
of the direction indicators for around two
seconds.
At the same time, depending on your
version, the door mirrors unfold. If your vehicle is not fitted with an
alarm, locking is signalled by the fixed
illumination of the direction indicators for
about two seconds.
At the same time, depending on your
version, the door mirrors fold.
If one of the opening elements (doors or
tailgate) is still open, the central locking
does not take place.
When the vehicle is locked, if it is
unlocked inadvertently, it will lock itself
again automatically after about thirty
seconds unless a door is opened.
And if your vehicle has an alarm, this will
be reactivated (with volumetric monitoring,
even if this had been deactivated).
The automatic folding and unfolding of the
electric door mirrors can be deactivated
by a PEUGEOT dealer or a qualified
workshop.
Access

43
To deadlock the vehicle:
F T urn the key to the rear of the vehicle.
F
Then within five seconds , turn the key to
the rear again.
Using the remote control
To lock the vehicle:
At the same time, depending on your
version, the door mirrors fold.
To deadlock the vehicle:
If your vehicle is not fitted with an alarm,
deadlocking is signalled by the fixed
illumination of the direction indicators for
about two seconds.
Ensure that no person or object could
prevent the correct closing of the windows.
Be particularly aware of children when
operating the windows.
Locating your vehicle
This function allows you to identify your vehicle
from a distance, particularly in poor light. Your
vehicle must be locked for more than five
seconds.
Remote operation of
lighting
If fitted to your vehicle. A short press on this button switches
on the lighting remotely (sidelamps,
dipped beam headlamps and number
plate lamps).
Using the key
A second press on this button before
the end of the timed period cancels
the remote lighting.
F

P

ress this button.
F

Then
within five seconds after
locking , press this button again. F
P
ress this button.
This will switch on the courtesy lamps and the
direction indicators will flash for around ten
seconds.
Deadlocking
Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
control button.
Therefore, never leave anyone inside the
vehicle when it is deadlocked.
2
Access

44
Anti-theft protection
Electronic engine immobiliser
The remote control contains an electronic chip
which has a secret code. When the ignition is
switched on, this code must be recognised in
order for starting to be possible.
A few seconds after switching off the ignition,
this system locks the engine control system,
therefore preventing the engine from being
started in the event of a break-in.In the event of a fault, you are
informed by illumination of this
warning lamp, an audible signal and
a message in the screen.
The vehicle will not start; contact a PEUGEOT
dealer as soon as possible.
B a c k- u p c o nt r o l (s)
Locking the driver's door
F Insert the key in the door lock, then turn it to the rear.
Unlocking
F Insert the key in the door lock, then turn it to the front. If your vehicle has an alarm, it will not be
deactivated/activated on unlocking/locking
the vehicle.
Opening a door will trigger the alarm,
which can be stopped by switching the
ignition on.
Locking the front
passenger door
F Open the door.
F

R
emove the cap on the edge of the door.
F

I
nsert the key into the latch aperture
(without forcing) and turn the assembly.
F

R
emove the key and refit the cap.
F

C
lose the door and check from the outside
that it has locked correctly.
For mechanically locking and unlocking the
doors in the event of a fault with the central
locking system or a battery failure.
Access

45
Unlocking
Use the interior door handle.
Locking the sliding side
door
F If fitted to your vehicle, check that the electric child lock is not on.
F

O
pen the door.
F

R
emove the cap on the edge of the door.
F

I
nsert the key into the latch aperture
(without forcing) and turn the assembly.
F

R
emove the key and refit the cap.
F

C
lose the door and check from the outside
that it has locked correctly.
Unlocking
F Use the interior door handle.
For more information on the Child lock ,
refer to the corresponding section.
Locking the side-hinged
doors
F If fitted to your vehicle, check that the electric child lock is not on.
F

O
pen the left-hand side-hinged door.
Unlocking
F Use the interior door handle.
Remote control problem
Following disconnection of the vehicle battery,
replacement of the remote control battery or
in the event of a remote control malfunction,
you can no longer unlock, lock or locate your
vehicle.
F

F
irst of all, use the key in the door lock to
unlock or lock your vehicle.
F

T
hen reinitialise the remote control.
If the problem persists, contact a PEUGEOT
dealer as soon as possible.
Reinitialisation
F Lock the driver's door using the key.
F
P
ress one of the remote control
buttons.
F

I

nsert the key into the latch aperture on the
edge of the door (without forcing) and slide
the assembly upward.
F

R

emove the key.
F

C

lose the door and check from the outside
that it has locked correctly.
2
Access

46
F Turn the key to position 2 (Ignition on).
F S witch the ignition off and remove the key
from the switch.
Changing the battery
Battery ref.: CR1620 / 3 volts.
I f the battery is flat, you will be
informed by lighting of this warning
lamp in the instrument panel, an
audible signal and a message in the
screen.
The remote control is now fully operational
again.
Do not throw the remote control
batteries away, they contain metals
which are harmful to the environment.
Take them to an approved collection
point.
F

U
nclip the cover using a small screwdriver
at the cut-out.
F
L
ift off the cover.
F
R
emove the flat battery from its
compartment.
F
F
it the new battery into its compartment
observing the original fitting direction.
F
C
lip the cover onto the casing.
Keyless Entry and
Starting
Remote control
It allows the central locking or unlocking of the
vehicle from a distance.
It is also used to locate and start the vehicle, as
well as providing protection against theft.
What is the purpose of total
or selective unlocking?
Total unlocking unlocks all
the vehicle’s doors
(front, side and rear).
Access
