2018 PEUGEOT EXPERT Owners Manual

55
With a tailgate
If the system is fitted to your
vehicle, pressing and holding
the locking controls closes the
windows. If you release the
button, the window will stop.
Ensure that no person or object could
prevent the correct closing of the windows.
Be particularly aware of children when
operating the windows.
F

T

o lock the vehicle, with the remote control
in the recognition zone A , press the tailgate
locking control.
With electric sliding side door(s)
F To totally lock the vehicle, with the remote
control in the recognition zone A , press with
a finger or thumb at the markings on one of
the front door handles.
With side-hinged doors
F To lock the vehicle, with the remote control in the recognition zone A , press the left-
hand door locking control. If your vehicle is not fitted with an
alarm, locking is signalled by the fixed
illumination of the direction indicators for
about two seconds.
Depending on your version, the door
mirrors fold at the same time.
Driving with the doors locked could make
it difficult for the emergency ser vices to
enter the vehicle in an emergency.
Deadlocking
Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
locking button.
Therefore, never leave anyone inside the
vehicle when it is deadlocked.
2
Access

56
F To totally lock the vehicle, with the remote
control in the recognition zone A , press
with a finger or thumb at the markings on
one of the front or manual sliding side door
handles.
F

T
o deadlock the vehicle, press the marking
again within five seconds.
With electric sliding side door(s)
F To totally lock the vehicle, with the remote
control in the recognition zone A , press with
a finger or thumb at the markings on one of
the front door handles.
F

T
o deadlock the vehicle, press the marking
again within five seconds .
With side-hinged doors
F To lock the vehicle, with the remote control
in the recognition zone A , press the left-
hand door locking control.
F

T
o deadlock the vehicle, press the control
again within five seconds .
With a tailgate
If your vehicle is not fitted with an alarm,
deadlocking is confirmed by fixed
illumination of the direction indicators for
about two seconds.
F

T
o lock the vehicle, with the remote control
in the recognition zone A , press the tailgate
locking control.
F

T
o deadlock the vehicle, press the control
again within five seconds .
Access

57
In the event of a fault, you are
informed by illumination of this
warning lamp, an audible signal and
a message in the screen.
The vehicle will not start; contact a PEUGEOT
dealer as soon as possible.
Anti-theft protection
Electronic engine immobiliser
The remote control contains an electronic chip
which has a secret code. When the ignition is
switched on, this code must be recognised in
order for starting to be possible.
A few seconds after switching off the ignition,
this system locks the engine control system,
therefore preventing the engine from being
started in the event of a break-in.
Locating your vehicle
This function allows you to identify your vehicle
from a distance, particularly in poor light. Your
vehicle must have been locked for more than
five seconds.
Remote operation of
lighting
If fitted to your vehicle. A short press on this button switches
on the lighting remotely (sidelamps,
dipped beam headlamps and number
plate lamps).
A second press on this button before
the end of the timed period cancels
the remote lighting. F
P
ress this button.
This will switch on the courtesy lamps and the
direction indicators will flash for around ten
seconds.
B a c k- u p c o nt r o l (s)
Integral key
It is used to lock and unlock the vehicle when
the remote control cannot operate:
-
c
ell battery flat, vehicle battery discharged
or disconnected, etc.
-

v
ehicle located in an area with strong
electromagnetic signals.
If the alarm is activated, the audible signal
triggered on opening a door with the key
(integral with the remote control) will stop
when the ignition is switched on.
F

H
old button 1 pulled to extract the integral
key 2 .
2
Access

58
Locking the driver's door
F Insert the integral key in the door lock, then turn it to the rear.
Unlocking
F Insert the integral key in the door lock, then turn it to the front.
If your vehicle has an alarm, it will not be
deactivated/activated on unlocking/locking
the vehicle.
Opening a door will trigger the alarm,
which can be stopped by switching the
ignition on.
To deadlock the vehicle, turn the key again
within five seconds of locking.
Locking the front passenger door
F Open the door.
F

R
emove the cap on the edge of the door.
F

I
nsert the key into the latch aperture
(without forcing) and turn the assembly.
F

R
emove the key and refit the cap.
F

C
lose the door and check from the outside
that it has locked correctly.
Unlocking
F Use the interior door handle.
Locking the sliding side door
F If fitted to your vehicle, check that the electric child lock is not on.
F

O
pen the door.
F

R
emove the cap on the edge of the door.
F

I
nsert the key into the latch aperture
(without forcing) and turn the assembly.
F

R
emove the key and refit the cap.
F

C
lose the door and check from the outside
that it has locked correctly.
Unlocking
F Use the interior door handle.
Access

59
Remote control problem
Following disconnection of the vehicle battery,
replacement of the remote control battery or
in the event of a remote control malfunction,
you can no longer unlock, lock or locate your
vehicle.
F
F
irst, use the integral key in the door lock to
unlock or lock your vehicle.
F

T
hen reinitialise the remote control.
Reinitialisation
F Unlock the driver's door using the integral key.
F

P
lace the integral key in the lock to unlock
your vehicle. F

P
ress one of the remote control
buttons.
Locking the side-hinged doors
F If fitted to your vehicle, check that the electric child lock is not on.
F

O
pen the left-hand side-hinged door.
Unlocking
F Use the interior door handle.F
I
nsert the key (without forcing) into the latch
aperture located on the edge of the door
and slide the assembly upward.
F
R
emove the key.
F
C
lose the door and check from the outside
that it has locked correctly.
For more information on the Child lock ,
refer to the corresponding section. If the problem persists, contact a
PEUGEOT dealer or a qualified workshop
as soon as possible.
F
P
lace the remote control against the reader.
F
K
eep it into place and switch the ignition on,
pressing "START/STOP".
The remote control is now fully operational
again.
2
Access

60
Changing the battery
Battery type: CR2032 / 3 volts.
T his replacement battery is available from a
PEUGEOT dealer or a qualified workshop.
A message is displayed in the instrument panel
screen when replacement of the battery is
needed.
Do not throw the remote control
batteries away, they contain metals
which are harmful to the environment.
Take them to an approved collection
point.
F

U
nclip the cover using a small screwdriver
at the cut-out.
F

R
emove the cover.
F

R
emove the dead battery from its
compartment.
F

F
it the new battery into its compartment
observing the original fitting direction.
F

C
lip the cover onto the casing. Lost keys, remote control
Go to a PEUGEOT dealer, taking with you the
vehicle's registration certificate, your personal
identification documents and if possible, the
label bearing the key code.
The PEUGEOT dealer will be able to retrieve
the key code and the transponder code
required to order a new key.
Remote control
The high frequency remote control is a
sensitive system; do not operate it while it is
in your pocket as there is a possibility that
it may unlock the vehicle, without you being
aware of it.
Do not repeatedly press the buttons of your
remote control out of range and out of sight
of your vehicle. You may stop it from working
and the remote control would have to be
reinitialised.
The remote control does not operate when
the key is in the ignition, even when the
ignition is switched off.
Locking the vehicle
Driving with the doors locked may make
access to the passenger compartment by
the emergency ser vices more difficult in an
emergency.
As a safety precaution (with children on
board), remove the key from the ignition or
take the remote control with you when leaving
the vehicle, even for a short time.Electrical interference
The
K eyless Entry and Starting remote
control may not operate if close to certain
electronic devices: telephone, laptop
computer, strong magnetic fields, etc.
Anti-theft protection
Do not make any modifications to the
electronic engine immobiliser system; this
could cause malfunctions.
Do not forget to turn the steering to engage
the steering lock.
When purchasing a second-hand vehicle
Have the key codes memorised by a
PEUGEOT dealer, to ensure that the keys in
your possession are the only ones which can
start the vehicle.
Access

61
Accumulations (water, dust, grime, salt,
etc.) on the inner sur face of the door
handle may affect detection.
If cleaning the inner sur face of the door
handle using a cloth does not restore
detection, contact a PEUGEOT dealer or a
qualified workshop.
A sudden splash of water (stream of water,
high pressure jet washer, etc.) may be
identified by the system as the desire to
open the vehicle.Locking/unlocking from
inside
Locking the vehicle
This button is inoperative if the vehicle
has been locked or deadlocked from
outside (using the key, remote control or
Keyless Entry and Starting, depending
on equipment) or if one of the opening
elements is still open.
Automatic
The cab doors lock automatically while driving
(speed above 6 mph (10 km/h)); the indicator
lamp comes on.
F

T
o activate or deactivate this
function, with the ignition on,
press this button until a message
appears in the screen.
Manual
The indicator lamp comes on to confirm the
locking.
When carrying long objects with the
tailgate or rear doors open, you can press
this button to lock just the cab doors.
When locking from inside, the door mirrors
do not fold.
Driving with the doors locked could make
it difficult for the emergency ser vices to
enter the vehicle in an emergency.
If the vehicle is deadlocked or locked with
the remote control or the door handles,
the button is not operational. Then, use
the key or remote control to unlock. F

P
ress this button.
2
Access

62
F Press this button.
The indicator lamp also goes off when
unlocking one or more doors.
Locking/unlocking the
loading area
This button is unavailable if the vehicle
has been locked or deadlocked from
outside (using the key, remote control or
Keyless Entry and Starting, depending
on equipment) or if one of the opening
elements is still open.
Unlocking the vehicle
The indicator lamp goes off to confirm the
unlocking.
Automatic
Manual
Cab and loading area selectivity
disabled.
F

W
ith the vehicle unlocked, press
this button.
F

W
ith the vehicle locked, press
this button.
Cab and loading area selectivity
enabled.
F

W
ith the loading area unlocked,
press this button.
The loading area
is always locked when
driving.
The indicator lamp comes on to confirm the
vehicle i s locked.
The indicator lamp goes off to confirm the
vehicle is unlocked.
The indicator lamp comes on to confirm that
the loading area is locked. F

W
ith the loading area locked,
press this button.
Driving with the doors locked could make
it difficult for the emergency ser vices to
enter the vehicle in an emergency.
The indicator lamp also goes off when
unlocking one or more opening elements
of the loading area .
For energy efficiency purposes, with the
ignition off and vehicle fully locked, the
indicator lamp goes off.
For more information on the Key, Remote
control or

K
eyless Entr y and Star ting,
and in particular programming the
selective locking of the loading area, refer
to the corresponding section.
The indicator lamp goes off to confirm that the
loading area
is unlocked.
To deactivate the automatic locking
function, go to a PEUGEOT dealer or a
qualified workshop.
Access
