2017 TOYOTA HIGHLANDER HYBRID Owners Manual

4416-1. Using the air conditioning system and defogger
6
Interior features
HIGHLANDER_HV_U (OM48F12U)■
Adjusting the temperature setting
To adjust the temperature setting, press
“∧” on to increase
the temperature and
“∨” to decrease the temperature.
■Fan speed setting
To adjust the fan speed, press “ ∧” on to increase the fan
speed and
“∨” to decrease the fan speed.
Press to turn the fan off.
Rear automatic air conditioning system
Air outlets and fan speed are automatically adjusted according
to the temperature setting.
Air conditioning controls

4426-1. Using the air conditioning system and defogger
HIGHLANDER_HV_U (OM48F12U)■
Changing airflow modes
To change the airflow mode,
press .
The air outlets used are
switched each time the button is
pressed.
Air flows to the upper body.
Air flows to the upper body
and feet.
Air flows to the feet.
Press .
Adjust the temperature setting.
To stop the operation, press .
■Automatic mode indicator
If the fan speed setting or air fl ow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.
1
2
3
Using automatic mode
1
2
3

4436-1. Using the air conditioning system and defogger
6
Interior features
HIGHLANDER_HV_U (OM48F12U)■
Location of air outlets
The air outlets and air volume
change according to the
selected airflow mode.
■Adjusting the position of and opening and closing the air out-
lets
Direct air flow to the left or right,
forward or backward.
Closes the vent
Slide the knob to the rear-most
position.
Opens the vent
Air outlets
1
2
NOTICE
■To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessary when the
hybrid system is off.

4446-1. Using the air conditioning system and defogger
HIGHLANDER_HV_U (OM48F12U)
Heated steering wheel∗/seat heaters∗/seat
ventilators
∗
∗: If equipped
The heated steering wheel and seat heaters heat the side grips
of the steering wheel and seats, respectively. Seat ventilators
maintain good airflow by blowing air from the seats.
WARNING
● Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel and seats when the heater is on\
:
• Babies, small children, the elderly, the sick and the physically chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold remedies, etc.)
● Observe the following precautions to prevent minor burns or overheating
• Do not cover the seat with a blanket or cushion when using the seat heater.
• Do not use the seat heaters more than necessary.
NOTICE
● Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.
● To prevent 12-volt battery discharge, do not use the functions when the
hybrid system is off.

4456-1. Using the air conditioning system and defogger
6
Interior features
HIGHLANDER_HV_U (OM48F12U)
Turn the heated steering wheel
on/off
The indicator light comes on when
the heated steering wheel is oper-
ating.
The heated steering wheel will
automatically turn off after about 30
minutes.
■The heated steering wheel can be used when
The power switch is in ON mode.
■
Seat heaters
Turns the seat heater on
The indicator light comes on.
Adjusts the seat temperature
The further you move the dial
forward, the warmer the seat
becomes.
■
Seat heaters/ventilators Turns the seat heater on
The indicator light comes on.
The higher the number is, the
warmer the seat becomes.
Blows air from the seat
The indicator light comes on.
The higher the number is, the
stronger the airflow becomes.
Heated steering wheel
Front seat heaters and ventilators
1
2
1
2

4466-1. Using the air conditioning system and defogger
HIGHLANDER_HV_U (OM48F12U)
■The seat heaters and seat heaters/ventilators can be used when
The power switch is in ON mode.
■ When not in use
Seat heaters
Turn the dial fully backward. The indicator light will turn off.
Seat heaters/ventilators
Set the knob at “0”. The indicator light will turn off.
Hi
Lo
Off
The indicator comes on when the
second seat heater is on.
■ The second seat heaters can be used when
The power switch is in ON mode.
Second seat heaters
1
2
3

447
6
Interior features
HIGHLANDER_HV_U (OM48F12U)
6-2. Using the interior lights
Rear interior/rear personal lights (→P. 448)
Ambient lights (if equipped)
Front interior/front personal lights ( →P. 448)
Outer foot lights (if equipped)
Power switch light
Front door courtesy lights
Interior li ghts list
1
2
3
4
5
6

4486-2. Using the interior lights
HIGHLANDER_HV_U (OM48F12U)
Turns the lights on/off
Turns the lights linked to door
position on/off
Turn the light on/off
Interior lights
1
2
Personal lights
FrontRear
