Page 537 of 676
5377-3. Do-it-yourself maintenance
7
Maintenance and care
IS200t_EE(OM53D77E)
Turn the bulb base counterclock-
wise.
Remove the light bulb.
Install a new light bulb then install
the bulb base to the light unit by
inserting it and turning the bulb
base clockwise.
When inserting the socket, align the
marks printed on the light body and
the socket.
5
6
7
Page 538 of 676
5387-3. Do-it-yourself maintenance
IS200t_EE(OM53D77E)
Install the visor cover on the mir-
ror frame, secure it with a screw,
and install the side turn signal light
and outer foot light.
Use only the screw position shown in
the illustration.
Align the tabs on the side turn signal
light unit and the cover and install it.
Interlock the groove of the outer foot
light unit with the tabs on the cover
and secure it.
After installing the outer foot light
unit, turn on the outer foot light to
visually check that there is no light
leaking from the bulb base.
Disconnect the tabs, and sepa-
rate the top and bottom of the
outer cover of the mirror.
8
9
Page 539 of 676
5397-3. Do-it-yourself maintenance
7
Maintenance and care
IS200t_EE(OM53D77E)
Install the outer cover of the mir-
ror by installing the lower side
first, then installing the upper side.
When installing the lower side of the
cover, insert the side turn signal light
pin into the hole in the cover.
Secure the cover with screws and
reconnect the connectors back
together.
Secure the wire harness by reinstall-
ing it to the hooks on the back side of
the mirror surface as it was.
Align the tabs, and secure the
mirror by pushing in each diago-
nally-opposite pair of tabs in
order.
Make sure to insert the tabs in order
as shown in the illustration, and push
them in until a click is heard.
If you do not hear the click, do not
force the tabs in. Instead, remove the
mirror and check that the tabs are
aligned.
After securing the mirror, remove the
protective tape applied to the lower
part of the mirror cover.
10
11
12
Page 540 of 676

5407-3. Do-it-yourself maintenance
IS200t_EE(OM53D77E)
■Replacing the following bulbs
If any of the lights listed below has burnt out, have it replaced by any autho-
rized Lexus retailer or Lexus authorized repairer, or any reliable repairer.
●Headlights
●Front position lights and daytime running lights
●Front turn signal lights (LED type)
●Side turn signal lights
●Stop/tail lights
●Tail lights
●Back-up light
●Rear turn signal lights
●Rear fog light
●High mounted stoplight
●License plate lights
■LED Lights
The lights other than the front turn signal lights (bulb type) and outer foot lights each con-
sist of a number of LEDs. If any of the LEDs burn out, take your vehicle to any authorized
Lexus retailer or Lexus authorized repairer, or any reliable repairer to have the light
replaced.
■Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the headlight lens does not indicate a
malfunction. Contact any authorized Lexus reta iler or Lexus authorized repairer, or any
reliable repairer for more information in the following situations:
●Large drops of water ha ve built up on the inside of the lens.
●Water has built up inside the headlight.
■When replacing the front turn signal lights (bulb type)
When the washer fluid filler op ening is removed with a large amount of washer fluid con-
tained in the washer tank, washer fluid may spill onto the vehicle and cleaning may be
required.
■When replacing light bulbs
P. 533
Page 541 of 676

5417-3. Do-it-yourself maintenance
7
Maintenance and care
IS200t_EE(OM53D77E)
WARNING
■Replacing light bulbs
●Turn off the lights. Do not attempt to replace the bulb immediately after turning off the
lights.
The bulbs become very hot and may cause burns.
●Do not touch the glass portion of the light bulb with bare hands. When it is unavoid-
able to hold the glass portion, use and hold with a clean dry cloth to avoid getting
moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.
●Fully install light bulbs and any parts used to secure them. Failure to do so may result
in heat damage, fire, or wate r entering the headlight unit. This may damage the head-
lights or cause condensation to build up on the lens.
■To prevent damage or fire
●Make sure bulbs are fully seated and locked.
●Check the wattage of the bulb before installing to prevent heat damage.
NOTICE
■When replacing the outer foot lights
If the front window is stopping you from conducting the replace operation properly,
open the window on the side you are working on to allow you enough space to work.
Continuing the operation without giving yourself enough space to work could lead you
to scratch the vehicle.
Page 542 of 676
5427-3. Do-it-yourself maintenance
IS200t_EE(OM53D77E)
Page 543 of 676

543
8When trouble arises
IS200t_EE(OM53D77E)
8-1. Essential informationEmergency flashers ..................544
If your vehicle has to be stopped in an
emergency .................................545 8-2. Steps to take
in an emergency
If your vehicle needs to be towed................................ 546
If you think something is wrong....................................... 552
Fuel pump shut off system ......553
If a warning light turns on or a warning buzzer
sounds..........................................554
If a warning message is displayed ................................560
If you have a flat tire (vehicles with emergency
tire puncture repair kit) ........586
If you have a flat tire (vehicles with a
spare tire) .................................... 601
If the engine will not start ......... 613
If the electronic key does not operate properly .............. 615
If the vehicle battery is discharged.............................. 618
If your vehicle overheats ......... 622
If the vehicle becomes stuck ............................................. 626
Page 544 of 676
544
IS200t_EE(OM53D77E)8-1. Essential information
Press the switch.
All the turn signals will flash.
To turn them off, press the switch once
again.
■Emergency flashers
If the emergency flashers are used for a long
time while the engine is not operating, the
battery may discharge.
Emergency flashers
The emergency flashers are used to wa rn other drivers when the vehicle has
to be stopped in the road due to a breakdown, etc.
