2017 INFINITI QX30 Owner's Manual

2017 Infiniti QX30
Printing: November 2016 (02) / OM17E0 0H15U1 / Printed in U.S.A.
For your safety, read carefully and keep in this vehicle.2017 Infiniti QX30
Owner’s Manual and
Maintenance Information

Owner’s Manual Supplement
The information contained within this supplement revises “Checking tire pressure”
information in the “Do–it–yourself” section of the 2017 INFINITI QX30 Owner’s
Manual and Maintenance Information.Read carefully and keep in vehicle
Printing: September 2016 (01)
Publication No. SU17E0 0H15U0

CHECKING TIRE PRESSURE
1. Remove the valve stem cap from the tire.
2. Press the pressure gauge squarely onto thevalve stem. Do not press too hard or force
the valve stem sideways, or air will escape. If
the hissing sound of air escaping from the
tire is heard while checking the pressure,
reposition the gauge to eliminate this leak-
age.
3. Remove the gauge. 4. Read the tire pressure on the gauge stem
and compare it to the specification shown
on the Tire and Loading Information label.
5. Add air to the tire as needed. If too much air is added, press the core of the valve stem
briefly with the tip of the gauge stem to
release pressure. Recheck the pressure and
add or release air as needed.
6. Install the valve stem cap.
7. Check the pressure of all other tires, includ- ing the spare.
Tire Size Cold Tire Inflation Pressure
Front Rear
235/
50R18 (2WD)
35psi
(240kPa) 35psi
(240kPa)
(4WD/
AWD) 35psi
(240kPa) 29psi
(200kPa)
235/45R19 32psi
(220kPa) 32psi
(220kPa)
Spare Tire NONELDI0393

Owner’s Manual Supplement
The information contained within this supplement updates the following
information in the 2017 and 2018 INFINITI QX30 Owner’s Manual
In “ CHILD SAFETY REAR DOOR LOCK"in the “Pre-driving checks and
adjustments” section of the Owner’s Manual.
Read carefully and keep in vehicle.
Printing: March 2018
Publication No. SU18E0 0H15U0

The child safety rear door locks help prevent
doors from being opened accidentally, espe-
cially when small children are in the vehicle.
When the switch (lever) is in the LOCK
2
position, the child safety rear door can only
be opened from the outside door handles.
To disengage, move the switch (lever) to the
unlock position
1.
LSU2010
CHILD SAFETY REAR DOOR LOCK

Your INFINITI represents a new way of thinking about vehicle design. It integrates advanced engineering and superior craftsmanship with a simple,
refined aesthetic sensitivity associated with traditional Japanese culture.
The result is a different notion of luxury and beauty. The car itself is important, but so is the sense of harmony that the vehicle evokes in its driver,
and the sense of satisfaction you feel with the INFINITI — from the way it looks and drives to the high level of retailer service.
To ensure that you enjoy your INFINITI to the fullest, we encourage you to read this Owner’s Manual immediately. It explains all of the features, controls
and performance characteristics of your INFINITI; it also provides important instructions and safety information.
A separate Warranty Information Booklet is included in your Owner’s literature portfolio. Always carry it with you when you take your vehicle to an
INFINITI retailer. The Warranty Information Booklet contents provide complete information about all warranties covering this vehicle, the requirements
to keep the warranties in effect as well as the INFINITI Roadside Assistance Program.
Additionally, a separate Customer Care and Lemon Law Information Booklet will explain how to resolve any concerns you may have with your vehicle,
as well as clarify your rights under your state’s lemon law.
In addition to factory-installed options, your vehicle may also be equipped with additional accessories prior to delivery. It is recommended that you
visit an INFINITI retailer for this service. It is important that you familiarize yourself with all disclosures, warnings, cautions and instructions concerning
proper use of such accessories prior to operating the vehicle and/or accessory. It is recommended that you visit an INFINITI retailer for details
concerning the particular accessories with which your vehicle is equipped.
READ FIRST — THEN DRIVE SAFELY
Before driving your vehicle, read this Owner’s
Manual carefully. This will ensure familiarity
with controls and maintenance requirements,
assisting you in the safe operation of your
vehicle.
WARNING
Important safety information reminders!
Follow these important driving rules to help
ensure a safe and complete trip for you and
your passengers!
•NEVER drive under the influence of alcohol
or drugs.
•ALWAYS observe posted speed limits and
never drive too fast for conditions.
•ALWAYS use your seat belts and appropri-
ate child restraint systems. Preteen chil-
dren should be seated in the rear seat.
•ALWAYS give your full attention to driving
and avoid using vehicle features or taking
other actions that could distract you.
•ALWAYS provide information about the
proper use of vehicle safety features to all
occupants of the vehicle.
•ALWAYS review this Owner’s Manual for im-
portant safety information.
As with other vehicles with features for off-
road use, failure to operate all-wheel drive
models correctly may result in loss of control
or an accident. Be sure to read “Driving safety
precautions” in the “Starting and driving” sec-
tion of this manual.
FOREWORD

ON-PAVEMENT AND OFF-ROAD
DRIVING
This vehicle will handle and maneuver differ-
ently from an ordinary passenger car because it
has a higher center of gravity for off-road use. As
with other vehicles with features of this type,
failure to operate this vehicle correctly may re-
sult in loss of control or an accident.
For additional information, refer to “On-
pavement and off-road driving precautions”,
“Avoiding collision and rollover” and “Driving
safety precautions” in the “Starting and driv-
ing” section of this manual.
MODIFICATION OF YOUR VEHICLE
This vehicle should not be modified. Modifica-
tion could affect its performance, safety or dura-
bility and may even violate governmental regu-
lations. In addition, damage or performance
problems resulting from modifications may not
be covered under INFINITI warranties.
WARNING
Installing an aftermarket On-Board Diagnostic
(OBD) plug-in device that uses the port during
normal driving, for example remote insurance
company monitoring, remote vehicle diagnos-
tics, telematics or engine reprogramming, maycause interference or damage to vehicle sys-
tems. We do not recommend or endorse the
use of any aftermarket OBD plug-in devices,
unless specifically approved by INFINITI. The
vehicle warranty may not cover damage
caused by any aftermarket plug-in device.
WHEN READING THE MANUAL
This manual includes information for all fea-
tures and equipment available on this model.
Features and equipment in your vehicle may
vary depending on model, trim level, options
selected, order, date of production, region or
availability. Therefore, you may find information
about features or equipment that are not in-
cluded or installed on your vehicle.
All information, specifications and illustrations
in this manual are those in effect at the time of
printing. INFINITI reserves the right to change
performance, design or component suppliers
without notice and without obligation.
From time to time, INFINITI may update or revise
this manual to provide Owners with the most
accurate information currently available. Please
carefully read and retain with this manual all
revision updates sent to you by INFINITI to
ensure you have access to accurate and up-to-
date information regarding your vehicle. Cur-rent versions of vehicle Owner’s Manuals and
any updates can also be found in the Owner
section of the INFINITI website at https://
owners.infinitiusa.com/owners/navigation/
manualsandGuides. If you have questions con-
cerning any information in your Owner’s
Manual, contact INFINITI Consumer Affairs. See
the INFINITI CUSTOMER CARE PROGRAM page in
this Owner’s Manual for contact information.IMPORTANT INFORMATION ABOUT
THIS MANUAL
You will see various symbols in this manual.
They are used in the following ways:
WARNING
This is used to indicate the presence of a haz-
ard that could cause death or serious personal
injury. To avoid or reduce the risk, the proce-
dures must be followed precisely.

CAUTION
This is used to indicate the presence of a haz-
ard that could cause minor or moderate per-
sonal injury or damage to your vehicle. To
avoid or reduce the risk, the procedures must
be followed carefully.
NOTE
Indicates additional helpful information.
If you see this symbol, it means “Do not do this”
or “Do not let this happen”.
If you see a symbol similar to these in an
illustration, it means the arrow points to the
front of the vehicle.
Arrows in an illustration that are similar to
these indicate movement or action.
Arrows in an illustration that are similar to
these call attention to an item in the illustra-
tion.
[]:
Square brackets are used to indicate messages,
keys, or items displayed on a screen. <>
:
Chevrons or angle brackets are used to indicate
texts on controls like buttons or switches inside
or on the vehicle.
CALIFORNIA PROPOSITION 65
WARNING
WARNING
Engine Exhaust, some of its constituents, and
certain vehicle components contain or emit
chemicals known to the State of California to
cause cancer and birth defects or other repro-
ductive harm. In addition, certain fluids con-
tained in vehicles and certain products of com-
ponent wear contain or emit chemicals known
to the State of California to cause cancer and
birth defects or other reproductive harm.
CALIFORNIA PERCHLORATE ADVISORY
Some vehicle parts, such as lithium batteries,
may contain perchlorate material. The following
advisory is provided: “Perchlorate Material -
special handling may apply, See
www.dtsc.ca.gov/hazardouswaste/
perchlorate.”
The Bluetooth® word mark and
logos are registered trademarks
owned by Bluetooth SIG, Inc.
and any use of such marks by
DENSO CORPORATION is under
license. Other trademarks and
trade names are those of their
respective owners.
SiriusXM® services require a
subscription after trial period
and are sold separately or as a
package. The satellite service is
available only in the 48
contiguous USA and DC.
SiriusXM® satellite service is
also available in Canada: see
www.siriusxm.ca
Required SiriusXM Satellite Ra-
dio and SiriusXM Travel Link
monthly subscriptions are sold
separately. Sirius XM Travel
Link is only available in select
markets. For more information,
see www.siriusxm.com/
travellink
