2016 SUBARU WRX Owners Manual

Audio/Antenna system
Antenna system & Roof antenna
The shark-fin type roof antenna is installed
in the center at the rear of the roof. & FM reception Although FM is normally static free,
reception can be affected by the surround-
ing area, atmospheric conditions, station
strength and transmitter distance. Build-
ings or other obstructions may cause
momentary static, flutter or station inter-
ference. If reception continues to be
unsatisfactory, switch to a stronger station.5-2

Installation of accessories Always consult your SUBARU dealer
before installing a citizen band radio or
other transmitting device in your vehicle.
Such devices may cause the electronic
control system to malfunction if they are
incorrectly installed or if they are not
suited for the vehicle.
Audio set Your SUBARU may be equipped with one
of the following audio sets. Refer to the
pages indicated in this section for operat-
ing details.
NOTE If a cell phone is placed near the audio
set, it may cause the audio set to emit
noise when the phone receives calls.
This noise does not indicate an audio
set malfunction. Note that a cell phone
should be placed as far as possible
from the audio set. Audio/Installation of accessories
– CONTINUED –5-3

Audio/Audio set
& Audio set The audio set will operate only when the
ignition switch is in the “ ACC ” or “ ON ”
position.
NOTE HD Radio Technology should be in-
cluded as feature.
5-4

Basic information before use & Initial screen ! Initial screen
1. When the ignition switch is in the
“ ACC ” or “ ON ” position, the initial screen
will be displayed and the system will begin
operating.
. When using the STARLINK function,
the display screen may be different
from the screen above.
. After a few seconds, the “ Caution
(Caution) ” screen will be displayed.
. After about 5 seconds, the “ Caution
(Caution) ” screen automatically
switches to the next screen. WARNINGWhen the vehicle is stopped with the
engine running, always apply the
parking brake for safety. & Loading and unloading a disc ! Loading a disc
CAUTIONNever try to disassemble the audio
kit or lubricate any part of the CD
player. Do not insert anything other
than a disc into the slot.
1. Insert a disc into the disc slot.
. After insertion, the disc is automati-
cally loaded. Audio/Basic information before use
– CONTINUED –5-5

Audio/Basic information before use
NOTE . For compatible discs, refer to “ CD
player and disc ” F 5-22.
. When inserting a disc, gently insert
it with the label facing up.
! Unloading a disc
1. Press
and remove the disc. & Connecting and disconnect-
ing a USB memory/portable
device ! Connecting a device
Connect a device to the USB port.
Turn on the power of the device when it is
not turned on.
NOTE . This device has a USB port for USB
memory/portable device.
. For compatible USB memory de-
vices, refer to “ USB memory device ”
F 5-24.
. For compatible iPod models, refer to
“ iPod ” F 5-24.
. Even if a USB hub is used to
connect more than two USB devices, only the last connected device will be
recognized.
5-6

& Touch screen gestures Operations are performed by touching the touch screen directly with your finger. Operation method Outline Main use
Touch
Quickly touch and release
once. Changing and selecting various
settings
Drag*
Touch the screen with your
finger, and move the screen
to the desired position. Scrolling the lists
Flick*
Quickly move the screen by
flicking with your finger. Scrolling the main screen page
*: The above operations may not be performed on all screens. NOTE There may be a delayed response to
flick operation that are performed at
high altitudes.
& Touch screen operation This system is operated mainly by the
buttons on the screen. (These are referred
to as screen buttons in this manual.)
. When a screen button is touched, a
beep sounds. (You can set the beep
sound.) Refer to “ Other settings ” F 5-10.
CAUTION. To prevent damaging the screen,
touch the screen buttons with
your finger lightly.
. Do not use objects other than
your finger to touch the screen.
. Wipe off fingerprints using a
glass cleaning cloth. Do not use
chemical cleaners to clean the
screen, as they may damage the
touch screen.
NOTE . If the system does not respond to
touching a screen button, move your
finger away from the screen and touch Audio/Basic information before use
– CONTINUED –5-7

Audio/Basic information before use
it again.
. Grayed-out screen buttons cannot
be operated.
. The displayed image may become
darkerandmovingimagesmaybe
slightly distorted when the screen is
cold.
. In extremely cold conditions, the
map may not be displayed and the data
input by a user may be deleted. Also,
the screen buttons may be harder than
usual to press.
. When you look at the screen
through polarized material such as
polarized sunglasses, the screen may
be dark and hard to see. If so, look at
the screen from different angles, adjust
the screen settings on the “ Display
Settings (Display Settings) ” screen or
take off your sunglasses.
& Entering letters and num-
bers/list screen operation! Entering letters and numbers
When entering the Bluetooth device name
or PIN-code, or the phone number, letters
and numbers can be entered via the
screen. In-Car-Device setting
No. Function
& 1
Enter the desired characters (alpha-
bet key mode).
& 2
Display the number keys (change to
number key mode).
& 3
Enter a space.
& 4
Set the characters/numbers entered
into the window.
& 5
Delete a character/number entered
into the window. Dialpad
No. Function
& 1
Enter the desired numbers.
& 2
Delete a number entered into the
window.5-8

! List screen
Two types of list are available on this
device.
. Multimedia playlists
. Contacts list
Multimedia playlists (Example: iPod play-
list)
No. Function
& 1
Graphic tab: Select a category that
wants to play back.
& 2
Return to the playback display of
each mode.
& 3
Select to skip to the next or previous
page. Contacts list (Example: phone book)
No. Function
& 1
Alphabet button: Jump to list entries
that begin with the same letter.
& 2
Return to the PHONE (Menu)
screen.
& 3
Select to skip to the next or previous
page. & Screen adjustment The contrast and brightness of the screen
display and the image of the camera
display can be adjusted.
1. Select
.
2. Select
SETTINGS (SETTINGS).
3. Select the items to be set.
In setting display, the Day/Night Mode and
the Brightness can be changed.
SETTINGS display Audio/Basic information before use
– CONTINUED –5-9
