2016 NISSAN NOTE headrest

FRONT SEATSE-35
< UNIT DISASSEMBLY AND ASSEMBLY >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
PASSENGER SIDE : Exploded ViewINFOID:0000000012432051
AWJIA1999ZZ
1. Headrest 2. Headrest holder (free) 3. Headrest holder (locked)
4. Seat assembly 5. Recline lever 6. Seat cushion outer finisher
(RH)
Revision: August 2015 2016 Versa Note

cardiagn.com

SE-36
< UNIT DISASSEMBLY AND ASSEMBLY >
FRONT SEAT
PASSENGER SIDE : Seatback
INFOID:0000000012834457
DISASSEMBLY
1. Remove the passenger side front seat. Refer to SE-22, "PASSENGER SIDE : Removal and Installation".
2. Remove the headrest.
3. Release trim strap (A) from the seat frame.
4. Release the J-hook retainer (C), unzip seatback zippers (A) and release J-clips (B).
5. Release the headrest holder locks as shown and remove. CAUTION:
Before removing the headrest holder, check its orientation
(front/rear and right/left).
ASSEMBLY
Assembly is in the reverse order of disassembly.
Smooth out all wrinkles during assembly.
PASSENGER SIDE : Seat CushionINFOID:0000000012834458
DISASSEMBLY
1. Remove the passenger side front seat. Refer to SE-22, "PASSENGER SIDE : Removal and Installation".
7. Occupant classification system sen-
sors 8. Occupant classification system har-
ness 9. Occupant classification
system control unit
10. Seat belt buckle 11. Seat cushion outer finisher (LH)
AWJIA0913ZZ
AWJIA1115ZZ
JMJIA4073ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

SE-38
< UNIT DISASSEMBLY AND ASSEMBLY >
REAR SEAT
REAR SEAT
Exploded ViewINFOID:0000000012432054
REAR SEAT WITH ARMREST
AWJIA1138ZZ
1. Seatback hinge trim2. Seatback hinge 3. Seatback striker
4. Headrest 5. Seatback (RH) 6. Headrest holder (locked)
Revision: August 2015 2016 Versa Note

cardiagn.com

REAR SEATSE-39
< UNIT DISASSEMBLY AND ASSEMBLY >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
7. Headrest holder (free) 8. Seatback latch bracket (RH) 9. Seatback latch (RH)
10. Seatback frame (RH) 11. Seatback latch finisher (RH) 12. Seatback latch release knob
13. Seatback trim (RH) 14. Seatback pad (RH) 15. Seat cushion hook
16. Seat cushion 17. Seat cushion pad 18. Seat cushion trim
19. Cup holder 20. Armrest 21. Armrest hinge bracket
22. Armrest pivot bolt bushing 23. Armrest pivot bolt 24. Armrest hinge bracket finisher
(RH)
25. Bushing 26. Armrest hinge bracket finisher (LH) 27. Seatback pad (LH)
28. Seatback trim (LH) 29. Seatback latch finisher (LH) 30. Seatback frame (LH)
31. Seatback latch bracket (LH) 32. Seatback latch (LH) 33. Seatbelt guide finisher
34. Seat belt guide 35. Seatback (LH)
Pawl
Revision: August 2015 2016 Versa Note

cardiagn.com

SE-40
< UNIT DISASSEMBLY AND ASSEMBLY >
REAR SEAT
REAR SEAT WITHOUT ARMREST
AWJIA1137ZZ
1. Seatback hinge trim2. Seatback hinge 3. Seatback striker
4. Headrest 5. Seatback(RH) 6. Headrest holder (locked)
7. Headrest holder (free) 8. Seatback latch bracket (RH) 9. Seatback latch (RH)
10. Seatback frame (RH) 11. Seatback latch finisher (RH) 12. Seatback latch release knob
13. Seatback trim (RH) 14. Seatback pad (RH) 15. Seat cushion hook
16. Seat cushion 17. Seat cushion pad 18. Seat cushion trim
Revision: August 2015 2016 Versa Note

cardiagn.com

SE-42
< UNIT DISASSEMBLY AND ASSEMBLY >
REAR SEAT
Seatback
INFOID:0000000012432056
DISASSEMBLY
Seatback (LH)
1. Remove the seatback (LH). Refer to SE-26, "SEATBACK : Removal and Installation".
2. Remove the headrest.
3. Release clips and remove latch finisher.
4. Release pawls and remove the seat belt guide finisher.
5. Remove nut and the seat belt guide.
6. Rotate the seatback latch release knob counterclockwise as shown ( ) and remove.
7. Release center seat belt guide rear finisher pawls and remove nut, then remove center seat belt guide.
8. Remove the armrest (1) (if equipped).
a. Remove clip (A) using a suitable tool, then the armrest bracket finisher (RH) (2) as shown ( ).
b. Remove nuts (B), then the armrest.
9. Release hook fasteners (A), then J-hook retainer (B).
10. Unzip the seatback trim zipper (C), then release J-clip retainers (D).
JMJIA4374ZZ
ALJIA1247ZZ
ALJIA1246ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

REAR SEATSE-43
< UNIT DISASSEMBLY AND ASSEMBLY >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
11. Release the headrest holder locks as shown and remove. CAUTION:
Before removing the headrest holder, check its orientation
(front/rear and right/left).
12. Remove the seatback trim and seatback pad from the seatback frame.
13. Remove bolts and the seatback latch.
14. Remove the hog rings and separate the seatback trim (1) from the seatback pad.
: Hog ring
NOTE:
Remove all pieces of hog rings and discard them.
Seatback (RH)
1. Remove the seatback (RH). Refer to SE-26, "SEATBACK : Removal and Installation".
2. Remove the headrest.
3. Release clips and remove latch finisher.
4. Rotate the seatback latch release knob counterclockwise as shown ( ) and remove.
5. Release hook fasteners (A), then J-hook retainer (B).
6. Unzip the seatback trim zipper (C), then release J-clip retainers (D).
JMJIA4073ZZ
ALJIA1248ZZ
JMJIA4374ZZ
ALJIA1250ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

SE-44
< UNIT DISASSEMBLY AND ASSEMBLY >
REAR SEAT
7. Release the headrest holder locks as shown and remove.CAUTION:
Before removing the headrest holder, check its orientation
(front/rear and right/left).
8. Remove the seatback trim and seatback pad from the seatback frame.
9. Remove bolts and the seatback latch.
10. Remove the hog rings and separate the seatback trim (1) from the seatback pad.
: Hog ring
NOTE:
Remove all pieces of hog rings and discard them.
ASSEMBLY
Assembly is in the reverse order of disassembly.
• Install new hog rings on the seatback trim in original positions.
• Use only one hog ring in each designated location.
• Make sure hog rings are correctly fastened around both the seat-
back trim and seatback pad wires.
• Use NISSAN standard hog rings and tools to assemble.
JMJIA4073ZZ
ALJIA1249ZZ
PIIB3356J
