2016 NISSAN NOTE headrest

FRONT SEATSE-19
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
DRIVER SEAT WITHOUT LIFT AND ARMREST
1. Armrest 2. Seat cushion outer finisher (RH) 3. Seat belt buckle
4. Seat cushion outer finisher (LH) 5. Lift lever 6. Lift lever cap
7. Recline lever 8. Headrest holder (locked) 9. Headrest holder (free)
10. Headrest 11. Seat assembly
AWJIA1998ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

SE-20
< REMOVAL AND INSTALLATION >
FRONT SEAT
DRIVER SIDE : Remova l and Installation
INFOID:0000000012432036
WARNING:
• Do not leave any objects (screwdriver s, tools, etc.) on the seat during repair. It can lead to personal
injury if the side air bag module should accidentally deploy.
• Always work from the side or back of th e seatback, do not work in front of seat.
• Do not use air tools or electric tools for servicing the seat.
• Do not drop, tilt, or bump the si de air bag module while installing the seat. Always handle it with
care.
• After the side air bag module inflates, the front seat frame must be replaced.
• Before removing the front seat, tu rn the ignition switch OFF, disconnect both battery cables then
wait at least three minutes.
CAUTION:
• When removing and installing the seat, use shop cloths to pr otect components from damage.
REMOVAL
1. Disconnect negative and positive battery terminals, then wait at least three minutes. Refer to PG-70,
"Removal and Installation (Battery)".
2. Slide the seat to the full forward position.
3. Remove the seat rear bolts.
4. Slide the seat to the full rearward position.
5. Remove the seat front bolts.
6. Tilt the seat rearward and disconnect the harness connectors from the seat and remove.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Make sure that the seat harness or the floor trim is not damaged during installation.
When installing the driver side front seat, tighten the bolts in the
order shown.
PASSENGER SIDE
1. Seat cushion outer finisher (RH) 2. Seat belt buckle 3. Seat cushion outer finisher
(LH)
4. Recline lever 5. Headrest holder (locked) 6. Headrest holder (free)
7. Headrest 8. Seat assembly
Driver side front seat bolt
torque: 40 Nm (4.1 kg-m, 30 ft-lb)
AWJIA0920ZZ
Revision: August 2015
2016 Versa Note

cardiagn.com

FRONT SEATSE-21
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
PASSENGER SIDE : Exploded ViewINFOID:0000000012829361
AWJIA1999ZZ
1. Headrest 2. Headrest holder (free) 3. Headrest holder (locked)
4. Seat assembly 5. Recline lever 6. Seat cushion outer finisher
(RH)
Revision: August 2015 2016 Versa Note

cardiagn.com

REAR SEATSE-23
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
REAR SEAT
Exploded ViewINFOID:0000000012432041
REAR SEAT WITH ARMREST
AWJIA1138ZZ
1. Seatback hinge trim 2. Seatback hinge 3. Seatback striker
4. Headrest 5. Seatback (RH) 6. Headrest holder (locked)
Revision: August 2015 2016 Versa Note

cardiagn.com

SE-24
< REMOVAL AND INSTALLATION >
REAR SEAT
7. Headrest holder (free)8. Seatback latch bracket (RH) 9. Seatback latch (RH)
10. Seatback frame (RH) 11. Seatback latch finisher (RH) 12. Seatback latch release knob
13. Seatback trim (RH) 14. Seatback pad (RH) 15. Seat cushion hook
16. Seat cushion 17. Seat cushion pad 18. Seat cushion trim
19. Cup holder 20. Armrest 21. Armrest hinge bracket
22. Armrest pivot bolt bushing 23. Armrest pivot bolt 24. Armrest hinge bracket finisher
(RH)
25. Bushing 26. Armrest hinge bracket finisher (LH) 27. Seatback pad (LH)
28. Seatback trim (LH) 29. Seatback latch finisher (LH) 30. Seatback frame (LH)
31. Seatback latch bracket (LH) 32. Seatback latch (LH) 33. Seatbelt guide finisher
34. Seat belt guide 35. Seatback (LH)
Pawl
Revision: August 2015 2016 Versa Note

cardiagn.com

REAR SEATSE-25
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
REAR SEAT WITHOUT ARMREST
AWJIA1137ZZ
1. Seatback hinge trim 2. Seatback hinge 3. Seatback striker
4. Headrest 5. Seatback(RH) 6. Headrest holder (locked)
7. Headrest holder (free) 8. Seatback latch bracket (RH) 9. Seatback latch (RH)
10. Seatback frame (RH) 11. Seatback latch finisher (RH) 12. Seatback latch release knob
13. Seatback trim (RH) 14. Seatback pad (RH) 15. Seat cushion hook
16. Seat cushion 17. Seat cushion pad 18. Seat cushion trim
Revision: August 2015 2016 Versa Note

cardiagn.com

FRONT SEATSE-31
< UNIT DISASSEMBLY AND ASSEMBLY >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
DRIVER SEAT WITHOUT LIFT AND ARMREST
1. Armrest 2. Seat cushion outer finisher (RH) 3. Seat belt buckle
4. Seat cushion outer finisher (LH) 5. Lift lever 6. Lift lever cap
7. Recline lever 8. Headrest holder (locked) 9. Headrest holder (free)
10. Headrest 11. Seat assembly
AWJIA1998ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

SE-32
< UNIT DISASSEMBLY AND ASSEMBLY >
FRONT SEAT
DRIVER SIDE : Seatback
INFOID:0000000012834455
DISASSEMBLY
1. Remove the driver side front seat. Refer to SE-20, "DRIVER SIDE : Removal and Installation".
2. Remove the headrest.
3. Release trim strap (A) from the seat cushion frame.
4. Remove the armrest (1) (if equipped).
a. Unzip the armrest to access armrest bolt (A).
b. Remove armrest bolt (A) and armrest (1).
5. Release the J-hook retainer (C), unzip seatback zippers (A) and release J-clips (B).
6. Release the headrest holder locks as shown and remove. CAUTION:
Before removing the headrest holder, check its orientation
(front/rear and right/left).
1. Seat cushion outer finisher (RH) 2. Seat belt buckle 3. Seat cushion outer finisher
(LH)
4. Recline lever 5. Headrest holder (locked) 6. Headrest holder (free)
7. Headrest 8. Seat assembly
JMJIA6015ZZ
ALJIA0994ZZ
AWJIA1114ZZ
JMJIA4073ZZ
