section for instructions on shifting the transmission out of
PARK for towing.
CAUTION!
•Towing this vehicle in violation of the above re-
quirements can cause severe transmission damage.
Damage from improper towing is not covered un-
der the New Vehicle Limited Warranty.
Automatic Transmission
• Vehicle can be towed with the front wheels elevated.
• Vehicle can be towed on a flatbed truck (all wheels off
the ground).
If the ignition key is unavailable, or the battery is
discharged, refer to “Shift Lever Override” in this section for instructions on shifting the transmission out of PARK
in order to move the vehicle.
CAUTION!
•
DO NOT flat tow any vehicle equipped with a
conventional automatic transmission. Damage to
the drivetrain will result. If these vehicles require
towing, make sure all drive wheels are OFF the
ground.
• Towing this vehicle in violation of the above re-
quirements can cause severe transmission damage.
Damage from improper towing is not covered un-
der the New Vehicle Limited Warranty.
6
WHAT TO DO IN EMERGENCIES 375

IGNITION KEY REMOVAL OVERRIDE
This vehicle is equipped with a Key Ignition Park Inter-
lock which requires the transmission to be in PARK
before the ignition switch can be turned to the LOCK/
OFF (key removal) position. To remove the key manually,
proceed as follows:
1. Firmly apply the parking brake
2. Remove the Allen Key located in the rear cargo area, inthe tool bag (if equipped) or on the left side in the
cargo box.
3. Unlock the steering column, pull the tilt/telescoping control handle down.
4. Pull the steering wheel outward until it is in the end of the travel position, then lock the steering column in
position, push the control handle up until fully en-
gaged. 5. Using the Allen key, undo the lower steering column
cover screws, and remove the lower cover.
Lower Steering Column Screw Locations
376 WHAT TO DO IN EMERGENCIES

6. Pull the release tab downwards using one hand andwith the other one remove the key, sliding it outwards.
7. Once the key is removed, reinstall the steering column cover.CAUTION!
It is advisable to contact your Authorized Dealer to
have the reinstall procedure carried out. If you would
like to proceed in performing the reinstall procedure
special attention must be paid to the correct coupling
of the clips. Otherwise damage to the cover or noise
might be heard due to incorrect fastening of the
lower cover.
Release Tab Location
6
WHAT TO DO IN EMERGENCIES 377

CAP-LESS FUEL FILL FUNNEL
The funnel for the Cap-Less Fuel System is located in the
rear cargo area inside the tool bag (if equipped), or on the
left side in the cargo box. If your vehicle is out of fuel and
an auxiliary fuel can is needed, insert the funnel into the
filler neck and proceed to fill the vehicle.
For more information on the Cap-Less Fuel System refer
to “Adding Fuel” in “Starting And Operating ” in this
manual.
378 WHAT TO DO IN EMERGENCIES

MAINTAINING YOUR VEHICLE
CONTENTS
ENGINE COMPARTMENT — 1.4L TURBO . . . .381
 ONBOARD DIAGNOSTIC SYSTEM — OBD II . .382
▫ Onboard Diagnostic System (OBD II)
Cybersecurity ....................... .382
 REPLACEMENT PARTS ..................383
 DEALER SERVICE ..................... .383
 MAINTENANCE PROCEDURES ...........384
▫ Engine Oil ......................... .385
▫ Engine Oil Filter ..................... .387
▫ Engine Air Cleaner Filter ................387 ▫
Maintenance-Free Battery ...............388
▫ Air Conditioner Maintenance .............389
▫ Body Lubrication .....................392
▫ Wiper Blades ....................... .393
▫ Adding Washer Fluid ..................397
▫ Exhaust System ..................... .397
▫ Cooling System ..................... .399
▫ Brake System ....................... .405
▫ Manual Transmission — If Equipped .......407
7

▫Euro Twin Clutch Transmission —
If Equipped ........................ .407
▫ Automatic Transmission — Aisin AW6F25
Transmission — If Equipped .............409
▫ Appearance Care And Protection From
Corrosion ...........................411
 FUSES ............................. .418
▫ Underhood Fuses ..................... .419
▫ Interior Fuses ....................... .422
▫ Rear Interior Fuses .....................426
 VEHICLE STORAGE ....................427
 REPLACEMENT BULBS .................428
 BULB REPLACEMENT ..................430 ▫
Headlamps Low Beam and High Beam ......430
▫ Front Turn Signal, Parking And Daytime Running
Lamps ............................ .433
▫ Front Fog Lamps ..................... .433
▫ Front, Rear Roof Lamps .................433
▫ Rear Tail, Stop, Backup And Turn Signal
Lamps ............................ .433
▫ Center High-Mounted Stop Lamp (CHMSL) . .434
 FLUID CAPACITIES ....................434
 FLUIDS, LUBRICANTS, AND GENUINE
PARTS ............................. .435
▫ Engine ............................ .435
▫ Chassis ........................... .437
380 MAINTAINING YOUR VEHICLE

ENGINE COMPARTMENT — 1.4L TURBO
1 — Air Cleaner Filter4 — Battery7 — Coolant Pressure Cap
2 — Engine Oil Dipstick 5 — Front Distribution Unit (Fuses) 8 — Coolant Pressure Bottle
3 — Brake Fluid Reservoir 6 — Washer Fluid Reservoir9 — Oil Fill Cap
7
MAINTAINING YOUR VEHICLE 381

ONBOARD DIAGNOSTIC SYSTEM — OBD II
Your vehicle is equipped with a sophisticated onboard
diagnostic system called OBD II. This system monitors
the performance of the emissions, engine, and Euro Twin
Clutch Transmission control systems. When these sys-
tems are operating properly, your vehicle will provide
excellent performance and fuel economy, as well as
engine emissions well within current government regu-
lations.
If any of these systems require service, the OBD II system
will turn on the “Malfunction Indicator Light (MIL)”. It
will also store diagnostic codes and other information to
assist your service technician in making repairs. Al-
though your vehicle will usually be drivable and not
need towing, see your authorized dealer for service as
soon as possible.
CAUTION!
•Prolonged driving with the MIL on could cause
further damage to the emission control system. It
could also affect fuel economy and driveability.
The vehicle must be serviced before any emissions
tests can be performed.
• If the MIL is flashing while the engine is running,
severe catalytic converter damage and power loss
will soon occur. Immediate service is required.
Onboard Diagnostic System (OBD II)
Cybersecurity
Your vehicle is required to have an Onboard Diagnostic
system (OBD II) and a connection port to allow access to
information related to the performance of your emissions
controls. Authorized service technicians may need to
382 MAINTAINING YOUR VEHICLE
