2014 NISSAN TEANA sensor

EM-158
< REMOVAL AND INSTALLATION >[VQ35DE]
OIL PAN AND OIL STRAINER
1. Remove the engine from the vehicle. Refer to
EM-220, "Removal and Installation".
2. Drain the engine oil. Refer to LU-26, "Changing Engine Oil"
.
3. Remove the oil level gauge guide.
4. Remove the drive belt. Refer to EM-134, "Removal and Installation"
.
5. Disconnect the A/C compressor harness connector.
6. Remove the A/C compressor bolts and remove the A/C compressor. Refer to HA-30, "COMPRESSOR :
Removal and Installation".
7. Remove coolant pipe bolts. Refer to CO-51, "Removal and Installation"
.
8. Disconnect the coolant lines from the engine oil cooler.
9. Remove the oil filter and engine oil cooler from the upper oil pan.
10. Remove the oil pressure switch, and the cranks haft position sensor (POS) from the upper oil pan.
11. Remove the lower oil pan. Refer to EM-156, "Removal and Installation (Lower Oil Pan)"
.
12. Remove the upper oil pan.
a. Loosen the bolts in the order as shown, using power tool.
b. Insert an appropriate size tool into the notch (1) of the upper oil pan as shown.
c. Pry off the upper oil pan by moving the tool up and down (2) as shown.
13. Remove the O-ring seals from the bottom of the cylinder block and oil pump housing. Use new O-rings for installation.
CAUTION:
Do not reuse O-rings.
LBIA0358E
SEM155F
WBIA0327E
Revision: November 20132014 Altima NAM

EM-168
< REMOVAL AND INSTALLATION >[VQ35DE]
ROCKER COVER
ROCKER COVER
Exploded ViewINFOID:0000000009460556
Removal and Installation LHINFOID:0000000009460557
REMOVAL
1. Remove front air duct. Refer to
EM-144, "Removal and Installation".
2. Remove blow by hose and breather hose from rocker cover.
3. Remove camshaft position sensor (LH). CAUTION:
• Handle carefully to avoid dropping and shocks.
• Do not disassemble.
• Do not allow metal powder to adhere to magnetic part at
sensor tip (A).
• Do not place sensors in a location where they are exposed to magnetism.
4. Disconnect the ignition coil harness connectors.
5. Remove the ignition coils. Refer to EM-162, "Removal and Installation LH"
.
CAUTION:
Do not shock ig nition coils.
1. Camshaft position sensor (LH) 2. O-ring 3. Camshaft position sensor (RH)
4. O-ring 5. Rocker cover (RH) 6. Breather (RH)
7. Blow by vent (RH) 8. Blow by vent (LH) 9. Rocker cover gasket (RH)
10. Rocker cover gasket (LH) 11. B reather (LH) 12. Rocker cover (LH)
Engine front A. Refer to INSTALLATION
AWBIA1339ZZ
ALBIA0258ZZ
Revision: November 20132014 Altima NAM

EM-170
< REMOVAL AND INSTALLATION >[VQ35DE]
ROCKER COVER
Do not shock ig
nition coils.
5. Remove blow by hose and breather hose from rocker cover.
6. Remove camshaft position sensor. CAUTION:
• Handle carefully to avoid dropping and shocks.
• Do not disassemble.
• Do not allow metal powder to adhere to magnetic part at sensor tip (A).
• Do not place sensors in a location where they are
exposed to magnetism.
7. Remove RH rocker cover bolts from cylinder head in order as shown.
INSTALLATION
Installation is in the reverse order of removal.
• Apply sealant to the areas on the front corners using suitable tool.
• Use Genuine Silicone RTV Sealant or equivalent. Refer to GI-21,
"Recommended Chemical Products and Sealants".
CAUTION:
The components must be installe d within 5 minutes of the liq-
uid gasket application. Then al low 30 minutes for the liquid
gasket to set before operating the engine.
ALBIA0258ZZ
: Engine front
AWBIA0704ZZ
PBIC2474E
Revision: November 20132014 Altima NAM

REAR TIMING CHAIN CASEEM-189
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
REAR TIMING CHAIN CASE
Exploded ViewINFOID:0000000009460566
Removal and InstallationINFOID:0000000009460567
REMOVAL
CAUTION:
• After removing timing chain, do not turn the crankshaft and camshaft separately, or the valves will
strike the pistons.
• When installing camshafts, chain tensioners, oil seal s, or other sliding parts, lubricate contacting
surfaces with new engine oil.
• Apply new engine oil to bolt threads and seat su rfaces when installing camshaft sprockets, camshaft
brackets, and crankshaft pulley.
• Before disconnecting fuel hose, release fuel pressure. Refer to FL-5, "Inspection"
.
1. Timing chain tensioner 2. Internal chain guide 3. Timing chain tensioner
4. Oil pressure sensor 5. Camshaft sprocket (EXH) 6. Timing chain (secondary)
7. Timing chain (primary) 8. Camshaft spro cket (INT) 9. Camshaft sprocket (INT)
10. Timing chain (secondary) 11. Camshaft sprocket (EXH) 12. Slack guide
13. Crankshaft sprocket 14. Rear timing chain case 15. Tension guide
16. O-ring
AWBIA1340ZZ
Revision: November 20132014 Altima NAM

EM-190
< REMOVAL AND INSTALLATION >[VQ35DE]
REAR TIMING CHAIN CASE
• Before removing the upper oil pan, re
move the crankshaft position sensor (POS).
• Be careful not to damage sensor edges.
• Do not spill engine oil or coolant on drive belt.
1. Remove the engine assembly. Refer to EM-220, "Removal and Installation"
.
2. Remove the oil pan lower and upper. Refer to EM-157, "Removal and Installation (Upper Oil Pan)"
.
3. Remove the front timing chain case. Refer to EM-174, "Removal and Installation"
.
4. Remove the primary and secondary timing chains. Refer to EM-182, "Removal and Installation"
.
5. Remove the rear timing chain case. CAUTION:
• Do not remove the plate metal cover for the oil passage.
• After removing the chain case, do not apply any load to
the case that might bend it.
a. Loosen and remove the rear timing chain case bolts in the order as shown.
b. Cut the sealant using Tool (A) and remove the rear timing chain case.
CAUTION:
• Be careful not to damage the mating surface.
• Do not insert a screwdriver or similar tool, this will dam-
age the mating surfaces.
c. In areas where the cutter is difficult to use, use a plastic hammer to lightly tap (1) the cutter where the liquid gasket is applied. Use
a plastic hammer to slide (2) the cutter by tapping on the side.
KBIA1307E
Tool number : KV10111100 (J-37228)
AWBIA0709ZZ
AWBIA1249GB
Revision: November 20132014 Altima NAM

EM-194
< REMOVAL AND INSTALLATION >[VQ35DE]
CAMSHAFT
CAMSHAFT
Exploded ViewINFOID:0000000009460568
Removal and InstallationINFOID:0000000009460569
CAUTION:
Apply new engine oil to parts marked in illustration before installation.
REMOVAL
1. Remove the timing chains. Refer to EM-182, "Removal and Installation".
1. Camshaft position sensor bracket (RH) 2. Camshaft brackets 3. No. 1 camshaft bracket (RH)
4. Camshaft (EXH) RH 5. Camshaft (INT) RH 6. Cylinder head (RH)
7. Cylinder head (LH) 8. Camshaft (EXH) LH 9. Camshaft (INT) LH
10. No. 1 camshaft bracket (LH) 11. Camshaft brackets 12. Camshaft position sensor bracket (LH)
A. Follow INSTALLATION procedure
AWBIA0840GB
Revision: November 20132014 Altima NAM

CAMSHAFTEM-195
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
2. Remove camshaft position sensor brackets (RH shown LH simi-
lar).
3. Remove the intake and exhaust camshaft brackets and the cam- shafts.
• Mark the camshafts, camshaft brackets, and bolts so they are
placed in the same position and direction for installation.
• Equally loosen the camshaft bracket bolts in several steps in the numerical order as shown.
4. Remove valve lifters, if necessary. NOTE:
Identify installation positions to ensure proper installation.
5. Remove secondary timing chain tensioner from cylinder head • Remove secondary tensioner with its stopper pin attached.
NOTE:
Stopper pin was attached when secondary timing chain was
removed.
INSTALLATION
ALBIA0259ZZ
SEM856E
SEM857E
SEM444G
Revision: November 20132014 Altima NAM

CAMSHAFTEM-199
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
• Tighten the camshaft brackets in the three steps, in numerical order as shown.
8. Measure difference in levels between front end faces of No. 1 camshaft bracket and cylinder head.
• If measurement is outside the specified range, re-install cam-
shaft and camshaft bracket.
9. Install camshaft position sensor bracket (PHASE) (RH and LH bank.)
10. Install the timing chains. Refer to EM-182, "Removal and Installation"
.
INSPECTION AFTER REMOVAL
Camshaft Visual Check
Check camshaft for scratches, seizure and wear. Replace if necessary.
Camshaft Runout
1. Put V-block on precise flat bed and support No. 2 and No. 4 jour-
nal of camshaft as shown.
2. Set dial gauges vertically to No. 3 journal as shown.
3. Turn camshaft in one direction slowly by hand, measure the camshaft runout on the dial gauges.
• Runout is the largest indicator reading after one full revolution.
4. If actual runout exceeds th e limit, replace the camshaft.
1 1.96 N·m (0.2 kg-m, 17 in-lb)
Tighten No. 7 - 10, then
tighten 1 - 6 in numerical order as shown.
2 5.88 N·m (0.6 kg-m, 52 in-lb) Tighten all in numerical or-
der as shown.
3 10.41 N·m (1.10 kg-m, 8 ft-lb) Tighten No. 1 - 10 in nu-
merical order as shown.
SEM885EA
SEM886EA
Standard : – 0.14 (– 0.0055 in)
EMQ0044D
Camshaft Runout
Standard : Less than 0.02 mm (0.0008 in)
Limit : 0.05 mm (0.0020 in)
PBIC0929E
Revision: November 20132014 Altima NAM
