2014 NISSAN TEANA sensor

EC-982
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
SENSOR POWER SUPPLY2 CIRCUIT
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK COMPONENTS
Check the following.
• Crankshaft position sensor (POS) (Refer to EC-819, "Component Inspection"
.)
• Refrigerant pressure sensor (Refer to EC-979, "Diagnosis Procedure"
.)
• APP sensor 2 (Refer to EC-941, "Component Inspection"
.)
• EVAP control system pressure sensor (Refer to EC-849, "Component Inspection"
.)
• EOP sensor (Refer to EC-877, "Component Inspection"
.)
Is the inspection result normal?
YES >> Perform GI-43, "Intermittent Incident".
NO >> Replace malfunctioning component.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ENGINE CONTROL SYSTEM SYMPTOMSEC-987
< SYMPTOM DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
SYMPTOM DIAGNOSIS
ENGINE CONTROL SYSTEM SYMPTOMS
Symptom TableINFOID:0000000009462865
SYSTEM — BASIC ENGINE CONTROL SYSTEM
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
Fuel Fuel pump circuit 11232 22 3 2 EC-965
Fuel pressure regulator system 334444444 4EC-687
Fuel injector circuit 11232 22 2EC-962
Evaporative emission system 334444444 4EC-580
Air Positive crankcase ventilation sys-
tem 334444444 41
EC-563
Incorrect idle speed adjustment 1 1 1 1 1 EC-675
Electric throttle control actuator 112332222 2 2EC-933,
EC-938
IgnitionIncorrect ignition timing adjustment33111 11 1 EC-675
Ignition circuit 11222 22 2EC-967
Power supply and ground circuit 22333 33 23 EC-709
Mass air flow sensor circuit
1
12 2
222 2 EC-727,
EC-732
Engine coolant temperature sensor circuit
333
EC-742,
EC-746
Air fuel ratio (A/F) sensor 1 circuit EC-753
,
EC-757
,
EC-760
,
EC-781
,
EC-927
Throttle position sensor circuit
22EC-744
,
EC-807
,
EC-895
,
EC-896
,
EC-945
Accelerator pedal position sensor circuit 3 2 1 EC-885
,
EC-940
,
EC-942
,
EC-947
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-988
< SYMPTOM DIAGNOSIS >[VQ35DE]
ENGINE CONTROL SYSTEM SYMPTOMS
1 - 6: The numbers refer to the order of inspection.
(continued on next page)
SYSTEM — ENGINE MECHANICAL & OTHER
Knock sensor circuit 2 3 EC-815
Engine oil temperature sensor 4 2 3EC-801,
EC-805
Crankshaft position sensor (POS) circuit 2 2 EC-817
Camshaft position sensor (PHASE) circuit 3 2EC-820
Vehicle speed signal circuit 2 3 3 3EC-867
ECM 22333333333EC-881,
EC-883
Intake valve timing control solenoid valve cir-
cuit 32 13223 3
EC-725
PNP signal circuit 3 3 3 3 3 EC-887
VIAS control solenoid valve 1 circuit 1EC-920
VIAS control solenoid valve 2 circuit 1EC-922
Refrigerant pressure sensor circuit 2 3 3 4EC-979
Electrical load signal circuit 3EC-957
Air conditioner circuit 223333333 3 2HA-15
ABS actuator and electric unit (control unit) 4BRC-55
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ENGINE CONTROL SYSTEM SYMPTOMSEC-989
< SYMPTOM DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
Fuel Fuel tank 5
5 FL-5
Fuel piping 5 5 5 5 5 5
Va p o r l o c k —
Valve deposit 5 555 55 5 —
Poor fuel (Heavy weight gasoline,
Low octane) —
Air Air duct
55555 5 EM-144
Air cleaner
EM-137
Air leakage from air duct
(Mass air flow sensor — electric
throttle control actuator) 5555 EM-144
Electric throttle control actuator
EM-146
Air leakage from intake manifold/
Collector/Gasket EM-146,
EM-149
Cranking Battery
111111
11
PG-4
Generator circuit
CHG-17,
CHG-20
Starter circuit 3 STR-12,
STR-16
Signal plate 6 EM-224
PNP signal 4TM-299
Engine Cylinder head
55555 55 5 EM-207
Cylinder head gasket 4 3
Cylinder block
66666 66 6 4
EM-224
Piston
Piston ring
Connecting rod
Bearing
Crankshaft
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-998
< SERVICE DATA AND SPECIFICATIONS (SDS) [VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Idle SpeedINFOID:0000000009462872
*: Under the following conditions
• A/C switch: OFF
• Electric load: OFF (Lights, heater fan & rear window defogger)
• Steering wheel: Kept in straight-ahead position
Ignition TimingINFOID:0000000009462873
*: Under the following conditions
• A/C switch: OFF
• Electric load: OFF (Lights, heater fan & rear window defogger)
• Steering wheel: Kept in straight-ahead position
Calculated Load ValueINFOID:0000000009462874
Mass Air Flow SensorINFOID:0000000009462875
*: Engine is warmed up to normal operating temperature and running under no load. Condition Specification
No load* (in P or N position) 650 ± 50 rpm
Condition Specification
No load* (in P or N position) 12 ± 2 ° BTDC
Condition Specification (Using CONSULT or GST)
At idle 10 – 35 %
At 2,500 rpm 10 – 35 %
Supply voltageBattery voltage (11 – 14 V)
Output voltage at idle (in N position) 0.9 – 1.2 V*
Mass air flow (Using CONSULT or GST) 2.0 – 6.0 g/s at idle*
7.0 – 20.0 g/s at 2,500 rpm*
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EM-4
< PRECAUTION >[QR25DE]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951675
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for Draining CoolantINFOID:0000000009460453
• Drain coolant when engine is cooled.
Precaution for Disconnecting Fuel PipingINFOID:0000000009460454
• Before starting work, make sure no fire or spark producing items are in the work area.
• Release fuel pressure before any removal or disassembly.
• After disconnecting pipes, plug openings to stop fuel leakage.
Precaution for Removal and DisassemblyINFOID:0000000009460455
• When instructed to use special service tools, use the s pecified tools. Always be careful to work safely, avoid
forceful operations.
• Use maximum care to avoid damage to mating or sliding surfaces.
• Cover openings of engine system with tape or equivalent , if necessary, to seal out foreign materials.
• Mark and arrange disassembly parts in an organi zed way for easy troubleshooting and assembly.
• When loosening nuts and bolts, as a basic rule, start with the one furthest outside, then the one diagonally
opposite, and so on. If the order of loosening is specified, follow the specifications.
Precaution for Inspection, Repair and ReplacementINFOID:0000000009460456
• Before repairing or replacing, thoroughly inspect parts. Inspect new replacement parts in the same way, and
replace if necessary.
Revision: November 20132014 Altima NAM

PREPARATIONEM-9
< PREPARATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
KV10107902
(J-38959)
Valve oil seal puller Removing valve oil seal
KV10115600
(J-38958)
Valve oil seal drift Installing valve oil seal
Use side A.
a: 20 (0.79) dia. d: 8 (0.31) dia.
b: 13 (0.51) dia. e: 10.7 (0.421) dia.
c: 10.3 (0.406) dia. f: 5 (0.20) dia.
Unit: mm (in)
—
(J-39386)
Valve oil seal drift Installing valve oil seal
EM03470000
(J-8037)
Piston ring compressor Installing piston assembly into cylinder bore
ST16610001
(J-23907)
Pilot converter puller Removing crankshaft pilot converter
16441 6N210
(J-45488)
Quick connector release Removing fuel tube quick connectors in en-
gine room
(Available in SEC. 164 of PARTS CATALOG:
Part No. 16441 6N210)
KV10117100
(J-36471-A)
Heated oxygen sensor wrench Loosening or tightening heated oxygen sen-
sor
For 22 mm (0.87 in) hexagon nut
Tool number
(TechMate No.)
Tool name Description
S-NT011
S-NT603
NT024
S-NT044
S-NT045
PBIC0198E
NT379
Revision: November 20132014 Altima NAM

EM-10
< PREPARATION >[QR25DE]
PREPARATION
Commercial Service Tool
INFOID:0000000009460462
KV991J0050
(J-44626)
Air fuel ratio (A/F) sensor wrench Loosening or tightening air fuel ratio (A/F)
sensor 1
KV11105210
(J-44716)
Stopper plate Holding drive plate and flywheel static
—
(J-46535)
Drive belt tension releaser Releasing drive belt tension
Tool number
(TechMate No.)
Tool name Description
LEM054
ZZA0009D
WBIA0536E
Tool name
Description
Tube presser Pressing the tube of liquid gasket
Pulley holder Removing and installing crankshaft pulley
(Holding crankshaft pulley)
a: 68 mm (2.68 in) dia.
b: 8 mm (0.31 in) dia.
Crank puller Removing crankshaft pulley
S-NT052
NT628
ZZA0010D
Revision: November 20132014 Altima NAM
