EC-544
< PRECAUTION >[VQ35DE]
PRECAUTIONS
•
Before replacing ECM, perform ECM Terminals and Reference
Value inspection and check ECM functions properly. Refer to
EC-613, "Reference Value"
.
• Handle mass air flow sensor carefully to avoid damage.
• Never clean mass air flow sensor with any type of detergent.
• Never disassemble electric throttle control actuator.
• Even a slight leakage in the air intake system can cause seri-
ous incidents.
• Never shock or jar the camsh aft position sensor (PHASE),
crankshaft position sensor (POS).
• After performing each TROUBLE DIAGNOSIS, perform DTC
Confirmation Procedure or Component Function Check.
The DTC should not be displ ayed in the DTC Confirmation
Procedure if the repair is completed. The Component Func-
tion Check should be a good result if the repair is completed.
• When measuring ECM signals with a circuit tester, never allow
the two tester probes to contact.
Accidental contact of probes will cause a short circuit and
damage the ECM power transistor.
MEF040D
JSBIA1315ZZ
SEF348N
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PREPARATIONEC-547
< PREPARATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Fuel filler cap adapter
i.e.: (MLR-8382) Checks fuel tank vacuum relief valve opening
pressure
Socket wrench Removes and installs engine coolant temperature sensor. Refer to CO-51, "Exploded View"
.
Oxygen sensor thread
cleaner
i.e.: (J-43897-18)
(J-43897-12) Reconditions the exhaust system threads before
installing a new oxygen sensor. Use with anti-
seize lubricant shown below.
a: 18 mm diameter with pitch 1.5 mm for Zirco-
nia Oxygen Sensor
b: 12 mm diameter with pitch 1.25 mm for Tita-
nia Oxygen Sensor
Anti-seize lubricant
i.e.: (Permatex
TM
133AR or equivalent
meeting MIL specifica-
tion MIL-A-907) Lubricates oxygen sensor thread cleaning tool
when reconditioning exhaust system threads.
Tool name
(TechMate No.) Description
S-NT815
S-NT705
AEM488
S-NT779
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-548
< SYSTEM DESCRIPTION >[VQ35DE]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
ENGINE CONTROL SYSTEM
ENGINE CONTROL SYSTEM :
Component Parts LocationINFOID:0000000009462480
ENGINE ROOM
ALBIA0805ZZ
No. Component Function
1. Power valve actuator 1 EC-561, "Power Valve Actuator 1 and 2"
2. Electronic controlled engine mount control solenoid valveEC-556, "Electronic Controlled Engine Mount"
3. Cooling fan motor-2EC-554, "Cooling Fan"
4. Cooling fan motor-1EC-554, "Cooling Fan"
5. ECMEC-555, "ECM"
6. Refrigerant pressure sensorEC-562, "Refrigerant
Pressure Sensor"Refer to HAC-9, "Component Part Location" for detailed installa-
tionlocation.
7. Battery current sensor (with battery temperature sensor) EC-553, "Battery Current Sensor (With Battery Temperature Sen-
sor)"
8. Cooling fan motor relay-2
EC-554, "Cooling Fan"
9. Cooling fan motor relay-3EC-554, "Cooling Fan"
10. IPDM E/RIPDM E/R activates the internal control circuit to perform the relay
ON-OFF control according to the input signals from various sen-
sors and the request signals received from control units via CAN
communication.
Refer to PCS-4, "Component Parts Location"
for detailed installa-
tionlocation.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

COMPONENT PARTSEC-549
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
ENGINE
11. Mass air flow sensor (with intake air temperature sensor)
EC-560, "Mass Air Flow Sensor (With Intake Air Temperature Sen-sor)"
12. Electric throttle control actuator
EC-555, "Electric Throttle Control Actuator"
13. Power valve actuator 2 EC-561, "Power Valve Actuator 1 and 2"
14. EVAP canister purge volume control solenoid valveEC-557, "EVAP Canister Purge Volume Control Solenoid Valve"
15. VIAS control solenoid valve 2EC-562, "VIAS Control Solenoid Valve 1 and 2"
16. VIAS control solenoid valve 1EC-562, "VIAS Control Solenoid Valve 1 and 2"
No. Component Function
A. Engine rear upper-left B. Engine top center C. Engine front lower-right
:Vehicle front
No. Component Function
1. Camshaft position sensor (PHASE)
(bank 1) EC-554, "Camshaft Position Sensor (PHASE)"
2.Ignition coil (with power transistor)
(bank 1) EC-560, "Ignition Coil
(With Power Transistor)"
3. PCV valve EC-563, "Positive Crankcase Ventilation (PCV)"
4. Intake valve timing control solenoid valve (bank 1)EC-560, "Intake Valve Timing Control Solenoid Valve"
5. Engine oil pressure sensorEC-557, "Engine Oil Pressure Sensor"
6. Intake valve timing control solenoid valve (bank 2)EC-560, "Intake Valve Timing Control Solenoid Valve"
7. Crankshaft position sensor (POS)EC-554, "Crankshaft Position Sensor (POS)"
JPBIA5982ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-550
< SYSTEM DESCRIPTION >[VQ35DE]
COMPONENT PARTS
EXHAUST
BODY
8.Ignition coil (with power transistor)
(bank 2) EC-560, "Ignition Coil (With Power Transistor)"
9.Camshaft position sensor (PHASE)
(bank 2) EC-554, "Camshaft Posi
tion Sensor (PHASE)"
10. Engine coolant temperature sensor EC-556, "Engine Coolant Temperature Sensor"
11. Fuel injector (bank 1)EC-558, "Fuel Injector"
12. Knock sensor (bank 1)EC-560, "Knock Sensor"
13. Knock sensor (bank 2)EC-560, "Knock Sensor"
14. Fuel injector (bank 2)EC-558, "Fuel Injector"
15. Engine oil temperature sensorEC-557, "Engine Oil Temperature Sensor"
No. Component Function
JPBIA4687ZZ
No. Component Function
1. Air fuel ratio (A/F ) sensor 1 (bank 2) EC-552, "Air Fuel Ratio (A/F) Sensor 1"
2. Heated oxygen sensor 2 (bank 2) EC-559, "Heated Oxygen Sensor 2"
3. Heated oxygen sensor 2 (bank 1)EC-559, "Heated Oxygen Sensor 2"
4. Air fuel ratio (A/F) sensor 1 (bank 1) EC-552, "Air Fuel Ratio (A/F) Sensor 1"
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

COMPONENT PARTSEC-551
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
A. Instrument panel
periphery (driver
side) B. Pedal periphery C. Inside fuel tank periphery
D. Behind fuel tank periphery :Vehicle front
No. Component Function
1. Combination meter Malfunction indicator lamp (MIL)
EC-560, "Malfunction Indicator lamp (MIL)"
Information displayThe operation mode of the ASCD is indicated on the information
display in the combination meter.
ECM transmits the status signal to the combination meter via CAN
communication according to ASCD operation.
2. ASCD steering switch EC-553, "ASCD Steering Switch"
3. Stop lamp switchEC-562, "Stop Lamp Switch & Brake Pedal Position Switch"
4. Brake pedal position switch EC-562, "Stop Lamp Switch & Brake Pedal Position Switch"
5. Accelerator pedal position sensor EC-552, "Accelerator Pedal Position Sensor"
6. Fuel level sensor unit and fuel pumpEC-558, "Fuel Level Sensor Unit and Fuel Pump (With Fuel Tank Temperature Sensor)"
7. Fuel tank temperature sensorEC-558, "Fuel Level Sensor Unit and Fuel Pump (With Fuel Tank Temperature Sensor)"
ALBIA0806ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-552
< SYSTEM DESCRIPTION >[VQ35DE]
COMPONENT PARTS
Accelerator Pedal Position Sensor
INFOID:0000000009462481
The accelerator pedal position sensor is installed on the upper end
of the accelerator pedal assembly. The sensor detects the accelera-
tor position and sends a signal to the ECM.
Accelerator pedal position sensor has two sensors. These sensors
are a kind of potentiometers which transform the accelerator pedal
position into output voltage, and emit the voltage signal to the ECM.
In addition, these sensors detect the opening and closing speed of
the accelerator pedal and feed the voltage signals to the ECM. The
ECM judges the current opening angle of the accelerator pedal from
these signals and controls the throttle control motor based on these
signals.
Idle position of the accelerator pedal is determined by the ECM
receiving the signal from the accelerator pedal position sensor. The
ECM uses this signal for the engine operation such as fuel cut.
Air Fuel Ratio (A/F) Sensor 1INFOID:0000000009462482
DESCRIPTION
The air fuel ratio (A/F) sensor 1 is a planar one-cell limit current sen-
sor. The sensor element of the A/F sensor 1 is composed an elec-
trode layer, which transports ions. It has a heater in the element.
The sensor is capable of precise measurement = 1, but also in the
lean and rich range. Together with its control electronics, the sensor
outputs a clear, continuous signal throughout a wide range.
The exhaust gas components diffuse through the diffusion layer at
the sensor cell. An electrode layer is applied voltage, and this current
relative oxygen density in lean. Also this current relative hydrocar-
bon density in rich.
Therefore, the A/F sensor 1 is able to indicate air fuel ratio by this
electrode layer of current. In additi on, a heater is integrated in the
sensor to ensure the required operating temperature of approxi-
mately 800 °C (1,472 °F).
8. EVAP control system pressure sensor EC-558, "EVAP Control System Pressure Sensor"
9. EVAP canister vent control valve EC-558, "EVAP Canister Vent Control Valve"
10. EVAP canisterEC-557, "EVAP Canister"
No. Component Function
JPBIA4615ZZ
PBIB1741E
JPBIA4038GB
JPBIA5446GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

COMPONENT PARTSEC-553
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
A/F SENSOR 1 HEATER
A/F sensor 1 heater is integrated in the sensor.
The ECM performs ON/OFF duty control of the A/F sensor 1 heater corresponding to the engine operating
condition to keep the temperature of A/F s ensor 1 element within the specified range.
ASCD Steering SwitchINFOID:0000000009462483
ASCD steering switch has variant values of electrical resistance for each button. ECM reads voltage variation
of switch, and determines which button is operated.
Battery Current Sensor (With Battery Temperature Sensor)INFOID:0000000009462484
OUTLINE
The power generation voltage variable control enables fuel con-
sumption to be decreased by reducing the engine load which is
caused by the power generation of the generator.
Based on sensor signals, ECM judges whether or not the power
generation voltage variable contro l is performed. When performing
the power generation voltage variable control, ECM calculates the
target power generation voltage based on the sensor signal. And
ECM sends the calculated value as the power generation command
value to IPDM E/R.
CAUTION:
Never connect the electrical componen t or the ground wire directly to the battery terminal. The con-
nection causes the malfunction of th e power generation voltage variable control, and then the battery
discharge may occur.
BATTERY CURRENT SENSOR
The battery current sensor is installed to the battery cable at the negative terminal. The sensor measures the
charging/discharging current of the battery.
BATTERY TEMPERATURE SENSOR
Battery temperature sensor is integrated in battery current sensor.
The sensor measures temperature around the battery.
The electrical resistance of the t hermistor decreases as temperature
increases.

*: These data are reference va lues and are measured between bat-
tery temperature sensor signal terminal and sensor ground.
JPBIA3262ZZ
Temperature [ °C ( °F)] Voltage* (V) Resistance (k Ω)
25 (77) 3.333 1.9 - 2.1
90 (194) 0.969 0.222 - 0.258
SEF012P
