2014 LEXUS LX570 display

5853-4. Using the rear seat entertainment system
3
Interior features
LX570_OM_OM60L21U_(U) Using the radio (internet radio broadcast) ■
When a different audio source is selected at the front seats
Radio (internet radio broadcast) mode ca nnot be selected at the rear seats.One of Apps’ features is the ability to listen to internet radio. In order to use
this service, an Apps compatible ph one and the navigation system needs to
be set. For details, refer to the “Navigation System Owner’s Manual”.
Select Apps mode on the
source screen to display the
control screen.

5863-4. Using the rear seat entertainment system
LX570_OM_OM60L21U_(U) Playing an audio CD/CD text
Selecting a track
Press or until the desired track number appears on the
screen.
Fast forwarding or rewinding a track
Press or , or press and hold or .
Playing or pausing a track
Press .■ Display
Select disc mode on the source
screen to display the control
screen.
■ Controller
Play/pause
Fast forward or rewind
Selecting a track (press)
Fast forward or rewind (press
and hold)

5873-4. Using the rear seat entertainment system
3
Interior features
LX570_OM_OM60L21U_(U) Playing WMA/MP3 discs
Selecting a file
Press or until the desired file number appears on the
screen.
Selecting a folder
Press “  ” or “  ” of the “FOL/CH” button until the desired folder number
appears on the screen.■ Display
Select disc mode on the source
screen to display the control
screen.
■ Controller
Selecting a folder
Play/pause
Fast forward or rewind
Selecting a file (press)
Fast forward or rewind (press
and hold)

5893-4. Using the rear seat entertainment system
3
Interior features
LX570_OM_OM60L21U_(U) Playing a Bluetooth ®
audio
Selecting a desired album
Press “  ” or “  ” of the “FOL/CH” button un til the desired album number
appears on the screen.
Selecting a desired track
Press or repeatedly until the desired track number
appears on the screen.■ Display
Select BT-A mode on the
source screen to display the
control screen.
■ Controller
Selecting a album
Play/pause
Fast forward or rewind
Selecting a track (press)
Fast forward or rewind (press
and hold)

5923-4. Using the rear seat entertainment system
LX570_OM_OM60L21U_(U) Playing a USB memory
Selecting a desired folder or album
Press “  ” or “  ” of the “FOL/CH” button un til the desired folder/album
number appears on the screen.
Selecting a desired file or track
Press or repeatedly until the desired file/track number
appears on the screen.■ Connecting a USB
 P. 5 4 9
■ Display
Select USB mode on the source
screen to display the control
screen.
■ Controller
Selecting a folder/album
Play/pause
Fast forward or rewind
Selecting a file/track (press)
Fast forward or rewind (press
and hold)

5943-4. Using the rear seat entertainment system
LX570_OM_OM60L21U_(U) Playing iPod
Selecting a desired track
Press or repeatedly until the desired track number
appears on the screen.
Fast forwarding or rewinding a track
Press or , or press and hold or .■ Connecting an iPod
 P. 5 5 9
■ Display
Select iPod mode on the source
screen to display the control
screen.
■ Controller
Play/pause
Fast forward or rewind
Selecting a track (press)
Fast forward or rewind (press
and hold)

5963-4. Using the rear seat entertainment system
LX570_OM_OM60L21U_(U) Playing DVD video Press the “DISC” button or select disc mode to display DVD video.
■ Controller
Selecting an icon
Turning on the DVD mode
Inputting the selected icon
Playing/pausing a disc
Fast forwarding a disc during
playback and forward slowly
during pause
Stopping a screen
Turning on the menu
Turning on the control icon
screen
Turning on the title selection
screen
Press to select a chapter
Press and hold to fast forward
or rewind a chapter
Rewinding a disc

5973-4. Using the rear se at entertainment system
3
Interior features
LX570_OM_OM60L21U_(U) ■ Control icon screen
Press the “OPTION” button on the controller if no icons are shown
while watching a DVD video, and the following screen appears.
Hide the buttons
Setting screen appears
(  P. 6 0 1 )
Menu screen appears
Rewind
Stop
Play/pause
Fast forward
If appears on the screen when you select an icon, the operation
relevant to that control is not permitted.
■ Settings screen
Select “Settings” on the control icon screen, the following screen
appears.
Change initial setting
Return to previous screen
Search by title
Display the predetermined
scene and start playing from
there
Change audio language
Change subtitle language
Change angle
