2014 LEXUS LX570 display

6013-4. Using the rear se at entertainment system
3
Interior features
LX570_OM_OM60L21U_(U) Initial DVD setup
■ Displaying “Setup Menu” screen
Select “Setup” on the control icon screen.
Select the setting to be changed.
Pa g e 1
After you change the settings,
select “OK”. The initial setting screen will be
turned off and return to the picture
previously.
“Default”: Restores default settings
“Page 2”: Go to page 2
: Returns to the previous
screen
Pa g e 2 STEP 1
STEP 2

6043-4. Using the rear seat entertainment system
LX570_OM_OM60L21U_(U) Setup operation from the front seat
This screen appears when a fron t passenger selects the setup menu.
Rear passengers can cancel this
setup operation by selecting
“Play”. The player will resume nor-
mal play.
Likewise, a front passenger can
cancel a rear passenger’s selection
of the setup menu.■
Error messages
If “Region code error” is displayed, chec k if the region code printed on the DVD
matches the player’s region code.
If a different message is displayed:  P. 5 2 5

6093-4. Using the rear se at entertainment system
3
Interior features
LX570_OM_OM60L21U_(U) Setting LCD AI
Automatically determines th e tone of the video image and sets the con-
trast to an optimum level, displaying a sharp image.
Press the “SETTING” button on the controller.
Select “LCD AI”. “LCD AI” indicator is highlighted.
Setting the display mode
Press the “SETTING” button on the controller.
Select “Screen Size” tab on the screen.
Select “Normal”, “Wide1” or
“Wide2”.STEP 1
STEP 2
STEP 1
STEP 2
STEP 3

6113-4. Using the rear se at entertainment system
3
Interior features
LX570_OM_OM60L21U_(U) ■
A/V input port
The rear seat entertainment system plays videos and sound when audio-video
equipment is connected to the A/V input port. For details, refer to the manufac-
turer’s instructions. ■
Powe r o u t l e t
The power outlet is used to connect the audio-video equipment. (  P. 7 0 1 )■
To turn off the display
■
LC D AI
The image quality is automatically adjust ed when the “LCD AI” indicator is on,
brightness and contrast adjustment becomes less effective.
NOTICE■
When the A/V input port is not in use
Keep the A/V input port cover closed.
Inserting anything other than an appropriat e plug may cause electrical failure or a
short circuit. Select “Screen off” on the screen.
To turn the display back on, press the
“SOURCE”, “DISC”, “VIDEO” or
“SETTING” button on the controller.

612
LX570_OM_OM60L21U_(U) 3-5. Using the hands-free system (for cellular phone)
Hands-free system (for cellular phone) The hands-free system is a function th at allows you to use your cellular
phone without touching it.
This system supports Bluetooth ®
cellular phones. Bluetooth ®
is a wireless
data system that allows a cellular phon e to wirelessly connect to the hands-
free system and outgoing/incoming calls.
The illustrations of the hands-free system screens shown here may slightly
vary depending on the type of the system.
■ Telephone switch
Off hook switch
• Sending
• Receiving
• “Phone” screen display
On hook switch
• End call
• Refuse call

6143-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L21U_(U) Status display
You can check indicators such as signal strength an d battery charge on
the “Phone” screen.
Connection status
Battery charge
Call area
Signal strength
Indicators Conditions
Connection status Good No
connection
Battery charge Full Empty
Call area “Rm”: Roaming area
Signal strength Excellent Poor

6163-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L21U_(U) ■
Bluetooth ®
antenna
The antenna is built into the audio unit. If the cellular phone is behind the seat or in
the console box, or touching or covered by metal objects, connection status may
deteriorate. ■
Battery charge/Signal status ●
This display may not correspond exac tly with the cellular phone itself.●
When the cellular phone is not conn ected, “No connect” is displayed.●
When the cellular phone is out of the se rvice area or in a place inaccessible by
radio waves, “No Service” is displayed.■
When using Bluetooth ®
audio and hands-free system at the same time
The following problems may occur. ●
The Bluetooth ®
connection may be cut.●
Noise may be heard on the Bluetooth ®
audio playback.■
About the phonebook in this system
The following data is stored for every registered phone. When another phone is
connecting, you cannot read the registered data. ●
Phonebook date ●
Call history data ●
Speed dial data ●
Image data ●
Messages ●
Quick reply messages ●
All phone settings
When you delete the phone, the above-mentioned data is also deleted. ■
When you release your car
Be sure to initialize your data. (  P. 4 2 2 )

6213-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L21U_(U) Using a Bluetooth ®
phone
Registering a Bluetooth ®
phone
You can register up to 5 phones in the system.
Display the “Phone” screen. (  P. 621)
Touch “Yes”. If 5 Bluetooth ®
devices have
already been registered, a regis-
tered device needs to be deleted.
(  P. 6 2 5 )Device name
Bluetooth ®
connection sta-
tus
Character deletion
Make a call
To display the screen shown above, press or on the steer-
ing wheel. STEP 1
STEP 2
