2013 VOLKSWAGEN PASSAT CC Owners Manual

8. Install the rubber cover ⇒ fig. 186 (2).

Replacing the HID bulb
See your authorized Volkswagen dealer or authorized Volkswagen Service Facility for assistance in
replacing the HID bulb (1).
The illustrations show the right headlight from behind. The left headlight is arranged as a mirror
image of the right.
Failure of a single LED within a headlight is not indicated. However, the = indicator light will
appear if all LEDs fail.
Different models may have different lights, and the location and design of covers, bulb holders,
and bulbs may be in a different location than shown in the illustrations.
You cannot replace the LEDs in LED daytime running lights. Contact your authorized
Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Changing the fog light bulbs in the front bumper

Fig. 188 In the left front bumper: Fog light.

Fig. 189 In the removed light: Replacing the bulb.

Changing the fog light bulbs in the front bumper (CC R Line)

Fig. 190 In the right front bumper: Fog light.

Fig. 191 In the removed light: Replacing the bulb.

Only perform these steps in the specified order:
11. Check if the bulb is installed securely.
12. Connect the connector (1) on the bulb so that it clicks into place.
13. Insert the light into the bumper.
14. Install the screws ⇒ fig. 190 (2).
15. Insert the cover in the bumper opposite the direction indicated by the arrow . The cover
must click into place securely.
16. Make sure the cover is installed securely.

The illustrations show the right fog light. The left fog light is arranged as a mirror image of the
right.
Replacing the taillight bulbs in the luggage compartment lid

Fig. 192 In the luggage compartment lid: Removing the cover.

Fig. 193 In the luggage compartment lid: Removing the bulb holder.

Only perform these steps in the specified order:
1. Follow the checklist and perform the steps.
2. Open the luggage compartment lid
3. Carefully pry the cover off ⇒ fig. 192 using the flat screwdriver blade from the vehicle tool
kit ⇒ fig. 170.
4. Turn the bulb holder approximately 30° counterclockwise and remove it with the bulb.
5. Replace burned out bulbs with new bulbs that are identical to the ones being replaced.
6. Insert the bulb holder in the taillight and turn it approximately 30° clockwise. The bulb
holder must click into place.
7. Insert the cover. The cover must lock into place and be secure.

LEDs in the taillights in the luggage compartment lid
LEDs cannot be replaced. Contact your authorized Volkswagen dealer or authorized Volkswagen
Service Facility for assistance.
Different models may have different lights, and the location and design of covers, bulb holders,
and bulbs may be in a different location than shown in the illustrations.

Jump-starting

Jump-starting

WARNING
Improper use of jumper cables when jump-starting a vehicle with a dead battery can cause
the battery to explode, leading to serious personal injury. To help reduce the risk of battery
explosion:
x All work on the batteries or the electrical system in your vehicle can cause serious acid
burns, fires, or electrical shocks. Always read and heed the following WARNINGS and safety
precautions before working on the batteries or the electrical system, Vehicle battery.
x Always make sure that the battery providing starting assistance (the booster battery) has
the same voltage as the dead battery (12 V) and about the same amperage capacity (see
battery label).
x Never jump-start a vehicle with a thawed or frozen vehicle battery. The battery can
explode. A dead battery can freeze at temperatures around +32 °F (0 °C).
x A battery that is frozen or was frozen, but has since thawed, must be replaced.
x When the vehicle battery is jump-started, it gives off hydrogen gas, which is highly
explosive! Always keep fire, sparks, open flame, and smoking materials far away from vehicle
batteries. Never use a cellular telephone while connecting or disconnecting jumper cables.
x Jump-start batteries only in well-ventilated areas. Batteries give off highly explosive
hydrogen gas during jump-starting.
x Always route the jumper cables so that they cannot get caught in any moving parts in the
engine compartment.
x Never short out the battery terminals by connecting the positive (+) and negative (-)
terminals with each other.
x Never connect the negative cable from the other vehicle directly to the negative terminal
of the dead battery, as this may cause the hydrogen gas given off by the dead battery to
explode.
x Never attach the negative cable from the vehicle providing starting assistance to any part
of the fuel system or to the brake hoses or brake lines.
x Never allow the non-insulated parts of the battery clamps to touch.
x Never allow the jumper cable attached to the positive battery terminal to contact metal
parts of the vehicle.
x Always follow the instructions of the jumper cable manufacturer.
NOTICE
To help prevent extensive damage to the vehicle electrical system, read and heed the
following:
x Connecting jumper cables improperly can cause a short circuit and do expensive damage
to the vehicle's electrical system.
x Do not let the vehicles touch each other while the jumper cables are connected. If they do,
electrical current may flow between the vehicles when the positive (+) terminals are connected,
causing electrical system damage.
