2013 VOLKSWAGEN PASSAT CC Owners Manual

Removing the front head restraints
x Sit in the back seat behind the head restraint you want to remove. Pull the head restraint all the
way up ⇒  in Adjusting the front and rear head restraints. Recline the backrest so that there is
enough overhead clearance to remove it.
x Slide the head restraint all the way up and back.
x On each side of the seat, slide a flat object, such as a plastic credit card, between the seat
backrest and the cap of each head restraint rod guide ⇒ fig. 38 (1) to unlock the head restraint. Press
lightly at the same time to release the rods.
x Pull the head restraint all the way out.
Installing the front head restraints
x Pull both rods as far as possible out of the head restraint.
x Position head restraint properly over the head restraint guides of the respective seat backrest and
insert the head restraint into the guides.
x Push the head restraint down until both rods lock in place.
x Adjust the head restraint according to the occupant's size
Removing the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward .
x Pull the head restraint all the way up ⇒ .
x If necessary, press the flat blade of the screwdriver from the vehicle tool kit into the slit of the trim
cap ⇒ fig. 39 (1) in the direction of the arrow and hold it in this position.
x At the same time press button (2) while a second person pulls out the head restraint completely.
x Fold the backrest of the rear seat bench back so that it locks securely.
Reinstalling the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward.
x Position head restraint properly over the head restraint guides of the respective seat backrest and
insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Fold the backrest of the rear seat bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size .
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk
of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the
risk of neck injury in crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are
properly protected.
NOTICE
When removing or reinstalling the head restraint, take care that the head restraint does not
strike the headliner or other parts of the vehicle. The headliner or other parts of the vehicle
could otherwise be damaged.

Adjusting the steering wheel position

Fig. 40 Manual adjustment for the steering wheel position.

Center armrest

Fig. 41 Front center armrest.

Fig. 42 Folding down the rear center armrest with storage compartment (arrow).

WARNING
The center armrest can restrict the driver's arm movement and cause crashes and serious
personal injury.
x Always keep storage compartments in the center armrest closed while driving.
x Never let a passenger, especially a child, ride on the center armrest. Improper seating
position can increase the risk of serious personal injury in a crash.
x Never put hot drinks or other liquids in the cup holder. Hot liquids can spill when the
vehicle is moving as well as during braking or other sudden maneuvers.
NOTICE
Do not press on the cup holder cover when raising the rear center armrest. The cup holder
could open and be damaged.

Seat functions

x If there is a child restraint installed on the front passenger seat.
x If there is a blanket or seat cover on the front passenger seat.
x If the seat is damp or wet.
x If the outside temperature or the temperature inside the passenger compartment is 77 °F (25 °C) or
more.

Function Action for seat heating ⇒fig.43
Switch on: Press the Aor ebutton. Seat heating is switched on
to maximum.
Adjust the heating
level:
Press the A or e button repeatedly until the desired
heating level is set.
Switch off: Press the A or ebutton repeatedly until all indicator
lights in the button are off.

Special seat heating features
On the driver and the passenger side, the seat heating will resume at the setting that was set when the
ignition was switched off. However, this feature only works if the key is not taken out of the ignition
switch.
People suffering from a low level of perceived pain or a lowered awareness of pain as from
medication, paralysis, or chronic illness (e.g. diabetes) should NEVER use the seat heating feature
⇒ !
The use of seat heating by persons with these conditions could result in burns to the back, buttocks,
and legs that may take a long time to heal and may never heal completely. If you have any of these
conditions, you should take regular breaks and get out of the vehicle, particularly on long trips. Consult
your doctor for advice regarding your specific condition.
WARNING
Certain medical conditions, such as paralysis and diabetes, and certain medications can
increase the risk of serious burns when the seat heating feature is switched on.
x Vehicle occupants who have a low level of perceived pain or a lowered awareness of pain
can receive serious burns to the back, buttocks, and legs that take a long time to heal or may
never heal completely.
x Never use the seat heating feature if you or your passengers are at risk of being burned
because of a medical condition. Take regular breaks and get out of the vehicle, particularly
on long trips. Consult your doctor for advice regarding your specific condition.
x Never let exposed skin remain in contact with the seat upholstery when the seat heating is
being used.
WARNING
A wet seat can cause the seat heating to malfunction and increase the risk of serious burns.
x Always make sure the seats are dry before using the seat heating.
x Never sit on the seat with wet clothes.
x Never put damp or wet things including clothes on the seat.
x Never spill liquids on the seats.

NOTICE
x To help prevent damage to electrical and other parts in the seat, do not kneel on the front
seats or apply concentrated pressure to a small area of the seat or backrest.
x Liquids, sharp objects and things that do not let the heat in the seat escape into the air,
including, for example, a child restraint, a blanket, or seat covers on the seat can damage seat
heating.
x If you smell an odor, immediately shut off seat heating and have it checked by an authorized
Volkswagen dealer or authorized Volkswagen Service Facility.
x Never install leather upholstery on a vehicle with seat heating that originally had cloth
upholstery. The seat heating elements for seats with cloth seats will overheat if the cloth
upholstery is replaced with leather upholstery.
Switch off seat heating when it is not needed to help reduce unnecessary fuel consumption.
Applicable only in the United States
Ventilated seats

Fig. 44 On front seat: Switch for seat ventilation.

Setting the ventilation level
x Move the fan switch (2) all the way down toward the – symbol to set the ventilation level to low.
x Move the fan switch (2) to the middle position to set the ventilation level to medium.
x Move the fan switch (2) all the way up toward the + symbol to set the ventilation level to high.
If the indicator light in the front seat (3) flashes, there is a malfunction in the system. Have the system
inspected by your authorized Volkswagen dealer or authorized Volkswagen Service Facility.
You may hear the sound of the seat ventilation when the feature is switched on. The sound is
part of normal operation and not a cause for concern.
Memory seat

Fig. 45 On the outer side of the driver seat: Memory buttons.
