2013 VOLKSWAGEN PASSAT CC Owners Manual

Park Distance Control
Applicable only in the United States

x If you continue driving closer to an object that the Park Distance Control has already
detected and reported, the object may disappear from the sensor range and may no longer be
detected. This is especially true for low or high objects. The system will no longer sound
warnings about these objects. Ignoring signals from the Park Distance Control system could
result in serious damage to the vehicle.
x The sensors in the bumper can be damaged or become misaligned in low speed impacts
and parking maneuvers. Damaged or misaligned sensors cannot accurately detect or report
objects that might be within range of the PDC system.
x To help make sure that the system works properly, always keep the sensors in the bumpers
clean and free of snow and ice; do not cover the sensors with stickers or other objects.
x When cleaning the sensors with power washers or steam cleaners, only spray the sensors
directly for a very short time, and always keep the washer nozzle at least 4 inches (10 cm) from
the sensors.
x Noise from rough roads, cobblestones, other vehicles and the surrounding area, for
example, can prevent the Park Distance Control system from accurately detecting and
reporting people and objects that may be within range of the system sensors.
Volkswagen recommends practicing with the Park Distance Control system in a location or
parking space with no traffic in order to become familiar with the system and how it works.
applicable only in the United States
Park Distance Control (PDC)

Fig. 126 In the center console: Button to switch the Park Distance Control system on or off.

Fig. 127 Park Distance Control system sensors.

Rear Assist

WARNING
Rear Assist technology cannot overcome the laws of physics and the limits of the system.
Careless or unintentional use of Rear Assist may result in accidents and severe injuries.
x Always adjust your speed and driving style to road, traffic, weather, and visibility
conditions.
x Always keep an eye on the parking direction and the vehicle surroundings. The front of
the vehicle swings out more than the rear of the vehicle.
x Never pay so much attention to the graphics shown on the screen that you fail to notice
what is going on around you.
x Always watch for people, especially small children, animals, and objects, because the
camera may not always be able to detect them.
x The system may not be able to clearly show everything behind the vehicle.
x Use Rear Assist only when the luggage compartment lid is completely closed.
NOTICE
x The camera shows only two-dimensional images on the screen. Due to the lack of depth of
field, it may be difficult or impossible to identify protruding objects or recesses in the road, for
example.
x Things like thin rods, fences, posts, and trees may not be detected by the camera and could
damage the vehicle.
Operation instructions

Fig. 128 In the luggage compartment lid: Location of the Rear Assist camera.

Fig. 129 Display of the Rear Assist: Mode 2 activated.

1) Do not use Rear Assist in the following situations:
– If the driver is not familiar with the system.
– If the position or angle of the camera has changed, such as after a rear-end collision. Have the
system checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.


2) Examples of optical distortion by the camera:
The Rear Assist camera displays only two-dimensional images. Recesses and protruding objects on
the ground or protruding parts on other vehicles are difficult or impossible to identify due to the lack
of depth of field.
Objects or another vehicle may seem closer or farther away on the screen than they really are:
– When driving from a level surface onto an upward or downward slope.
– When driving up or down a slope onto a level surface.
– If the rear of the vehicle is heavily loaded.
– When approaching protruding objects. These objects can disappear from the field of view when
backing up.

Cleaning the camera lens
Keep the camera lens clean and free of snow and ice:
x Engage the parking brake.
x Switch on the ignition.
x Select the Reverse (R) gear.
x Wet the camera lens with a commercially available alcohol-based glass cleaner and clean with a
dry cloth ⇒ .
x Remove snow with a brush.
x Remove ice with deicer spray ⇒ .
NOTICE
x Never use abrasive cleaning agents to clean the camera lens.
x Never remove snow or ice on the camera lens with warm or hot water. This can damage the
camera lens.
Volkswagen recommends practicing parking with Rear Assist in a safe place with little or no
traffic or in a parking lot under good visibility and weather conditions in order to familiarize yourself
with the system, the orientation lines and the way they work.
Rear Assist does not work when the luggage compartment lid is open.

Perpendicular parking (Mode 1)

Fig. 130 On the screen: Orientation lines for the parking area behind the vehicle.
