Dispose of the wheel electronics and the old batteries in an environmentally responsible manner.
Batteries of the type used in the wheel electronics may contain Perchlorate Material. Special handling
may apply. See www.dtsc.ca.gov/hadardouswaste/perchlorate. Obey all applicable legal requirements
regarding proper disposal.
Do not rely only on the Tire Pressure Monitoring System. Check your tires regularly to make sure
they are properly inflated and have no signs of damage, such as punctures, cuts, cracks, and blisters.
Remove any objects that become embedded in the tire tread but have not penetrated into the body of
tire itself.
The Tire Pressure Monitoring System checks for the factory-recommended inflation pressure, as
shown on the label inside the driver door
x For replacement tires that require a different inflation pressure, the TPMS must be adjusted to the
new pressure specification by an authorized Volkswagen dealer or an authorized Volkswagen Service
Facility. Only one value can be entered for each tire; see the tire inflation pressure label on the driver
door pillar
x To help prevent damage to the sensor and valve, do not put excessive force on the valve when
checking the tire pressure. Do not try to bend the valve.
x If sensors have to be replaced, have the valves changed at the same time.
x The tire valve gaskets must be replaced whenever a tire is mounted on the rim. Your authorized
Volkswagen dealer or authorized Volkswagen Service Facility has a valve seal and gasket kit for this
purpose. Always make sure that a valve seal and gasket kit is also used whenever a sensor is
replaced.
x If you have to adjust the tire pressure on a “warm” tire, fill the tire with 2.0 - 4.35 psi (20 - 30 kPa)
more than the pressure specified on the tire pressure label.
x When the TPMS determines that the air pressure in at least one tire is too low, carefully check the
pressure in all 4 tires with an accurate tire pressure gauge. Low tire pressure usually cannot be
determined by looking at the tire. This is especially true of low-profile tires.
A Declaration of Compliance with the United States FCC and Industry Canada regulations is
found in the Consumer Information section of this Manual
There may be differences between the pressure readings from a tire pressure gauge and the
pressures registered by the Tire Pressure Monitoring System. The electronic TPMS is more accurate.
If you have work done on your wheels or tires, inform the workshop that the vehicle is equipped
with a Tire Pressure Monitoring System that has sensors in the wheels.
Applicable only in Canada

Your vehicle's Tire Pressure Monitoring System (TPMS) uses the Anti-lock Brake System (ABS)
sensors to indirectly check the tire pressure of all 4 tires while you are driving. The sensors monitor the
tread circumference (rolling circumference) and vibration characteristics of the individual tires. TPMS
warns if there is a significant loss of pressure in one or more tires while the vehicle is moving.
Pressure loss is signaled by the indicator light Ç (described below) as well as by text warnings in the
instrument cluster display if your vehicle has this display (Multi-Function Indicator- MFI).
The original benchmark pressure is the recommended maximum load cold tire inflation pressure for
the tires that come with your vehicle. This pressure is listed on the tire pressure label on the driver
door jamb. After adjusting the tire pressures in all 4 tires, you must confirm and store the new cold
inflation pressures using the Settings menu in the instrument cluster , which changes the
benchmark pressure to match the current pressure of the tires on your vehicle.
Recalibrating the TPMS to reset the benchmark cold tire inflation pressure is explained below
More information:
x Volkswagen Information System
x Transporting
x Braking, stopping and parking
x Exterior care and cleaning
x Tires and wheels
x Parts, accessories, repairs and modifications
x Consumer information

WARNING
Incorrect tire pressures and/or underinflation can cause sudden tire failure, loss of control,
collision, serious personal injury or even death.
x When the warning symbol appears in the instrument cluster, stop and inspect the tires.
x Incorrect tire pressure and/or underinflation can cause increased tire wear and can affect
the handling of the vehicle and stopping ability.
x Incorrect tire pressures and/or underinflation can also lead to sudden tire failure,
including a blowout and sudden deflation, causing loss of vehicle control.
x The driver is responsible for the correct tire pressures for all tires on the vehicle. The
recommended tire pressure values are listed on a sticker inside the driver door 272.
x The TPMS can only work correctly when all tires on the vehicle are filled to the correct
cold tire inflation pressure.
x Using incorrect tire pressure values can cause accidents or other damage. Always inflate
the tires to the correct specified cold tire pressure values for the tires installed on the vehicle.
x Always maintain correct cold tire inflation pressure so that TPMS can do its job.
x Always inflate tires to the recommended and correct tire pressure before driving off.
x Driving with underinflated tires causes them to flex (bend) more, letting them get too hot,
resulting in tread separation, sudden tire failure, and loss of control.
x Excessive speed and/overloading can cause heat build-up, sudden tire failure and loss of
control.
x If the tire pressure is too low or too high, the tires will wear prematurely and the vehicle
will not handle well.
x If the tire is not “flat” and you do not have to change a wheel immediately, drive carefully
and at reduced speed to the nearest service station to check the tire pressure and add air as
required.
x When replacing tires or wheel rims on vehicles equipped with TPMS always read and heed
the information and all WARNINGS regarding , Tires and wheels.
x The Tire Pressure Monitoring System must be recalibrated whenever you remove and
remount or change any wheel or tire on the vehicle, even if the reinstalled or replacement
wheels and tires are identical to those that were removed and even if the tire pressure does
not change .
WARNING
Improper recalibration can cause the TPMS to give false warnings or to give no warning
despite dangerously low tire pressure.
Underinflation increases fuel consumption and tire wear.
Do not rely solely on the Tire Pressure Monitoring System. Check your tires regularly to make
sure they are properly inflated and have no signs of damage, such as punctures, cuts, cracks, and
blisters. Remove any objects that become embedded in the tire tread but have not penetrated into the
body of tire itself.
When you take delivery of the vehicle, the Tire Pressure Monitoring System is calibrated for the
factory-recommended cold tire inflation pressure for the tires on your vehicle, as shown on the label
inside the driver door .

x The system must be recalibrated whenever you remove and remount or change any wheel or tire
on the vehicle, even if the reinstalled or replacement wheels and tires are identical to those that were
removed and even if the tire pressure does not change .
x If you have to adjust the tire pressure on a warm tire, fill the tire with 2.0 - 4.35 psi (20 - 30 kPa)
more than the pressure specified on the tire pressure label inside the driver door 272.
x If the TPMS determines that the air pressure in at least one tire is too low, carefully check the
pressure in all 4 tires with an accurate tire pressure gauge. Low tire pressure usually cannot be
determined by looking at the tire. This is especially true of low-profile tires.
If you have work done on your wheels or tires, inform the workshop that the vehicle is equipped
with a Tire Pressure Monitoring System (TPMS).
New tires may expand slightly the first time they are driven at high speeds, which can trigger a
tire pressure warning. Remember that tire pressure can only be properly measured when the tire is
“cold” .
Only replace old tires with tires that have been approved by Volkswagen for your vehicle type.
Applicable only in the United States
Indicator light (telltale)

Flashes Display text Possible cause or meaning
⇒ 
Proper response
Ç – There is a malfunction
between a sensor and the
system. The function can be
temporarily disrupted by
interference from transmitters
in the vicinity of the vehicle
working in the same
frequency range such as radio
equipment, remote controls or
children's toys.
Switch the source of interference off.
(Intermittently
while
driving.)

WARNING
Incorrect tire pressures and/or underinflation can cause sudden tire failure, loss of control,
collision, serious personal injury, or even death.
x When the warning symbol Ç appears in the instrument cluster, stop the vehicle as soon as
it is safe to do so and inspect all tires.
x Incorrect tire pressure and/or underinflation can cause increased tire wear and can affect
the handling of the vehicle and its stopping ability.
x Incorrect tire pressure and/or underinflation can also lead to sudden tire failure, including
a blowout and sudden deflation, causing loss of vehicle control.
x The driver is responsible for the correct tire pressures for all tires on the vehicle. The
recommended tire pressure values are listed on a sticker inside the driver's door
x The TPMS can only work correctly when all tires on the vehicle are filled to the correct
cold tire inflation pressure. Always maintain the correct cold tire inflation pressure so that
TPMS can do its job.
x Using incorrect tire pressure values can cause accidents or other damage. Check the
pressure in all 4 tires when the tires are still cold. Never reduce air pressure in warm tires to
match cold tire inflation pressure.
x Always inflate the tires to the correct specified cold tire pressure values for the tires
installed of the vehicle; see the tire inflation pressure label on the driver door jamb .
x Always inflate tires to the recommended and correct tire pressure before driving off.
x Driving with underinflated tires causes them to flex (bend) more, letting them get too hot,
which can result in tread separation, sudden tire failure, and loss of control.
x Excessive speed and/or overloading can cause heat build-up, sudden tire failure, and loss
of control.
x If the tire pressure is too low or too high, the tires will wear prematurely and the vehicle
will not handle well.
x If the tire is not “flat” and you do not have to change the tire or wheel immediately, drive at
reduced speed to the nearest service station to check the tire pressure and add air as
required.
x When replacing tires or wheel rims on vehicles equipped with TPMS, always read and
heed the information and all WARNINGS in the section, Tires and wheels.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Applicable only in Canada
Indicator light (telltale)

Lights up Possible cause or meaning ⇒  Proper response

WARNING
Incorrect tire pressures and/or underinflation can cause sudden tire failure, loss of control,
collision, serious personal injury, or even death.
x When the warning symbol Ç appears in the instrument cluster, stop the vehicle as soon as
it is safe to do so and inspect all tires.
x Incorrect tire pressure and/or underinflation can cause increased tire wear and can affect
the handling of the vehicle and its stopping ability.
x Incorrect tire pressure and/or underinflation can also lead to sudden tire failure, including
a blowout and sudden deflation, causing loss of vehicle control.
x The driver is responsible for the correct tire pressures for all tires on the vehicle. The
recommended tire pressure values are listed on a sticker inside the driver door.
x The TPMS can only work correctly when all tires on the vehicle are filled to the correct
cold tire inflation pressure. Always maintain the correct cold tire inflation pressure so that
TPMS can do its job.
x Using incorrect tire pressure values can cause accidents or other damage. Check the
pressure in all 4 tires when the tires are still cold. Never reduce air pressure in warm tires to
match cold tire inflation pressure.
x Always inflate the tires to the correct specified cold tire pressure values for the tires
installed on the vehicle; see the tire inflation pressure label on the driver door jamb Tires and
wheels.
x Always inflate tires to the recommended and correct tire pressure before driving off.
x Driving with underinflated tires causes them to flex (bend) more, letting them get too hot,
which can result in tread separation, sudden tire failure, and loss of control.
x Excessive speed and/or overloading can cause heat build-up, sudden tire failure, and loss
of control.
x If the tire pressure is too low or too high, the tires will wear prematurely and the vehicle
will not handle well.
x If the tire is not “flat” and you do not have to change the tire or wheel immediately, drive at
reduced speed to the nearest service station to check the tire pressure and add air as
required.
x When replacing tires or wheel rims on vehicles equipped with TPMS, always read and
heed the information and all WARNINGS in the section 267, Tires and wheels.
x The Tire Pressure Monitoring System must be recalibrated whenever you remove and
remount or change any wheel or tire on the vehicle, even if the reinstalled or replacement
wheels and tires are identical to those that were removed and even if the tire pressure does
not change
WARNING
Improper recalibration can cause the TPMS to give false warnings or to give no warning
despite dangerously low tire pressure
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
