2013 VOLKSWAGEN PASSAT CC Owners Manual

Fig. 15 Vehicle identification number (VIN).

Maximum power
output (SAE net)
Injection
technology
Engine
code
Maximum torque No. of cylinders
Displacement
200 hp at 5100 –
6000 rpm
147 kW at 5100 –
6000 rpm
TSI® CCTA
CBFA
2.0T
207 lb-ft at 1700 – 5000 rpm
280 Nm at 1700 – 5000 rpm
4 cylinders
121 CID
1984 ccm
280 hp at 6200 rpm
206 kW at 6200 rpm
FSI®
3.6L
CNNA
3.6L
265 lb-ft at 2750 rpm
360 Nm at 2750 rpm
6 cylinders
219 CID
3597 ccm

Dimensions

Vehicle key set

Remote control vehicle keys

Fig. 16 Remote control vehicle key with panic button.

Do not press the buttons on the remote control vehicle key unless you actually want to use the
function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle
key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you
are out of range.
Remote control vehicle key functions can be temporarily disrupted by interference from transmit-
ters near the vehicle that use the same frequency range (such as radio equipment or cellular phones).
Things between the remote control vehicle key and vehicle, bad weather, as well as a weak
battery can reduce the operating range.
If the remote control vehicle key buttons 47 or the power locking buttons 48 are pushed re-
peatedly in quick succession, the power locking system is switched off for a brief period to help keep it
from being overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the
luggage compartment lid is opened in this span of time, the vehicle is automatically locked afterwards.
Emergency key

Fig. 17 Remote control vehicle key (side view): Press the button 1 and remove emergency key 3 by the eyelet
2.

x Locking and unlocking the glove compartment on the passenger side
x Locking and unlocking the luggage compartment pass-through
x Locking and unlocking the luggage compartment lid using the key switch in the driver door
x Manually locking and unlocking the vehicle
Reinserting the emergency key
Insert the emergency key (3) into the opening in the remote control vehicle key.
Slide the emergency key in the direction opposite to the arrow until it locks into place.
Indicator light in the remote control vehicle key

Fig. 18 Indicator light in the remote control vehicle key.

x Switch the ignition on with the remote control vehicle key. The synchronization is complete.
x Insert the emergency key into the vehicle key.
x Reinstall the cap.
