2013 DACIA SANDERO Owners Manual

children .................................................(up to the end of the DU)doors.....................................................(up to the end of the DU)electric door locking ..............................(up to the end of the DU)central door locking ..............................(up to the end of the DU)
1.5
ENG_UD5543_1Verrouillage des portes (B90 - Dacia)ENG_NU_817-2_NU_Dacia_1
LOCKING THE DOORS
Manual locking
Front: use the key if outside or, if inside,
press down knob 1 when the door is closed.
Rear: press down button 1 in each door.
Electric central locking
Depending on the vehicle, this is used to simultaneously lock the four doors and luggage compartment.
Press the bottom of switch
2 to lock.
The front door mechanism cannot be locked if the door is open.
Childproof locks
To make it impossible for the rear doors to be opened from the inside, move
lever 3 on each door and check from the inside that the doors are securely locked.
If you decide to keep the doors locked when you are driving, remember that it may be more difficult for those assisting you to gain access to the passenger compartment in the event of an emergency.
3
21

1.6
ENG_UD5544_1condamnation automatique des ouvrants en roulage (B90 - Dacia)ENG_NU_817-2_NU_Dacia_1
Condamnation automatique des ouvrants en roulage
You must first decide if you want to activate this function.
To activate
Depending on the vehicle, with the ignition on or the engine running, press and hold central door locking but-
ton 1 for approximately 5 seconds, until you hear a beep.
To deactivate
Depending on the vehicle, with the ignition on or the engine running, press and hold central door locking but-
ton 1 for approximately 5 seconds, until you hear a beep.
Operating principle
When the vehicle is started, the system automatically locks the doors as soon as a speed of 4 mph (7 km/h) is reached.
The door can be unlocked:
– by pressing the door unlocking but
-
ton 1.
– by opening a front door (vehicle sta
- tionary).
Note: if a door is opened, it will auto- matically lock again when the vehicle reaches approximately 4 mph (7 km/h).
Operating faults
If you notice an operating fault (no au- tomatic locking) first check that all of the doors and tailgate are closed. If they are properly closed, contact an ap- proved Dealer.
AUTOMATIC LOCKING wHEN DRIvING
If you decide to keep the doors locked when you are driving, remember that it may be more difficult for those assisting you to gain access to the passenger compartment in
the event of an emergency.
1

engine immobiliser................................(up to the end of the DU)engine immobiliser................................(up to the end of the DU)
1.7
ENG_UD5545_1Système antidémarrage (B90 - Dacia)ENG_NU_817-2_NU_Dacia_1
Système antidémarrage
ENGINE IMMOBILISER
This prevents the vehicle being driven by anyone not in possession of the vehicle’s coded ignition key.
Operating principle
The vehicle is automatically protected a few seconds after the ignition is switched off.
If the vehicle does not recognise the
coded ignition key, tell-tale light 1 will flash continuously and the engine cannot be started.
Any unauthorised work carried out on the engine immobiliser (computers, wiring, etc.) could be dan- gerous. Work must be carried out by qualified personnel.
Indicator light
System operating tell-tale light
When the ignition is switched on, tell-
tale 1 lights up continuously for approx- imately three seconds and then goes out. The vehicle has recognised the code. You can then start the engine. v
ehicle protection tell-tale light
A few seconds after the ignition has
been switched off, tell-tale light 1 will flash constantly.
The vehicle will only be protected after the ignition has been switched off.
Operating fault warning light
After the ignition has been switched
on, if warning light 1 continues to flash or remains continuously lit, there is a system operating fault.
In all cases, it is essential to contact an approved dealer as only they are qual- ified to repair the engine immobiliser.
If the coded ignition key is faulty, use the second key (supplied with the vehicle).
1

headrest................................................(up to the end of the DU)
1.8
ENG_UD8366_2Appuis-tête avant (B90 - L90 Ph2 - Dacia)ENG_NU_817-2_NU_Dacia_1
Headrests - Seats
FRONT HEADRESTS
To adjust the height
Press tab
1 and simultaneously slide the headrest to the required position.
To remove the headrest
Depending on the vehicle, press tabs
1
and 2 on the head restraint guides or
on button 3 and lift the headrest to re- lease it (tilt the seatback backwards if necessary).
To refit the headrest
Insert the rods into the sleeves, with the notches facing forwards, and lower the headrest to the desired height.
The headrest is a safety component. Ensure that it is fitted and in the correct po- sition: the top of your head should be in line with the top of the headrest.
1
2
Depending on the vehicle, insert the
headrest rods 4 into the holes (tilt the seatback backwards if necessary). Push the headrest in until it locks in po- sition.
3
4

headrest................................................(up to the end of the DU)adjusting your driving position ..............(up to the end of the DU)
1.9
ENG_UD6896_1Appuis-tête arrière (B90 - Dacia)ENG_NU_817-2_NU_Dacia_1
REAR HEADRESTS
Positions for use
Press tab A of lock 1 and raise the headrest to its maximum height to use it in the high position. Lower it until it locks to use it in the bottom position.
Storage position
Press catch 2 and lower the headrest completely.
when the headrest is set at the
lowest position, this is for storage only. It should not be in this position when a seat is occupied.
To remove the headrest
Press tab A on catches 1 and 2 then take out the headrest.
To refit the headrest
Insert the rods into the holes, press the tabs on both rods and lower the head- rest.
The headrest is a safety component, check that it is fitted and in the correct po- sition.
1
A
2

front seat adjustment ............................(up to the end of the DU)front seatsadjustment ......................................(up to the end of the DU)
1.10
ENG_UD8376_2Sièges avant (B90 - Dacia)ENG_NU_817-2_NU_Dacia_1
FRONT SEATS
To move forwards or
backwards(depending on vehicle)
Lift bar
1 or handle 4 to release. Once in the desired position, release the bar or handle and ensure it is correctly locked.
To raise or lower the driver’s
seat surface
Depending on the vehicle, move
lever 2.
Heated seats
With the ignition on, press switch 3.
For safety reasons, carry out any adjustments when the vehicle is not being driven.
We would advise you not to recline the seatbacks too far to ensure that the effectiveness of the seat belts is not reduced.
Make sure that the seatbacks are correctly locked in place.
Nothing should be placed on the floor (area in front of driver) as such objects may slide under the pedal during braking manoeuvres, thus obstructing its use.
1
23
The system, which has a thermostat, decides whether or not the heating is needed.
To tilt the seatback
Move handle 5 and tilt the seatback to the desired position.
To adjust the lumbar support
on the driver’s seat(depending on vehicle)
Turn control knob
6.
4
6
5
2

adjusting your driving position ..............(up to the end of the DU)seat belts ..............................................(up to the end of the DU)
1.11
ENG_UD5460_1Ceintures de sécurité (U90 - Dacia)ENG_NU_817-2_NU_Dacia_1
Ceintures de sécurité
SEAT BELTS
Always wear your seat belt when trav- elling in your vehicle. You must also comply with the legislation of the par- ticular country you are in.
Before starting:
– first ensure that your driving posi
- tion is correctly adjusted,
– then adjust your seat belt to pro
- vide maximum protection.
Incorrectly adjusted seat- belts may cause injuries inthe event of an accident.The seatbelt is for the use of one person only, whether adult or child. Even pregnant women should wear a seat belt.If this is the case, ensure that the lap belt is not exerting too much pressure on the abdomen but do not allow any slack.
Adjusting your driving
position
– Sit well back in your seat (having first removed your coat or jacket).
This is essential to ensure your back is positioned correctly.
– Adjust the distance between the
seat and the pedals.
Your seat should be as far back as possible while still allowing you to depress the clutch pedal fully. The
seatback should be adjusted so that your arms are slightly bent when you hold the steering wheel.
– Adjust the position of your head
- rest.
For safety reasons, the top of your head should be in line with the top of the headrest.
– Adjust the height of the seat.
This adjustment allows you to select the seat position which offers you the best possible view.
Adjusting the seat belts
Sit with your back firmly against the seatback.
Shoulder strap
1 should be as close as possible to the base of the neck but not on it.
The lap strap
2 should be worn flat over the thighs and against the pelvis.
The belt should be worn so that it is as close as possible to your body, i.e. avoid wearing heavy clothing or keep- ing bulky objects under the belts.
1
2

seat belts ..............................................(up to the end of the DU)adjusting your driving position ..............(up to the end of the DU)
1.12
ENG_UD8378_2Ceintures de sécurité avant (B90 - Dacia)ENG_NU_817-2_NU_Dacia_1
FRONT SEAT BELTS
If your seat belt becomes completely jammed:
– pull the belt slowly but firmly so that
just over 3 cm unwinds;
– then allow the seat belt to rewind au
- tomatically;
– unwind it again;
– if there is still a problem, contact your
approved dealer.
çSeat belt reminder
light
Depending on the country, it comes on when the engine is started if the driv- er ’s seat belt is not fastened. When the vehicle is being driven, it comes on and a bleep sounds for approximately 2 minutes until the driver’s seat belt is fastened.
Unlocking
Press button 4 on catch 5 and the seat belt will be rewound by the inertia reel.
Guide the buckle to help the operation.
Adjusting the height
of the seat belt
Move button 1 to select the position you
require so that shoulder strap 2 is worn as described above.
Make sure that the seat belt is locked in position correctly after you have ad- justed it.
3
2
5
4
5
To fasten
Unwind the belt slowly and smoothly
and ensure that buckle 3 locks into
catch 5 (check that it is locked by pull-
ing on buckle 3). If the belt jams, allow it to return slightly before attempting to unwind it again.
1
