2010 TOYOTA PRIUS Owners Manual

321
3-2. Using the audio system
3
Interior features
PRIUS_U (OM47668U) U.S.A.
■
Adjusting the Automatic Sound Levelizer (ASL)
Type A
When “ASL” is selected, turning to the right turns ASL on,
and turning to the left turns ASL off.
ASL automatically adjusts the volume and tone quality according to the
noise level as you drive your vehicle.
Type B
When “ASL” is selected, turni ng to the right changes the
ASL level in the order of “LOW” , “MID” and “HIGH”.
Turning to the left turns off the ASL.
ASL automatically adjusts the volume and tone quality according to vehi-
cle speed.

322
3-2. Using the audio system
PRIUS_U (OM47668U) U.S.A.
Using the AUX adapter
: If equipped
■Operating portable audio devices connected to the audio system
The volume can be adjusted using the vehicle’s audio controls. All other
adjustments must be made on the portable audio device itself.
■ When using a portable audio device connected to the power outlet
Noise may occur during playback. Use the power source of the portable
audio device.
This adapter can be used to connect a portable audio device and lis-
ten to it through the vehicle’s speakers.
Connect the portable audio
device.
Press .
ITO32P109
STEP1
ITO32P106
STEP2

323
3-2. Using the audio system
3
Interior features
PRIUS_U (OM47668U) U.S.A.
Using the steering switches
Turning on the powerPress when the audio system is turned off.
The audio system can be turned off by holding the switch down for 1 sec-
ond or more.
Changing the audio sourcePress when the audio system is turned on. The audio source
changes as follows each time the bu tton is pressed. If a CD is not
inserted, that mode will be skipped.
FM (1, 2) CD player AM SAT (1, 2, 3)
Some audio features can be cont rolled using the switches on the
steering wheel.
Vo l u m e
Power on, select audio
source
Radio: Select radio stations
CD: Select tracks, discs and folder
ITO32P108

324 3-2. Using the audio system
PRIUS_U (OM47668U) U.S.A.
Adjusting the volumePress “+” on to increase the volume and “-” to decrease the
volume.
Hold down the button to continue increasing or decreasing the volume.
Selecting a radio station Press to select the radio mode.
Press or  on to select a radio station.
To scan for receivable stations, press and hold the switch until you
hear a beep.
Selecting a track
Press to select the CD mode.
Press  or  on to select the desired track.
Selecting a disc or folder in th e CD player (Folder selection is
available only when MP3/WMA disc is in use.)
Press to select the CD player.
Press and hold  or  on until you hear a beep.
STEP1
STEP2
STEP1
STEP2
STEP1
STEP2

325
3-2. Using the audio system
3
Interior features
PRIUS_U (OM47668U) U.S.A.
■
Canceling automatic selection of a radio station
Push the same switch.
■ When operating the steering switches
On vehicles with touch tracer display, the steering switches operation status
is displayed on the instrument cluster for confirmation purposes. ( P. 182)
CAUTION
■To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.

326
PRIUS_U (OM47668U) U.S.A.
3-3. Using the hands-free system (for cellular phone)
Hands-free system (for cellular phone)
: If equipped
■Conditions affecting operation
The hands-free phone system may not operate normally in the following situ-
ations:
● The cellular phone is turned off, or located outside the service area.
● The cellular phone has a low battery.
● The cellular phone is not connected to the system.
● The cellular phone is behind the seat or in the glove box, or metal mate-
rial covers or touches the phone.
With navigation system
Owners of models equipped with a navigation system should
refer to the “Navigation System Owner’s Manual”.
Without navig ation system
This system supports Bluetooth
®, which allows you to make or
receive calls without using cables to connect a cellular phone
and the system, and without operating the cellular phone.
TitlePage
Using the hands-free systemP. 329
Making a phone callP. 338
Setting a cellular phoneP. 344
Security and system setupP. 350
Using the phone bookP. 354

327
3-3. Using the hands-free
system (for cellular phone)
3
Interior features
PRIUS_U (OM47668U) U.S.A.
■When transferring ownership of the vehicle
Be sure to initialize the system to prevent the personal data from being
improperly accessed.
■ About Bluetooth
®
■Compatible models
Compatible with HFP (Hands Free Profile) Ver. 1.0 and OPP (Object Push
Profile) Ver. 1.1.
If your cellular phone does not support HFP, you cannot enter the Bluetooth
®
phone, and take OPP service individually.
■ Certification for the hands-free system
FCC ID: ACJ932C5ZZZ035 
IC ID: 216J-C5ZZZ035 
NOTE: 
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC WARNING: 
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Bluetooth is a registered trademark of
Bluetooth SIG. Inc.

328 3-3. Using the hands-free system (for cellular phone)
PRIUS_U (OM47668U) U.S.A.
CAUTION
■While driving
Do not use a cellular phone, or connect the Bluetooth
® phone.
NOTICE
■To prevent damage to a cellular phone
Do not leave a cellular phone in the vehicle. The temperature inside may
become high resulting in damage to the phone.
