4-3. Do-it-yourself maintenance
4
Maintenance and care
PRIUS_U (OM47668U) U.S.A.
Vehicles with halogen headlights
■ Rear bulb locations
ITO43P13R
Headlight low beam
Front turn 
signal light
Headlight 
high beam
Parking light
Front side marker light
ITO43P138
Rear turn signal light Back-up lightLicense plate lights

474 4-3. Do-it-yourself maintenance
PRIUS_U (OM47668U) U.S.A.
Replacing light bulbs■ Headlight low beams (halogen bulbs)
For the right side only: 
Remove the bolt and unclip the
engine coolant reservoir hose.
Then lift up the air cleaner inlet
duct.
Turn the bulb base counterclock-
wise.
STEP1
ITO43P162
STEP2

475
4-3. Do-it-yourself maintenance
4
Maintenance and care
PRIUS_U (OM47668U) U.S.A.
Unplug the connector while
pushing the lock release.
ITO43P163
STEP3

476 4-3. Do-it-yourself maintenance
PRIUS_U (OM47668U) U.S.A.■
Headlight high beams
For the right side only: Remove the bolt and unclip the engine
coolant reservoir hose. Then lift up the air cleaner inlet duct.
( P. 474)
Turn the bulb base counterclockwise.
Vehicles with LED headlights
Vehicles with halogen headlights
Unplug the connector while
pushing the lock release.
STEP1
STEP2
ITO43P185
ITO43P164
ITO43P165
STEP3

477
4-3. Do-it-yourself maintenance
4
Maintenance and care
PRIUS_U (OM47668U) U.S.A.
■
Parking lights
For the right side only: Remove the bolt and unclip the engine
coolant reservoir hose. Then lift up the air cleaner inlet duct.
( P. 474)
Turn the bulb base counterclockwise.
Vehicles with LED headlights
Vehicles with halogen headlights
Remove the light bulb.
STEP1
STEP2
ITO43P186
ITO43P166
ITO43P167
STEP3

478 4-3. Do-it-yourself maintenance
PRIUS_U (OM47668U) U.S.A.■
Front side marker lights
For the right side only: Remove the bolt and unclip the engine
coolant reservoir hose. Then lift up the air cleaner inlet duct.
( P. 474)
Turn the bulb base counterclockwise.
Vehicles with LED headlights
Vehicles with halogen headlights
Remove the light bulb.
STEP1
STEP2
ITO43P187
ITO43P167
STEP3

479
4-3. Do-it-yourself maintenance
4
Maintenance and care
PRIUS_U (OM47668U) U.S.A.
■
Front fog lights (vehicles with LED headlights)
Remove the engine under cover
bolt and clip and pull down the
engine under cover.
Unplug the connector while
pushing the lock release.
Turn the bulb base counterclock-
wise.
ITO43P140
STEP1
ITO43P141
STEP2
ITO43P142
STEP3

480 4-3. Do-it-yourself maintenance
PRIUS_U (OM47668U) U.S.A.■
Front turn signal lights
Remove the engine under cover bolt and clip and pull down
the engine under cover. ( P. 479)
Unplug the connector while
pushing the lock release.
Remove the light bulb.
STEP1
ITO43P143
STEP2
ITO43P144
STEP3
