2010 TOYOTA PRIUS Owners Manual

81
1-4. Adjustable components (s
eats, mirrors, steering wheel)
1
Before driving
PRIUS_U (OM47668U) U.S.A.
CAUTION
■Before folding down a rear seat
Do not fold down a rear seat when there are passengers sitting in the rear
seats or when there is luggage placed on the rear seats.
■ After returning the seatback to the upright position
Observe the following precaution. Failure to do so may result in death or
serious injury.
● Check that the seat belts are not twisted or caught under the seat.
● Make sure the seatbacks are securely locked by lightly rocking it back and
forth.

82
1-4. Adjustable components (seats, mirrors, steering wheel)
PRIUS_U (OM47668U) U.S.A.
Head restraints
Head restraints are provided for all seats.
Front seatsVertical adjustment
Up
Pull the head restraints up.
Down
Push and hold the lock release
button when lowering the head
restraint.
Rear center seat Vertical adjustment
Up
Down
Push the head restraint up or
down while pressing the lock
release button.
Rear outboard seats (foldable type only) To f o l d
Push the head restraint up
while pressing the lock release
button.
To u s e
Lift up and push down the
head restraint to the lowest
lock position.
Lock
release
button
Lock
release
button
Lock release button

83
1-4. Adjustable components (s
eats, mirrors, steering wheel)
1
Before driving
PRIUS_U (OM47668U) U.S.A.
■Adjusting the height of the head restraints
■ Adjusting the rear cent er seat head restraint
Always raise the head restraint one level from the stowed position when using.
■ Removing the head restraints
Front and rear center seats
Rear outboard seats (foldable type)
Rear outboard seats (non-foldable type)
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.
Pull the head restraint up while pressing
the lock release button.
Pull the head restraint up while pressing
the lock release buttons.
Pull the head restraint up while pressing
the lock release button.

84 1-4. Adjustable components (seats, mirrors, steering wheel)
PRIUS_U (OM47668U) U.S.A.
■Installing the head restraints
Front and rear center seats
Rear outboard seats
CAUTION
■Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
● Use the head restraints designed for each respective seat.
● Adjust the head restraints to the correct position at all times.
● After adjusting the head restraints, push down on them and make sure
they are locked in position.
● Do not drive with the head restraints removed.
Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.
Align the head restraint with the installa-
tion holes and push it down to the lowest
lock position.

85
1
1-4. Adjustable components (seats, mirrors, steering wheel)
Before driving
PRIUS_U (OM47668U) U.S.A.
Seat belts
Make sure that all occupants are wearing their seat belts before driv-
ing the vehicle.
■Correct use of the seat belts
Extend the shoulder belt so
that it comes fully over the
shoulder, but does not
come into contact with the
neck or slide off the shoul-
der.
Position the lap belt as low
as possible over the hips.
Adjust the position of the
seatback. Sit up straight
and well back in the seat.
Do not twist the seat belt.
■ Fastening and releasing the seat belt
Fastening the belt
Push the tab into the buckle
until a clicking sound is heard.
Releasing the belt
Press the release button.
Release 
button

86 1-4. Adjustable components (seats, mirrors, steering wheel)
PRIUS_U (OM47668U) U.S.A.
Seat belt pretensioners (front seats)
The pretensioner helps the seat
belt to quickly restrain the occu-
pant by retracting the seat belt
when the vehicle is subjected to
certain types of severe frontal
collision.
The pretensioner may not acti-
vate in the event of a minor frontal
impact, a side impact or a rear
impact.
Pre-collision seat belts (front seats of vehicles with pre-collision
system)If the pre-collision sens or detects that a collision is unavoidable, the
pre-collision system will retract the seat be lt, thus enhancing the
effectiveness of the seat be lt pretensioner in a crash.
The same will happen if the driver makes an emergency braking or loses
control of the vehicle. (P. 249)
■Adjusting the height of the belt (front seats)
Down
Up
Move the height adjuster up
and down as needed until you
hear a click.

87
1-4. Adjustable components (s
eats, mirrors, steering wheel)
1
Before driving
PRIUS_U (OM47668U) U.S.A.
■Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on impact. It may also
lock if you lean forward too quickly. A slow, easy motion will allow the belt to
extend so that you can move around fully.
■ Automatic locking retractor (ALR)
When a passenger’s shoulder belt is completely extended and then
retracted even slightly, the belt is locked in that position and cannot be
extended. This feature is used to hold the child restraint system (CRS) firmly.
To free the belt again, fully retract the belt and then pull the belt out once
more. ( P. 137)
■ Pregnant women
Obtain medical advice and wear the seat
belt in the proper way. ( P. 85)
Women who are pregnant should position
the lap belt as low as possible over the
hips in the same manner as other occu-
pants. Extend the shoulder belt com-
pletely over the shoulder and position the
belt across the chest. Avoid belt contact
over the rounding of the abdominal area.
If the seat belt is not worn properly, not
only a pregnant woman, but also the fetus
could suffer death or serious injury as a
result of sudden braking or a collision.

88 1-4. Adjustable components (seats, mirrors, steering wheel)
PRIUS_U (OM47668U) U.S.A.
■People suffering illness
Obtain medical advice and wear the seat belt in the proper way.
■ Child seat belt usage
The seat belts of your vehicle were principally designed for persons of adult
size.
● Use a child restraint system appropriately for the child, until the child
becomes large enough to properly wear the vehicle’s seat belt. ( P. 132)
● When the child becomes large enough to properly wear the vehicle’s
seat belt, follow the instructions on P. 85 regarding seat belt usage.
■ Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will activate
for the first collision, but will not activate for the second or subsequent colli-
sions.
■ Seat belt extender
If your seat belts cannot be fastened
securely because they are not long
enough, a personalized seat belt
extender is available from your Toyota
dealer free of charge.
