2010 TOYOTA PRIUS Owners Manual

249
2-4. Using other driving systems
2
When driving
PRIUS_U (OM47668U) U.S.A.
Pre-Collision System
: If equipped
Safety systems such as the brakes and seat belts are automati-
cally engaged to lessen impact and in juries to occupants as well as
vehicle damage when the radar sensor detects an unavoidable
frontal collision.
■ Pre-collision seat belts
If the pre-collision s ensor detects that a co llision is unavoidable,
the pre-collision system will retract the seat belt before the colli-
sion occurs. 
The same will happen if the driver makes an emergency braking
or loses control of the vehicle. ( P. 8 6 )
■ Pre-collision brake assist
When there is a high possibility of a frontal collision, the system
applies greater braking force in relation to how strongly the
brake pedal is depressed.
■ Pre-collision braking
When there is a high possibility of a frontal collision, the system
warns the driver using a warning light, warning display and
buzzer. If the system determines that a collision is unavoidable,
the brakes are auto matically applied to reduce the collision
speed. Pre-collision braking can be disabled using the pre-colli-
sion braking off button.

250 2-4. Using other driving systems
PRIUS_U (OM47668U) U.S.A.
Disabling pre-collision brakingEnabled
Disabled
The “PCS” warning light comes
on when the pre-collision braking
is disabled.
Radar sensorDetects vehicles or other obsta-
cles on or near the road ahead
and determines whether a colli-
sion is imminent based on the
position, speed, and heading of
the obstacles.
ITO24P116
ITO24P131

251
2-4. Using other
driving systems
2
When driving
PRIUS_U (OM47668U) U.S.A.
■Obstacles not detected
The sensor cannot detect plastic obstacles such as pylons. There may also
be occasions when the radar sensor cannot detect pedestrians, animals,
bicycles, motorcycles, trees, or snowdrifts.
■ The pre-collision system is operational when
● Pre-collision seat belts:
• Vehicle speed is above 3 mph (5 km/h).
• The relative speed difference between your vehicle and another vehi-
cle that is ahead of your vehicle, or the speed at which your vehicle is
approaching an obstacle is greater than 18 mph (30 km/h).
• The front occupants are wearing a seat belt.
● Pre-collision brake assist:
• Vehicle speed is above 18 mph (30 km/h).
• The relative speed difference between your vehicle and another vehi-
cle that is ahead of your vehicle, or the speed at which your vehicle is
approaching an obstacle is greater than 18 mph (30 km/h).
• The brake pedal is depressed.
● Pre-collision braking:
• The pre-collision braking off button is not pressed.
• Vehicle speed is above 9 mph (15 km/h).
• The relative speed difference between your vehicle and another vehi-
cle that is ahead of your vehicle, or the speed at which your vehicle is
approaching an obstacle is greater than 9 mph (15 km/h).

252 2-4. Using other driving systems
PRIUS_U (OM47668U) U.S.A.
■Conditions that may trigger the system even if there is no danger of
collision
● When there is an object by the roadside at the entrance to a curve
● When passing an oncoming vehicle on a curve
● When driving over a narrow iron bridge
● When there is a metal object on the road surface
● When driving on an uneven road surface
● When passing an oncoming vehicle on a left-turn
● When your vehicle rapidly closes on the vehicle in front
When the system is activated in the situations described above there is also
a possibility that the seat belts will retract quickly and the brakes will be
applied with a force greater than normal. When the seat belt is locked in the
restricted position, stop the vehicle in a safe place, release the seat belt and
refasten.
■ When there is a malfunction in the system
Warning lights and/or warning messages will turn on or flash. ( P. 508)

253
2-4. Using other
driving systems
2
When driving
PRIUS_U (OM47668U) U.S.A.
■Certification
For vehicles sold in the U.S.A.
FCC ID: HYQDNMWR004
FCC WARNING 
Changes or modifications not expressly approved by the party responsi-
ble for compliance could void the user’s authority to operate the equip-
ment.
FCC RF exposure Information 
This device complies with the FCC RF exposure requirements.
This device complies with Part 15 of the FCC Rules and RSS-210. Oper-
ation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interfer-
ence received, including interference that may cause undesired opera-
tion.
For vehicles sold in Canada
Operation is subject to the following two conditions: (1) this device may
not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.

254 2-4. Using other driving systems
PRIUS_U (OM47668U) U.S.A.
CAUTION
■Handling the radar sensor
Observe the following to ensure the pre-collision system can function effec-
tively.
● Keep the sensor and grille cover clean at all time. 
Clean the sensor and grille cover with a soft cloth so you do not mark or
damage them.
● Do not subject the sensor or surrounding area to a strong impact. 
If the sensor moves even slightly off position, the system may malfunction.
If the sensor or surrounding area is subject to a strong impact, always
have the area inspected and adjusted by your Toyota dealer.
● Do not disassemble the sensor.
● Do not attach accessories or stickers to the sensor, grille cover or sur-
rounding area.
● Do not modify or paint the sensor and grille cover.
■ Limitations of the pre-collision system
Do not rely on the pre-collision system. Always drive safely, taking care to
observe your surroundings and checking for any obstacles or other road
hazards.

255
2
When driving
PRIUS_U (OM47668U) U.S.A.
2-5. Driving information
Cargo and luggage
Take notice of the following information about storage precau-
tions, cargo capacity and load.
●Stow cargo and luggage in the luggage compartment when-
ever possible. Be sure all items are secured in place.
● Be careful to keep the vehicle le vel. Placing the weight as far
forward as possible helps maintain vehicle balance.
● For better fuel economy, do no t carry unnecessary weight.

256 2-5. Driving information
PRIUS_U (OM47668U) U.S.A.
Capacity and distributionCargo capacity depends on the total weight of the occupants.
(Cargo capacity) = (Total load capa city) — (Total weight of occupants)
Steps for Determining Correct Load Limit—
(1) Locate the statement “The comb ined weight of occupants and
cargo should never exceed XXX kg or XXX lbs.” on your vehi-
cle’s placard.
(2) Determine the combined weight of the driver and passengers that will be riding in your vehicle.
(3) Subtract the combined weight of the driver and passengers from
XXX kg or XXX lbs.
(4) The resulting figure equals the available amount of cargo and luggage load capacity.
For example, if the “XXX” amount equals 1400 lbs. and there will
be five 150 lb passengers in your vehicle, the amount of avail-
able cargo and luggage load capacity is 650 lbs. (1400 - 750 (5
 150) = 650 lbs.)
(5) Determine the combined weight of luggage and cargo being loaded on the vehicle.
That weight may not safely exceed the available cargo and lug-
gage load capacity calculated in Step 4.
(6) If your vehicle will be towing a tr ailer, load from your trailer will
be transferred to your vehicle. C onsult this manual to determine
how this reduces the available cargo and luggage load capacity
of your vehicle. ( P. 260)
Toyota does not recommend towing a trailer with your vehicle.
Your vehicle is not designed for trailer towing.
