2005 TOYOTA AVENSIS code

05−346
−
DIAGNOSTICS ECD SYSTEM (1CD −FTV)(From September, 2003)
AVENSIS Supplement (RM 1045E)
DTC P0 106 MANIFOLD ABSOLUTE PRESSURE/
BAROMETRIC PRESSURE CIRCUIT RANGE/
PERFORMANCE PROBLEM
CIRCUIT DESCRIPTION
Refer to DTC P0 105 on page 05 −342.
DTC No.DTC Detection ConditionTrouble Area
P0 106
Voltage output of the manifold absolute pressure sensor is out
of the standard range
(2 trip detection logic)
S Manifold absolute pressure sensor
INSPECTION PROCEDURE
HINT:
S If DTCs P0 105, P0 107, and P0 108 are output simultaneously, the manifold absolute pressure sensor
circuit may be open or short. Perform troubleshooting for those DTCs first.
S Read freeze frame data using the hand −held tester. Freeze frame data records the engine conditions
when a malfunction is detected. When troubleshooting, freeze frame data can help determine if the
vehicle was running or stopped, if the engine was warmed up or not, if the air −fuel ratio was lean or
rich, and other data from the time the malfunction occurred.
1 CHECK OTHER DTC OUTPUT(IN ADDITION TO DTC P0 106)
(a) Connect the hand −held tester to the DLC3.
(b) Turn the ignition switch to ON and turn the hand −held tester ON.
(c) Select the item ”DIAGNOSIS / OBD/MOBD / DTC INFO / CURRENT CODES”.
(d) Read DTCs. Result:
Display (DTC output)Proceed to
P0106A
P0 106 and other DTCsB
HINT:
If any other codes besides P0 106 are output, perform troubleshooting for those DTCs first.
B GO TO RELEVANT DTC CHART(See page 05 −299)
A
REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR
05CPK −05

−
DIAGNOSTICS ECD SYSTEM (1CD −FTV)(From September, 2003)
05 −34 1
AVENSIS Supplement (RM 1045E)
DTC P0 101 MASS OR VOLUME AIR FLOW CIRCUIT
RANGE/PERFORMANCE PROBLEM
CIRCUIT DESCRIPTION
Refer to DTC P0 100 on page 05 −336.
DTC No.DTC Detection ConditionTrouble Area
After engine is warmed up, condition (a) continues for more
than 10 seconds at idling:
(2 trip detection logic)
(a) Mass air flow meter output greater than 2.2 V
P0 101Conditions (a) and (b) continue for more than 6 seconds with
engine speed at 2,000 rpm or more:
(2 trip detection logic)
(a) VTA greater than 0. 1 V
(b) Mass air flow meter output less than 0.25 VS Mass air flow meter
INSPECTION PROCEDURE
HINT:
Read freeze frame data using the hand−held tester. Freeze frame data records the engine conditions when
a malfunction is detected. When troubleshooting, freeze frame data can help determine if the vehicle was
running or stopped, if the engine was warmed up or not, if the air −fuel ratio was lean or rich, and other data
from the time the malfunction occurred.
1 CHECK OTHER DTC OUTPUT(IN ADDITION TO DTC P0 101)
(a) Connect the hand −held tester to the DLC3.
(b) Turn the ignition switch to ON and turn the hand −held tester ON.
(c) Select the item ”DIAGNOSIS / OBD/MOBD / DTC INFO / CURRENT CODES”.
(d) Read DTCs. Result:
Display (DTC output)Proceed to
P0101 and other DTCsA
P0 101B
HINT:
If any other codes besides P0 101 are output, perform troubleshoot for those DTCs first.
B REPLACE MASS AIR FLOW METER
A
GO TO RELEVANT DTC CHART (See page 05 −299)
05CPI −05

05−328
−
DIAGNOSTICS ECD SYSTEM (1CD −FTV)(From September, 2003)
AVENSIS Supplement (RM 1045E)
DTC P0093 FUEL SYSTEM LEAK DETECTED − LARGE
LEAK
HINT:
S If DTC P 1229 is detected, P0093 (fuel leaks in high −pressurized area) may be detected simultaneous-
ly. Because of the extremely high internal fuel pressure in the common rail opens the pressure limiter,
and the ECM may interpret this as a fault and set P0093.
S For more information on the common rail system, see page 05 −255.
S If P0093 is present, refer to the diagnostic trouble codes (DTCs) table for the fuel system on page
05 −255.
CIRCUIT DESCRIPTION
Refer to the description on page 05 −255.
DTC No.DTC Detection ConditionTrouble Area
P0093Fuel leaks in high −pressurized area
( 1 trip detection logic)
SFuel line between supply pump and common rail
S Fuel line between common rail and injector
S Supply pump
S Common rail
S Injector (P 1238 is set simultaneously)
S Pressure discharge valve
S Open or short in EDU circuit (P0200 is set simultaneously)
S Open or short in injector circuit (P0200 and P 1238 are set
simultaneously)
S EDU (P0200 is set simultaneously)
S ECM
HINT:
After confirming DTC P0093, check the internal fuel pressure of the common rail in the ”DIAGNOSIS / OBD/
MOBD / DATA LIST / ALL / COMN RAIL” using the hand −held tester.
Reference:
Engine SpeedFuel Pressure (MPa)
IdlingApproximately 30 to 40
2,500 rpm (No engine load)Approximately 50 to 100
MONITOR DESCRIPTION
P0093 (Fuel leaks in high −pressurized area):
This DTC stands for fuel leaks that are existing in high −pressurized area in the common rail system. The
ECM constantly monitors the internal fuel pressure of the common rail after the engine is started, and the
ECM then will set this DTC if the drop of the internal fuel pressure is large when injecting the fuel.
In the common rail system, high −pressurized fuel, approximately 30 to 180 MPa (306 to 1,835 kgf/cm
2, 4,35 1
to 26, 106 psi), is always applied to the high −pressurized area including the supply pump, common rail, injec-
tor and piping. The ECM adjusts the suction control valve control current (by applying duty ratio signal) to
obtain the target internal fuel pressure.
If this DTC is present, the ECM enters the fail −safe mode. The fail −safe mode suspends both fuel injection
and supply pump operation, and then stops the engine. Before stopping the engine, the ECM permits driving
the vehicle for 1minute. The fail −safe mode continues until the ignition switch is turned to OFF.
MONITOR STRATEGY
Required sensorsFuel pressure sensor
Frequency of operationContinuous
Duration1 second
CHK ENG operation1driving cycle
05CPF −05

−
DIAGNOSTICS ECD SYSTEM (1CD −FTV)(From September, 2003)
05 −329
AVENSIS Supplement (RM 1045E)
TYPICAL ENABLING CONDITIONS
ItemSpecificationItemMinimumMaximum
Engine speed600 rpm−
The monitor will not run if the fuel pressure sensor, suction control valve circuit, or pressure discharge valve is malfunctioning
TYPICAL MALFUNCTION THRESHOLDS
Threshold
Drop of the internal fuel pressure is large when injecting fuel
INSPECTION PROCEDURE
HINT:
Read freeze frame data using the hand−held tester. Freeze frame data records the engine conditions when
a malfunction is detected. When troubleshooting, freeze frame data can help determine if the vehicle was
running or stopped, if the engine was warmed up or not, if the air −fuel ratio was lean or rich, and other data
from the time the malfunction occurred.
1 CHECK OTHER DTC OUTPUT(IN ADDITION TO DTC P0093)
(a) Connect the hand −held tester to the DLC3.
(b) Turn the ignition switch to ON and turn the hand −held tester ON.
(c) Select the item ”DIAGNOSIS / OBD/MOBD / DTC INFO / CURRENT CODES”.
(d) Read DTCs. Result:
Display (DTC output )Proceed to
P0093A
P0093 and P 1238B
P0093 and P0200 and/or P 127 1C
HINT:
If any other codes besides P0093 are output, perform troubleshooting for those DTCs first.
B Go to step 3
C GO TO RELEVANT DTC CHART(See page 05 −299)
A
2 CHECK FUEL LEAKAGE(IN HIGH −PRESSURIZED FUEL PARTS AND AREA)
(a) Visually check the supply pump, injector and fuel line located between the supply pump and common
rail for fuel leaks or fuel pressure leaks. Also, perform the same on the fuel line between the common
rail and the injector (see page 11− 67, 11− 46).
HINT:
There is possibility that fuel leaks inside the components (supply pump, etc) have been occurred.
NG REPAIR OR REPLACE
OK

−
DIAGNOSTICS ECD SYSTEM (1CD −FTV)(From September, 2003)
05 −32 1
AVENSIS Supplement (RM 1045E)
DTC P0088 FUEL RAIL/SYSTEM PRESSURE − TO O
HIGH
DTC P 1229 FUEL PUMP SYSTEM
HINT:
S For more information on the supply pump (suction control valve) and the common rail system,
see page 05 −255.
S If P0088 and/or P 1229 is present, refer to the diagnostic trouble codes (DTCs) table for the fuel system
on page 05 −255.
CIRCUIT DESCRIPTION
Refer to the description on page 05 −255.
DTC No.DTC Detection ConditionTrouble Area
P0088
SInternal fuel pressure of the common rail is too high:
The fuel pressure exceeds 200 MPa (2,039 kgf/cm2, 29,007
psi)
( 1 trip detection logic)
SSupply pump (Suction control valve)
S Pressure discharge valve
S Short in supply pump (Suction control valve) circuit
S Open in pressure discharge valve circuit
S ECM
P 1229
SFuel over −feed:
Internal fuel pressure is beyond the target fuel pressure de-
spite the ECM closing the suction control valve
( 1 trip detection logic)SShort in supply pump (Suction control valve) circuit
S Supply pump (Suction control valve)
S ECM
HINT:
After confirming DTC P0088 and P 1229, check the fuel rail pressure in the ”DIAGNOSIS / OBD/MOBD /
DATA LIST / ALL / COMN RAIL” using the hand −held tester.
Reference:
Engine SpeedFuel Pressure (MPa)
IdlingApproximately 30 to 40
2,500 rpm (No engine load)Approximately 50 to 100
MONITOR DESCRIPTION
P0088 (Internal fuel pressure too high):
The ECM will set this DTC if the fuel pressure inside the common rail is beyond 200 MPa (2,039 kgf/cm
2,
29,007 psi). This DTC indicates that the suction control valve may be stuck open, or there may be short in
its circuit, and the pressure discharge valve may be stuck closed, or there may be open in its circuit.
If this DTC is present, the ECM enters the fail −safe mode and limits the engine power. The fail −safe mode
continues until the ignition switch is turned to OFF.
P 1229 (Fuel over −feed):
The ECM will set this DTC if the actual fuel pressure inside the common rail stays higher than the target fuel
pressure, despite the ECM closing the suction control valve. This DTC represents that the suction control
valve may be stuck open, or there may be short in its circuit. Under this condition, the pressure discharge
valve operates frequently.
If this DTC is present, the ECM enters the fail −safe mode and limits the engine power. The fail −safe mode
continues until the ignition switch is turned to OFF.
05CPE −03

05−324
−
DIAGNOSTICS ECD SYSTEM (1CD −FTV)(From September, 2003)
AVENSIS Supplement (RM 1045E)
1 CHECK OTHER DTC OUTPUT(IN ADDITION TO DTC P0088 AND/OR P 1229)
(a) Connect the hand −held tester to the DLC3.
(b) Turn the ignition switch to ON and turn the hand −held tester ON.
(c) Select the item ”DIAGNOSIS / OBD/MOBD / DTC INFO / CURRENT CODES”.
(d) Read DTCs.
Result:
Display (DTC output)Proceed to
P0088, or P0088 and P 1229A
P 1229B
P0 190, P0 191,P0 192, P0 193 and/or P 127 1C
P1272D
B Go to step 4
C GO TO RELEVANT DTC CHART
(See page 05 −299)
D Go to step 3
A
2 READ OUTPUT DTC(SEE IF DTC P 1272 IS OUTPUT)
(a) Connect the hand −held tester to the DLC3.
(b) Turn the ignition switch to ON and turn the hand −held tester ON.
(c) Select the item ”DIAGNOSIS / OBD/MOBD / DTC INFO / CLEAR CODES”.
(d) Clear the DTCs.
(e) Start the engine and turn the ignition switch to OFF. Wait for 10 seconds and then restart the engine
and turn the ignition switch to OFF again.
(f) Select the item ”DIAGNOSIS / OBD/MOBD / DTC INFO / CURRENT CODES”.
(g) Read DTCs. Result:
Display (DTC output)Proceed to
P1272A
No outputB
B Go to step 4
A
3 REPLACE COMMON RAIL ASSY(PRESSURE DISCHARGE VALVE) (See page 11− 67)
GO
CHECK IF DTCS OUTPUT RECUR (DTC P0088 AND/OR P 1229 OUTPUT AGAIN)
HINT:
After clearing the DTCs, drive the vehicle at 50 km/h (3 1mph) for 5 minutes, and then confirm that P0088
and/or P 1229 is not present again.

A75346
Suction
Control
Valve
−
DIAGNOSTICS ECD SYSTEM (1CD −FTV)(From September, 2003)
05 −325
AVENSIS Supplement (RM 1045E)
4 INSPECT INJECTION OR SUPPLY PUMP ASSY(SUCTION CONTROL VALVE)
(a) Measure the resistance between the terminals of the suc-
tion control valve.
Standard: 1.9 to 2.3
at 20 _C (68 _F)
NG REPLACE INJECTION OR SUPPLY PUMP ASSY (SUCTION CONTROL VALVE)
(See page 11− 58)
OK
5 READ OUTPUT DTC(SEE IF DTC P 1229 IS OUTPUT)
(a) Connect the hand −held tester to the DLC3.
(b) Turn the ignition switch to ON and turn the hand −held tester ON.
(c) Select the item ”DIAGNOSIS / OBD/MOBD / DTC INFO / CLEAR CODES”.
(d) Clear the DTCs.
(e) Disconnect the suction control valve connector and then start the engine. Wait for 1 minute.
HINT:
If the engine does not start, the suction control valve is normal. Therefore proceed to step 6.
(f) Select the item ”DIAGNOSIS / OBD/MOBD / DTC INFO / CURRENT CODES”.
(g) Read DTCs. Result:
Display (DTC output)Proceed to
No outputA
P1229B
B REPLACE INJECTION OR SUPPLY PUMP ASSY
(SUCTION CONTROL VALVE)
(See page 11− 58)
A

05−314
−
DIAGNOSTICS ECD SYSTEM (1CD −FTV)(From September, 2003)
AVENSIS Supplement (RM 1045E)
DTC P0087 FUEL RAIL/SYSTEM PRESSURE − TO O
LOW
DTC P0 190 FUEL RAIL PRESSURE SENSOR CIRCUIT
DTC P0 192 FUEL RAIL PRESSURE SENSOR CIRCUIT
LOW INPUT
DTC P0 193 FUEL RAIL PRESSURE SENSOR CIRCUIT
HIGH INPUT
HINT:
S For more information on the fuel pressure sensor and the common rail system, see page 05 −255.
SIf P0087, P0 190, P0 192 and/or P0 193 is present, refer to the diagnostic trouble codes (DTCs) table
for fuel system on page 05 −255.
05CPD −05
