2005 NISSAN 350Z Owner´s Manual

straint could tip over or otherwise be
unsecured and cause injury to the
child in a sudden stop or collision.
CAUTION
Turn off the automatic passenger seat-
back tilt function by turning the seat-
back tilt cancel switch to the CANCEL
position. (Roadster models)
Front facingIf you must install a child restraint in the front
seat, follow these steps:
1. Turn the air bag ON/OFF switch to the OFF
position.
Turn the seatback tilt cancel switch to the
CANCEL position. (Roadster models only)
2. Position the child restraint on the front pas-
senger seat.Move the seat to the rear-
most position.Adjust the head restraint to
its highest position (if so equipped). The
direction of the child restraint depends on the
type of the child restraint and the size of thechild. Always follow the restraint manufactur-
er’s instructions.
The back of the child restraint should be
secured against the vehicle seatback. If nec-
essary, adjust or remove the head restraint to
obtain the correct child restraint fit. See
“Head restraint adjustment” earlier in this
section. If the head restraint is removed, store
it in a secure place. Be sure to install the
head restraint when the child restraint is
removed. If the seating position does not
have an adjustable head restraint and it is
interfering with the proper child restraint fit,
try a different child restraint.
SSS0301C
Front facing — step 2
1-20
Safety — Seats, seat belts and supplemental restraint system


04.8.23/Z33-D/V5.0


3. Route the seat belt tongue through the child
restraint and insert it into the buckle until you
hear and feel the latch engage. Be sure to
follow the child restraint manufacturer’s in-
structions for belt routing.4. Pull on the shoulder belt until all of the belt is
fully extended. At this time, the belt retractor
is in the automatic locking mode (child re-
straint mode). It reverts back to emergency
locking mode when the belt is fully retracted.5. Allow the belt to retract. Pull up on the belt to
remove any slack in the belt.
SSS0253D
Front facing — step 3
SSS0254D
Front facing — step 4
SSS0331
Front facing — step 5
Safety — Seats, seat belts and supplemental restraint system
1-21


04.8.23/Z33-D/V5.0


6. Before placing the child in the child restraint,
use force to push the child restraint from side
to side, and tug it forward to make sure that it
is securely held in place. It should not move
more than 1 in (25 mm). If it does move more
than 1 in (25 mm), pull again on the shoulder
belt to further tighten the child restraint. If
unable to properly secure the restraint, try a
different child restraint. Not all child restraints
fit in all types of vehicles.
7. Check that the retractor is in the automatic
locking mode by trying to pull more belt out of
the retractor. If you cannot pull any more belt
webbing out of the retractor, the belt is in the
automatic locking mode.8. Check to make sure that the child restraint is
properly secured prior to each use. If the lap
belt is not locked, repeat steps 4 through 7.
After the child restraint is removed and the seat
belt is allowed to wind back into the retractor,
the automatic locking mode (child restraint
mode) is canceled.
Rear facingWhen you install a child restraint in the front
seat, follow these steps:
1. Turn the air bag ON/OFF switch to the OFF
position.
Turn the seatback tilt cancel switch to the
CANCEL position. (Roadster models only)
2. Position the child restraint on the front pas-
senger seat. Move the seat to the rearmost
position. The direction of the child restraint
depends on the type of the child restraint and
the size of the child. Always follow the re-
straint manufacturer’s instructions.
SSS0302B
Front facing — step 6
SSS0211A
Rear facing — step 2
1-22
Safety — Seats, seat belts and supplemental restraint system


04.8.23/Z33-D/V5.0


3. Route the seat belt tongue through the child
restraint and insert it into the buckle until you
hear and feel the latch engage.
Be sure to follow the child restraint manufac-
turer’s instructions for belt routing.4. Pull on the shoulder belt until all of the belt is
fully extended. At this time, the belt retractor
is in the automatic locking mode (child re-
straint mode). It reverts back to emergency
locking mode when the belt is fully retracted.5. Allow the belt to retract. Pull up on the belt to
remove any slack in the belt.
SSS0212A
Rear facing — step 3
SSS0213A
Rear facing — step 4
SSS0214A
Rear facing — step 5
Safety — Seats, seat belts and supplemental restraint system
1-23


04.8.23/Z33-D/V5.0


6. Before placing the child in the child restraint,
use force to push the child restraint from side
to side, and tug it forward to make sure that it
is securely held in place. It should not move
more than 1 in (25 mm). If it does move more
than 1 in (25 mm), pull again on the shoulder
belt to further tighten the child restraint. If
unable to properly secure the restraint, try a
different child restraint. Not all child restraints
fit in all types of vehicles.
7. Check that the retractor is in the automatic
locking mode by trying to pull more belt out of
the retractor. If you cannot pull any more belt
webbing out of the retractor, the belt is in the
automatic locking mode.8. Check to make sure that the child restraint is
properly secured prior to each use. If the belt
is not locked, repeat steps 4 through 7.
After the child restraint is removed and the seat
belt is allowed to wind back into the retractor,
the automatic locking mode (child restraint
mode) is canceled.
TOP TETHER STRAP CHILD
RESTRAINT (Coupe models)An anchor for a child restraint with a top tether is
provided in this vehicle.However, a child
restraint of this type should not be used in
this vehicle unless an air bag ON/OFF
switch has been installed and is being
properly used.See “Obtaining an air bag
ON/OFF switch” earlier in this manual.
If your child restraint has a top tether strap, it
must be secured to the provided anchor point.
Secure the child restraint with the seat belt.
Guide the top tether strap under the head
restraint as illustrated, and secure it to the
SSS0215A
Rear facing — step 6
SSS0207
1-24
Safety — Seats, seat belts and supplemental restraint system


04.8.23/Z33-D/V5.0


anchor bracket. Tighten the strap according to
manufacturer instructions to remove any slack.
WARNING
Child restraint anchor point is designed
to withstand only those loads imposed
by correctly fitted child restraints. Under
no circumstance is it to be used for adult
seat belts or harnesses.
Anchor point locationThe anchor point
A
is located on the luggage
area floor.
A flap is provided in the carpet for easy access
and is marked with the label shown.
If you have any questions when installing a
top tether strap child restraint on the pas-
senger seat, consult a NISSAN dealer for
details.
PRECAUTIONS ON BOOSTER
SEATS
WARNING

The information in this section is pro-
vided only for those owners who
have received permission to install
an air bag ON/OFF switch and the
switch has been installed. See “Ob-
taining an air bag ON/OFF switch”
earlier in this manual. Never let chil-
dren 12 or under ride in this vehicle
unless an air bag ON/OFF switch is
installed and it is being properly
used.

Infants and small children should al-
ways be placed in an appropriate
child restraint while riding in the ve-
hicle. Failure to use a child restraint
or booster seat can result in serious
injury or death.

Infants and small children should
never be carried on your lap. It is not
possible for even the strongest adult
to resist the forces of a severe acci-
SPA1644
BOOSTER SEATS
Safety — Seats, seat belts and supplemental restraint system
1-25


04.8.23/Z33-D/V5.0


dent. The child could be crushed be-
tween the adult and parts of the ve-
hicle. Also, do not put the same seat
belt around both your child and your-
self.

Never install a booster seat in the
front seat unless an air bag ON/OFF
switch has been installed and the air
bag has been turned OFF. An inflat-
ing supplemental air bag could seri-
ously injure or kill your child.

A booster seat must only be installed
in a seating position that has a
lap/shoulder belt. Failure to use a
three-point type seat belt with a
booster seat can result in a serious
injury in sudden stop or collision.

An improperly installed booster seat
could lead to serious injury or death
in an accident.
WARNING
Do not use towels, books, pillows or
other items in place of a booster seat.
Items such as these may move during
normal driving or a collision and result
in serious injury or death. Booster seats
are designed to be used with a
lap/shoulder belt. Booster seats are de-
signed to properly route the lap and
shoulder portions of the seat belt over
the strongest portions of a child’s bodyto provide the maximum protection dur-
ing a collision.
Booster seats of various sizes are offered by
several manufacturers. When selecting any
booster seat, keep the following points in mind:

Choose only a booster seat with a label
certifying that it complies with Federal Motor
Vehicle Safety Standard 213 or Canadian
Motor Vehicle Safety Standard 213.

Check the booster seat in your vehicle to be
sure it is compatible with the vehicle’s seat
and seat belt system.
LRS0455
1-26
Safety — Seats, seat belts and supplemental restraint system


04.8.23/Z33-D/V5.0


Make sure the child’s head will be properly
supported by the booster seat or vehicle
seat. The seatback must be at or above the
center of the child’s ears. For example, if a
low back booster seat
1
is chosen, the
vehicle seatback must be at or above the
center of the child’s ears. If the seatback is
lower than the center of the child’s ears, a
high back booster seat
2
should be used.

If the booster seat is compatible with your
vehicle, place your child in the booster seat
and check the various adjustments to be sure
the booster seat is compatible with your
child. Always follow all recommended proce-
dures.All U.S. states and Canadian provinces re-
quire that infants and small children be
restrained in an approved child restraint at
all times while the vehicle is being oper-
ated.
WARNING

Improper use of a booster seat can
increase the risk or severity of injury
for both the child and other occu-
pants of the vehicle.

Follow all of the booster seat manu-
facturer’s instructions for installation
and use. When purchasing a booster
seat, be sure to select one which will
fit your child and vehicle. It may not
be possible to properly install some
types of booster seats in your ve-
hicle.

If the booster seat and seat belt are
not used properly, the risk of a child
being injured in a collision or a sud-
den stop greatly increases.

Adjustable seatbacks should be po-
sitioned to fit the booster seat, but as
SSS0363
LRS0454
Safety — Seats, seat belts and supplemental restraint system
1-27


04.8.23/Z33-D/V5.0
