2 Instruments and controlsInstrument panel ................................................................... 2-2
Meters and gauges .............................................................. 2-3
Speedometer and odometer ........................................ 2-4
Tachometer ....................................................................... 2-5
Engine coolant temperature gauge ............................ 2-6
Fuel gauge ........................................................................ 2-6
Engine oil pressure gauge ........................................... 2-7
Volt meter ......................................................................... 2-8
Trip computer .................................................................. 2-8
Warning/indicator lights and audible reminders ......... 2-12
Checking bulbs ............................................................. 2-12
Warning lights ............................................................... 2-12
Indicator lights ............................................................... 2-16
Audible reminders ........................................................ 2-18
Security systems ................................................................ 2-19
Vehicle security system .............................................. 2-19
NISSAN vehicle immobilizer system (NVIS) ......... 2-20
Windshield wiper and washer switch ........................... 2-22
Rear window wiper and washer switch
(Coupe models) .................................................................. 2-22
Rear window and outside mirror defroster switch .... 2-23
Headlight and turn signal switch ................................... 2-24
Xenon headlights (if so equipped) .......................... 2-24
Headlight switch ........................................................... 2-24Daytime running light system (Canada only) ........ 2-25
Turn signal switch ........................................................ 2-26
Instrument brightness control ................................... 2-26
Hazard warning flasher switch ....................................... 2-27
Horn ....................................................................................... 2-27
Heated seats (if so equipped) ........................................ 2-28
Vehicle dynamic control (VDC) off switch
(if so equipped).................................................................... 2-29
Traction control system (TCS) off switch
(if so equipped).................................................................... 2-29
Clock ..................................................................................... 2-30
Adjusting the time ........................................................ 2-30
Power outlet ........................................................................ 2-31
Storage ................................................................................. 2-32
Instrument pocket (except for navigation system
equipped models) ........................................................ 2-32
Sunglasses holder (Coupe models) ........................ 2-32
Tray .................................................................................. 2-33
Cup holders ................................................................... 2-33
Console box .................................................................. 2-34
Rear floor box ................................................................ 2-35
Rear parcel box ............................................................ 2-36
Stowing golf bags ......................................................... 2-36
Coat hook (Coupe models) .............................................. 2-37


04.8.23/Z33-D/V5.0


Windows .............................................................................. 2-38
Power windows ............................................................ 2-38
Automatic adjusting function ...................................... 2-39
Interior lights ........................................................................ 2-40
Interior ............................................................................. 2-40
Map .................................................................................. 2-40
Vanity mirror light ............................................................... 2-41
Luggage compartment light (Coupe models) ............. 2-41
Trunk light (Roadster models).......................................... 2-41HomeLink
universal transceiver (if so equipped) ...... 2-42
Programming HomeLink
........................................... 2-42
Programming HomeLinkfor Canadian
customers ....................................................................... 2-44
Operating the HomeLinkuniversal transceiver.... 2-44
Programming trouble diagnosis ................................ 2-44
Clearing the programmed information .................... 2-44
Reprogramming a single HomeLink
button .......... 2-45
If your vehicle is stolen ............................................... 2-45


04.8.23/Z33-D/V5.0


1. Headlight/turn signal switch
2. Instrument brightness control switch
3. Driver supplemental air bag/Horn
4. Meters/gauges
5. Cruise control main/set switch
(if so equipped)6. Trip computer mode/setting switch
7. Windshield wiper/washer switch
8. Center ventilator
9. Cup holder
10. Passenger supplemental air bag
11. Side ventilator12. VDC (Vehicle dynamic control) OFF switch
or TCS (Traction control system) OFF
switch
13. Soft top operating switch (for Roadster
models)
14. Fuel filler lid opener switch
15. Hood lock release handle
16. Fuse box
17. Tilting steering wheel lock lever
18. Ignition switch/steering lock
19. Navigation system display* or Instrument
pocket
20. Rear window and outside mirror defroster
switch
21. Heater/air conditioner control
22. Audio system/Clock
23. Heated seat switch (if so equipped)
24. Hazard warning flasher switch
25. Tray
26. Power outlet
*: Refer to the separate Navigation System
Owner’s Manual.
SIC2268
INSTRUMENT PANEL2-2
Instruments and controls


04.8.23/Z33-D/V5.0


Combination meter:
1. Warning/Indicator lights
2. Turn signal/hazard indicator lights
3. Tachometer
4. Speedometer5. Instrument brightness control switch
(See “Headlight and turn signal switch” later
in this section.)
6. Fuel gauge
7. Engine coolant temperature gauge8. Automatic transmission position indicator or
Manual transmission shift up indicator
(See “Driving the vehicle” in the “5. Starting
and driving” section.)
9. Reset knobfor trip odometer
10. Odometer (Total/Twin trip)
11. Trip computer setting switch
(See “Trip computer” later in this section.)
12. Trip computer mode switch
(See “Trip computer” later in this section.)
SIC2233
METERS AND GAUGES
Instruments and controls
2-3


04.8.23/Z33-D/V5.0


Triple meter:
1. Trip computer
2. Engine oil pressure gauge
3. Volt meter
1
Speedometer
2
Odometer
3
Twin trip odometer
4
Reset knobfor trip odometer
SPEEDOMETER AND ODOMETER
SpeedometerThe speedometer indicates vehicle speed in
miles per hour (MPH) and kilometers per hour
(km/h).Odometer/Twin trip odometerThe odometer/twin trip odometer are displayed
when the ignition key is in the ON position.The odometer records the total distance the
vehicle has been driven.
The twin trip odometer records the distance of
individual trips.
SIC1948
SIC1949A
2-4
Instruments and controls


04.8.23/Z33-D/V5.0


Changing the display:
Pushing the reset knobchanges the display as
follows:
TRIP A→TRIP B→TRIP A
Resetting the trip odometer:
Pushing the reset knobfor more than 1 second
resets the trip odometer to zero.
1
Tachometer
2
Transmission indicator
TACHOMETERThe tachometer indicates engine speed in revo-
lutions per minute (rpm). Do not rev engine into
the red zone
A.CAUTION
When engine speed approaches the red
zone, shift to a higher gear. Operating
the engine in the red zone may causeserious engine damage.
SIC1950A
Instruments and controls
2-5


04.8.23/Z33-D/V5.0


ENGINE COOLANT TEMPERATURE
GAUGEThe gauge indicates the engine coolant tem-
perature.
The engine coolant temperature is within the
normal range
A
when the gauge needle points
within the zone shown in the illustration.
The engine coolant temperature will vary with the
outside air temperature and driving conditions.
CAUTION
If the gauge indicates engine coolant
temperature near the hot (H) end of the
normal range, reduce vehicle speed to
decrease temperature. If the gauge is
over the normal range, stop the vehicle
as soon as safely possible. If the engine
is overheated, continued operation of
the vehicle may seriously damage the
engine. See “If your vehicle overheats”
in the “6. In case of emergency” section
for immediate action required.
FUEL GAUGEThe gauge indicates the approximate fuel level in
the tank.
The gauge may move slightly during braking,
turning, acceleration, or going up or down hill.
The gauge needle is designed to move to the E
(Empty) position when the ignition key is turned
to the OFF position.
Refill the fuel tank before the gauge regis-
ters the E (Empty) position.
SIC2371A
SIC2556
2-6
Instruments and controls


04.8.23/Z33-D/V5.0


The low fuel warning light comes on when
the fuel tank is getting low. Refuel as soon
as it is convenient, preferably before the
gauge reaches the E position. There will be
a small reserve of fuel in the tank when the
fuel gauge needle reaches the E position.
The
indicates that the fuel filler lid is lo-
cated on the passenger’s side of the vehicle.
CAUTION

If the vehicle runs out of fuel, the
malfunction indicator lamp
(MIL) may come on. Refuel as soon
as possible. After a few driving trips,
the
lamp should turn off. If the
lamp remains on after a few driving
trips, have the vehicle inspected by a
NISSAN dealer.

For additional information, see “Mal-
function indicator lamp (MIL)” later in
this section.
ENGINE OIL PRESSURE GAUGEThe gauge indicates the engine lubrication sys-
tem oil pressure while the engine is running.
When the engine speed is high, the engine oil
pressure is also high. When it is low, the gauge
indicates the low oil pressure.
CAUTION

This gauge is not designed to indi-
cate low engine oil level. Use the
dipstick to check the oil level. (See
“Engine oil” in the “8. Maintenance
and do-it-yourself” section.)

If the gauge needle does not move
with the proper amount of engine oil,
have the vehicle checked by a
NISSAN dealer. Continued vehicle
SIC1954A
Type A
SIC1953A
Type B
Instruments and controls
2-7
