STARTING SYSTEM
CIRCUIT DIAGRAMS90-19
STARTING SYSTEM
M1901000501318
IGNITION
SWITCH (ST)
STARTER
ENGINE CONTROL
SYSTEM
Wire colour code
B : Black LG : Light green G : Green L : Blue W : White Y : Yellow SB : Sky blue
BR : Brown O : Orange GR : Grey R : Red P : Pink V : Violet
NOTE
: LHD
: RHD
BATTERY

STARTING SYSTEM
CIRCUIT DIAGRAMS90-20
STARTING SYSTEM
M1901000501329
BATTERYIGNITION
SWITCH (ST)
INHIBITOR
SWITCH
STARTER
ENGINE CONTROL
SYSTEM
Wire colour code
B : Black LG : Light green G : Green L : Blue W : White Y : Yellow SB : Sky blue
BR : Brown O : Orange GR : Grey R : Red P : Pink V : Violet
NOTE
: LHD
: RHD

IGNITION SYSTEM <4G1-M/T (LHD)>
CIRCUIT DIAGRAMS90-21
IGNITION SYSTEM <4G1-M/T (LHD)>
M1901000601832
IGNITION
SWITCH (IG1)
IGNITION
COIL (1)IGNITION
COIL (2)
SPARK PLUG
ENGINE-ECU
ENGINE SPEED
DETECTION
CONNECTOR
INPUT SIGNAL
·ATMOSPHERIC
PRESSURE SENSOR
·CAMSHAFT
POSITION SENSOR
·ENGINE CRANK
ANGLE SENSOR·WATER TEMPERATURE
SENSOR UNIT ·ENGINE CONTROL
DETONATION SENSOR·FUEL PRESSURE SENSOR
·IGNITION SWITCH (ST)
·INTAKE AIR TEMPERATURE
SENSOR
·ENGINE CONTROL
OXYGEN SENSOR·VEHICLE SPEED SENSOR ·THROTTLE BODY
THROTTLE SENSOR

IGNITION SYSTEM <4G1-M/T (RHD)>
CIRCUIT DIAGRAMS90-22
IGNITION SYSTEM <4G1-M/T (RHD)>
M1901000601843
IGNITION
SWITCH (IG1)
IGNITION
COIL (1)IGNITION
COIL (2)
SPARK PLUG
ENGINE-ECU
ENGINE SPEED
DETECTION
CONNECTOR
INPUT SIGNAL
BATTERY
IGNITION
COIL RELAYRELAY
BOX
·ENGINE
CONTROL
SYSTEM
·IMMOBILIZER
SYSTEM
·ATMOSPHERIC
PRESSURE SENSOR
·CAMSHAFT
POSITION SENSOR
·ENGINE CRANK
ANGLE SENSOR·WATER TEMPERATURE
SENSOR UNIT ·ENGINE CONTROL
DETONATION SENSOR·FUEL PRESSURE SENSOR
·IGNITION SWITCH (ST)
·INTAKE AIR
TEMPERATURE
SENSOR
·ENGINE CONTROL
OXYGEN SENSOR
·VEHICLE SPEED SENSOR ·THROTTLE BODY
THROTTLE SENSOR

IGNITION SYSTEM <4G1-A/T (LHD)>
CIRCUIT DIAGRAMS90-23
IGNITION SYSTEM <4G1-A/T (LHD)>
M1901000601854
IGNITION
SWITCH (IG1)
IGNITION
COIL (1)IGNITION
COIL (2)
SPARK PLUG
ENGINE-
A/T-ECU
ENGINE SPEED
DETECTION
CONNECTOR
INPUT SIGNAL
·ATMOSPHERIC
PRESSURE SENSOR
·CAMSHAFT
POSITION SENSOR·FUEL PRESSURE SENSOR
·IGNITION SWITCH (ST)
·INTAKE AIR
TEMPERATURE
SENSOR ·INHIBITOR SWITCH
·ENGINE CRANK
ANGLE SENSOR·WATER TEMPERATURE
SENSOR UNIT ·ENGINE CONTROL
DETONATION SENSOR
·ENGINE CONTROL
OXYGEN SENSOR·THROTTLE BODY
THROTTLE SENSOR

IGNITION SYSTEM <4G1-A/T (RHD)>
CIRCUIT DIAGRAMS90-24
IGNITION SYSTEM <4G1-A/T (RHD)>
M1901000601865
IGNITION
SWITCH (IG1)
IGNITION
COIL (1)IGNITION
COIL (2)
SPARK PLUG
ENGINE-
A/T-ECU
ENGINE SPEED
DETECTION
CONNECTOR
INPUT SIGNAL
·ATMOSPHERIC
PRESSURE SENSOR
·CAMSHAFT
POSITION SENSOR·FUEL PRESSURE SENSOR
·IGNITION SWITCH (ST)
·INTAKE AIR
TEMPERATURE
SENSOR
BATTERY
IGNITION
COIL RELAYRELAY
BOX
·ENGINE
CONTROL
SYSTEM
·IMMOBILIZER
SYSTEM
·INHIBITOR SWITCH
·ENGINE CRANK
ANGLE SENSOR·WATER TEMPERATURE
SENSOR UNIT ·ENGINE CONTROL
DETONATION SENSOR
·ENGINE CONTROL
OXYGEN SENSOR·THROTTLE BODY
THROTTLE SENSOR

IGNITION SYSTEM <4G6 (LHD)>
CIRCUIT DIAGRAMS90-25
IGNITION SYSTEM <4G6 (LHD)>
M1901000601876
IGNITION
SWITCH (IG1)
IGNITION
COIL (1)IGNITION
COIL (2)
SPARK PLUG
ENGINE-ECU
ENGINE SPEED
DETECTION
CONNECTOR
INPUT SIGNAL
CAPACITOR
·ATMOSPHERIC
PRESSURE SENSOR
·CAMSHAFT
POSITION SENSOR
·ENGINE CRANK
ANGLE SENSOR·WATER TEMPERATURE
SENSOR UNIT ·ENGINE CONTROL
DETONATION SENSOR·FUEL PRESSURE SENSOR
·IGNITION SWITCH (ST)
·INTAKE AIR
TEMPERATURE
SENSOR
·ENGINE CONTROL
OXYGEN SENSOR
·VEHICLE SPEED SENSOR ·THROTTLE BODY
THROTTLE SENSOR

IGNITION SYSTEM <4G6 (RHD)>
CIRCUIT DIAGRAMS90-26
IGNITION SYSTEM <4G6 (RHD)>
M1901000601887
IGNITION
SWITCH (IG1)
IGNITION
COIL (1)IGNITION
COIL (2)
SPARK PLUG
ENGINE-ECU
ENGINE SPEED
DETECTION
CONNECTOR
INPUT SIGNAL
·ATMOSPHERIC
PRESSURE SENSOR
·CAMSHAFT
POSITION SENSOR
·ENGINE CRANK
ANGLE SENSOR·WATER TEMPERATURE
SENSOR UNIT ·ENGINE CONTROL
DETONATION SENSOR·FUEL PRESSURE SENSOR
·IGNITION SWITCH (ST)
·INTAKE AIR TEMPERATURE
SENSOR
·ENGINE CONTROL
OXYGEN SENSOR
·VEHICLE SPEED SENSOR ·THROTTLE BODY
THROTTLE
SENSOR
BATTERY
IGNITION
COIL RELAYRELAY
BOX
·ENGINE
CONTROL
SYSTEM
·IMMOBILIZER
SYSTEM
CAPACITOR
