2005 MITSUBISHI LANCER Workshop Manual

DOOR MIRROR
EXTERIOR51-47
INSPECTIONM1511006500286
ELECTRIC REMOTE CONTROL MIRROR
OPERATION CHECK WITHOUT HEATED DOOR MIRROR>
Check that the mirror moves as described in the
table when each terminal is connected to the battery.
ELECTRIC REMOTE CONTROL MIRROR
OPERATION CHECK HEATED DOOR MIRROR>
Check that the mirror moves as described in the
table when each terminal is connected to the battery.
Battery connection Direction
operation
•Connect terminal 1 to the negative
battery terminal.
•Connect terminal 3 to the positive
battery terminal.Mirror
glass
should face
upward
•Connect terminal 3 to the negative
battery terminal.
•Connect terminal 1 to the positive
battery terminal.Mirror
glass
should face
downward
•Connect terminal 1 to the negative
battery terminal.
•Connect terminal 2 to the positive
battery terminal.Mirror
glass
should face
to the right
•Connect terminal 2 to the negative
battery terminal.
•Connect terminal 1 to the positive
battery terminal.Mirror
glass
should face
to the left
3 2
1
AC005969
Battery connection Direction
operation
•Connect terminal 5 to the negative
battery terminal.
•Connect terminal 7 to the positive
battery terminal.Mirror
glass
should face
upward
•Connect terminal 7 to the negative
battery terminal.
•Connect terminal 5 to the positive
battery terminal.Mirror
glass
should face
downward
•Connect terminal 5 to the negative
battery terminal.
•Connect terminal 6 to the positive
battery terminal.Mirror
glass
should face
to the right
•Connect terminal 6 to the negative
battery terminal.
•Connect terminal 5 to the positive
battery terminal.Mirror
glass
should face
to the left
AC202548
1
456723

DOOR MIRROR
EXTERIOR51-48
DOOR MIRROR CONTROL SWITCH
CONTINUITY CHECKHEATED DOOR MIRROR CHECK
CAUTION
When relocating the car between locations with
extremely different temperatures (warm and
cold), leave the car in the location for a while to
adapt to the temperature prior to checking it.
The resistance value between door mirror connector
terminals 1 and 4 should meet the standard value
with the ambient temperature at steady 25°C.
Standard value: 5.9 − 7.8 Ω Switch position Tester
connectionSpecified
condition
OFF 9 − 2, 9 − 3, 9 − 6,
9 − 10, 9 − 11 ,
1 − 2, 1 − 3, 1 − 6,
1 − 10, 1 − 11Open circuit
Left side OFF 9 − 6, 9 − 10, 9 −
11 , 1 − 6, 1 − 10,
1 − 11Open circuit
Up 1 − 6, 9 − 11 Less than 2
ohms
Down 1 − 11 , 6 − 9
Right 1 − 6, 9 − 10
Left 1 − 10, 6 − 9
Right
sideOFF 9 − 2, 9 − 3, 9 − 6,
1 − 2, 1 − 3, 1 − 6Open circuit
Up 1 − 6, 3 − 9 Less than 2
ohms
Down 1 − 3, 6 − 9
Right 1 − 6, 2 − 9
Left 1 − 2, 6 − 9
AC005970
2
14 3
5109
8
7 611
AC202548
1
456723
