2005 MITSUBISHI LANCER Workshop Manual

HOOD
BODY42-3
HOOD
ON-VEHICLE SERVICE
ADJUSTMENT OF CLEARANCE AROUND
HOOD
M1421007200129
ADJUSTMENT OF ALIGNMENT OF HOOD
STEPPED PORTION AND HOOD
STRIKER
M1421007300126
ADJUSTMENT OF HOOD HEIGHTM1421007400123
Rotate the hood bumper by using arrow mark on the
hood bumper as a guide to adjust the hood height. If
the hood bumper is rotated just one turn, the hood
height changes by approximately 3 mm.
AC005945
AC005947
Y0215AU
X0424CA
AC005948
AB
Section A – AA
A
Hood
Hood bumper 17 mm

HOOD
BODY42-4
HOOD
REMOVAL AND INSTALLATIONM1421001600561
Post-installation Operation
•Adjustment of Clearance Around Hood (Refer to P.42-3).
•Adjustment of Alignment of Hood Stepped Portion and
Hood Striker (Refer to P.42-3).
•Adjustment of Hood Height (Refer to P.42-3).
AC304739
1 1
22
44
5 6 73 8
910
AD9.0 ± 2.0 N·m21 ± 4 N·m 11 ± 2 N·m21 ± 4 N·m
Removal
1. Hood bumper
2. Hood latch
3. Hood weatherstrip
Hood lock release cable removal
steps
4. Hood lock release handle
5. Hood lock release cableHood and hood hinge removal
steps
6. Hood insulator
7. Hood weatherstrip
•Washer hose (Refer to GROUP 51,
Windshield wiper and washer
P.51-23.)
8. Hood
9. Hood support rod
10. Hood hinge

FENDER
BODY42-5
FENDER
SPECIAL TOOLM1421000600256
AC300865
Note
: Clip positions
Section A – A
AC
Clip
A
A
6 8
6 8
Clip positions
Tool Number Name Use
MB990784 Ornament remover Side turn-signal lamp removal
MB990784

FENDER
BODY42-6
FENDER
REMOVAL AND INSTALLATIONM1421001900302
Pre-removal and Post-installation Operation
•Front Bumper Removal and Installation (Refer to GROUP
51, Front Bumper P.51-2.)
•Front Deck Garnish Removal and Installation (Refer to
GROUP 51, Windshield Wiper and Washer P.51-23.)
•Side Air Dam Removal and Installation side air dam> (Refer to GROUP 51, Side Air Dam
P.51-15.)
AC300491
AC304753
AC303863
Clip Section A – A
AB
A A
123
3 4
Note
: Clip positions
Removal steps
1. Splash shield
<> >>A<<2. Side turn-signal lamp3. Delta outer garnish
4. FenderRemoval steps (Continued)

FENDER
BODY42-7
REMOVAL SERVICE POINT
<> SIDE TURN-SIGNAL LAMP
REMOVAL
Use special tool ornament remover (MB990784) to
prize out the tab from the fender, and remove the
side turn signal light.
INSTALLATION SERVICE POINT
>>A<< SIDE TURN-SIGNAL LAMP
INSTALLATION
Engage the claw with the fender panel, and install
the side turn-signal lamp.
AC005980AC005980
Front of vehicle
Side turn-signal light
MB990784
ABAC005719
Fender panelHook
Claw
Fender panel
: Front of vehicle
AE

FUEL FILLER LID
BODY42-8
FUEL FILLER LID
REMOVAL AND INSTALLATIONM1421002500277
Pre-removal and Post-installation Operation
•Rear Seat Removal and Installation (Refer to GROUP
52A, Rear Seat P.52A-28.)
•Front Scuff Plate (Driver's Seat Side), Rear Scuff Plate
(Driver's Side), Centre Pillar Lower Trim (Driver's Side),
Quarter Trim (Driver's Side) Removal and Installation
(Refer to GROUP 52A, Trims P.52A-11.)
18M0109W0570AQ
AC005996
AC005973
3
54
3
2 1
5.0 ± 1.0 N·m
AC
Fuel filler lid height and clearance
adjustment
Removal steps
1. Fuel filler lid panel assembly
2. Clip
3. Fuel filler lid hook assembly4. Fuel filler lid lock release cable
5. Fuel filler lid lock release handleRemoval steps (Continued)

STRUT TOWER BAR
BODY42-9
STRUT TOWER BAR
REMOVAL AND INSTALLATIONM1421005600091
WINDOW GLASS
ADHESIVEM1422000500081
SPECIAL TOOLSM1422000600293
AC304680AB
Strut tower bar44 ± 5 N·m
Item Specified adhesive
Windshield 3M ATD Part No.8609 Super Fast Urethane Auto Glass
Sealant or equivalent
3M ATD Part No.8608 Super Fast Urethane Primer or
equivalent Rear window glass
Quarter window glass
Tailgate window glass
Tool Number Name Use
MB990480 Glass holder Removal and installation of window glass
MB990784 Ornament remover Removal of rear window lower moulding
MB990480
MB990784

WINDOW GLASS
BODY42-10
WINDOW REPAIRM1422005600027
The windshield, rear window glass, quarter window
glass and tailgate window glass are attached by an
urethane-base adhesive to the window frame. This
adhesive provides improved glass holding and
sealing, and also gives body openings a greater
structural strength.
ITEMS
HANDLING OF AUTO WINDOW SEALER
Keep the sealant in a cool place, not exposed to the
direct rays of the sun. Do not place any heavy article
on the sealant nor press it, otherwise it will become
deformed. Avoid storing the sealant for more than 6
months, because it will lose its sealing effect.
BODY PINCH-WELD FLANGE SERVICING
Before servicing the body pinch-weld flange, remove
old adhesive completely. If the flange requires
painting, bake it after painting is completed. Name Remark
Adhesive 3M ATD Part No.8609 Super Fast Urethane Auto Glass Sealant or
equivalent
Primer 3M ATD Part No.8608 Super Fast Urethane Primer or equivalent
Spacers Available as service part
Dam Available as service part
Anti-rust solvent (or Tectyl
506T.Valvoline Oil Company)For rust prevention
Isopropyl alcohol For grease removal from bonded surface
Steel piano wire Dia. × length... 0.6mm × 1m For cutting adhesive
Glass adhesive knife For cutting adhesive
Adhesive gun For pressing-out adhesive
