2004 SUBARU FORESTER sensor

EN(H4SO)-149
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
Step Check Yes No
1 CHECK HARNESS BETWEEN KNOCK SEN-
SOR AND ECM CONNECTOR.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from ECM.
3) Measure the resistance between ECM har-
ness connector and chassis ground.
Connector & terminal
(B135) No. 16 — Chassis ground:Is the resistance more than
700 kΩ?Go to step 2.Repair harness
and connector.
N
OTE:
In this case repair
the following:
 Open circuit in
harness between
knock sensor and
ECM connector
 Poor contact in
knock sensor con-
nector
 Poor contact in
coupling connector
2 CHECK KNOCK SENSOR.
1) Disconnect the connector from knock sen-
sor.
2) Measure the resistance between knock
sensor connector terminal and engine ground.
Te r m i n a l
No. 2 — Engine ground:Is the resistance more than
700 kΩ?Go to step 3.Repair harness
and connector.
NOTE:
In this case repair
the following:
 Poor contact in
knock sensor con-
nector
3 CHECK CONDITION OF KNOCK SENSOR
INSTALLATION.Is the knock sensor installation
bolt tightened securely?Replace the knock
sensor. FU(H4SO)-28,
Knock Sensor.>Tighten knock sen-
sor installation bolt
securely.

EN(H4SO)-150
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
AH:DTC P0328 KNOCK SENSOR 1 CIRCUIT HIGH INPUT (BANK 1 OR SINGLE
SENSOR)
DTC DETECTING CONDITION:
Immediately at fault recognition
TROUBLE SYMPTOM:
 Poor driving performance
 Knocking occurs.
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode ERATION, Clear Memory Mode.> and Inspection Mode tion Mode.>.
WIRING DIAGRAM:
EN-00272
1627
KNOCK
SENSOR
16
2
ECM B135
B22
E3
E14
E14
12
B22
125678
131415169101112
34
17181920
B135
567
82 1
94
310
24 22 23 251112131415
26 27
281617181920 21

EN(H4SO)-151
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
Step Check Yes No
1 CHECK HARNESS BETWEEN KNOCK SEN-
SOR AND ECM CONNECTOR.
Measure the resistance of harness between
ECM connector and chassis ground.
Connector & terminal
(B135) No. 16 — Chassis ground:Is the resistance less than 400
kΩ?Go to step 2.Go to step 3.
2 CHECK KNOCK SENSOR.
1) Disconnect the connector from knock sen-
sor.
2) Measure the resistance between knock
sensor connector terminal and engine ground.
Te r m i n a l s
No. 2 — Engine ground:Is the resistance less than 400
kΩ?Replace the knock
sensor. FU(H4SO)-28,
Knock Sensor.>Repair ground
short circuit in har-
ness between
knock sensor con-
nector and ECM
connector.
N
OTE:
The harness be-
tween both connec-
tors are shielded.
Repair short circuit
in harness covered
with shield.
3 CHECK INPUT SIGNAL FROM ECM.
1) Connect the connectors to ECM and knock
sensor.
2) Turn the ignition switch to ON.
3) Measure the voltage between ECM and
chassis ground.
Connector & terminal
(B135) No. 16 (+) — Chassis ground (
−):Is the voltage more than 2 V? Even if the mal-
function indicator
light illuminates,
the circuit has
returned to a nor-
mal condition at
this time. (How-
ever, the possibility
of poor contact still
remains.)
N
OTE:
In this case repair
the following:
 Poor contact in
knock sensor con-
nector
 Poor contact in
ECM connector.
 Poor contact in
coupling connectorRepair the poor
contact in ECM
connector.

EN(H4SO)-152
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
AI: DTC P0335 CRANKSHAFT POSITION SENSOR “A” CIRCUIT
DTC DETECTING CONDITION:
Immediately at fault recognition
TROUBLE SYMPTOM:
 Engine stalls.
 Failure of engine to start
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode ERATION, Clear Memory Mode.> and Inspection Mode tion Mode.>.
WIRING DIAGRAM:
EN-00273
12
1917
1728
B22
E3
E10
B22
E10
12
B135ECM CRANKSHAFT
POSITION
SENSOR
125678
131415169101112
34
17181920
6
B135
567
82 1
94
310
24 22 23 251112131415
26 27
281617181920 21

EN(H4SO)-153
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
Step Check Yes No
1 CHECK HARNESS BETWEEN CRANK-
SHAFT POSITION SENSOR AND ECM CON-
NECTOR.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from the crank-
shaft position sensor.
3) Measure the resistance of harness
between crankshaft position sensor connector
and engine ground.
Connector & terminal
(E10) No. 1 — Engine ground:Is the resistance more than
100 kΩ?Repair harness
and connector.
N
OTE:
In this case repair
the following:
 Open circuit in
harness between
crankshaft posi-
tion sensor and
ECM connector
 Poor contact in
ECM connector.
 Poor contact in
coupling connectorGo to step 2.
2 CHECK HARNESS BETWEEN CRANK-
SHAFT POSITION SENSOR AND ECM CON-
NECTOR.
Measure the resistance of harness between
crankshaft position sensor connector and
engine ground.
Connector & terminal
(E10) No. 1 — Engine ground:Is the resistance less than 10
Ω?Repair ground
short circuit in har-
ness between
crankshaft posi-
tion sensor and
ECM connector.
N
OTE:
The harness be-
tween both connec-
tors are shielded.
Repair ground short
circuit in harness to-
gether with shield.Go to step 3.
3 CHECK HARNESS BETWEEN CRANK-
SHAFT POSITION SENSOR AND ECM CON-
NECTOR.
Measure the resistance of harness between
crankshaft position sensor connector and
engine ground.
Connector & terminal
(E10) No. 2 — Engine ground:Is the resistance less than 5
Ω?Go to step 4.Repair harness
and connector.
NOTE:
In this case repair
the following:
 Open circuit in
harness between
crankshaft posi-
tion sensor and
ECM connector
 Poor contact in
ECM connector.
 Poor contact in
coupling connector
4 CHECK CONDITION OF CRANKSHAFT PO-
SITION SENSOR.Is the crankshaft position sen-
sor installation bolt tightened
securely?Go to step 5.Tighten the crank-
shaft position sen-
sor installation bolt
securely.
5 CHECK CRANKSHAFT POSITION SENSOR.
1) Remove the crankshaft position sensor.
2) Measure the resistance between connector
terminals of crankshaft position sensor.
Te r m i n a l s
No. 1 — No. 2:Is the resistance 1 — 4 kΩ? Repair poor con-
tact in crankshaft
position sensor
connector.Replace the crank-
shaft position sen-
sor. FU(H4SO)-26,
Crankshaft Posi-
tion Sensor.>

EN(H4SO)-154
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
AJ:DTC P0336 CRANKSHAFT POSITION SENSOR “A” CIRCUIT RANGE/PER-
FORMANCE
DTC DETECTING CONDITION:
Immediately at fault recognition
TROUBLE SYMPTOM:
 Engine stalls
 Failure of engine to start
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode ERATION, Clear Memory Mode.> and Inspection Mode tion Mode.>.
WIRING DIAGRAM:
EN-00273
12
1917
1728
B22
E3
E10
B22
E10
12
B135ECM CRANKSHAFT
POSITION
SENSOR
125678
131415169101112
34
17181920
6
B135
567
82 1
94
310
24 22 23 251112131415
26 27
281617181920 21

EN(H4SO)-155
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
Step Check Yes No
1 CHECK ANY OTHER DTC ON DISPLAY.Is any other DTC displayed? Inspect the DTC
using “List of Diag-
nostic Trouble
Code (DTC)”.
EN(H4SO)-72, List
of Diagnostic Trou-
ble Code (DTC).>Go to step 2.
2 CHECK CONDITION OF CRANKSHAFT PO-
SITION SENSOR.
Turn the ignition switch to OFF.Is the crankshaft position sen-
sor installation bolt tightened
securely?Go to step 3.Tighten the crank-
shaft position sen-
sor installation bolt
securely.
3 CHECK CRANK SPROCKET.
Remove the front belt cover.Are crank sprocket teeth
cracked or damaged?Replace the crank
sprocket. ME(H4SO)-55,
Crank Sprocket.>Go to step 4.
4 CHECK INSTALLATION CONDITION OF
TIMING BELT.
Turn the crankshaft using ST, and align align-
ment mark on crank sprocket with alignment
mark on cylinder block.
ST 499987500 CRANKSHAFT SOCKETIs the timing belt dislocated
from its proper position?Repair installation
condition of timing
belt. ME(H4SO)-48,
Timing Belt.>Replace the crank-
shaft position sen-
sor. FU(H4SO)-26,
Crankshaft Posi-
tion Sensor.>

EN(H4SO)-156
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
AK:DTC P0340 CAMSHAFT POSITION SENSOR “A” CIRCUIT (BANK 1 OR SIN-
GLE SENSOR)
DTC DETECTING CONDITION:
Immediately at fault recognition
TROUBLE SYMPTOM:
 Engine stalls.
 Failure of engine to start
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode ERATION, Clear Memory Mode.> and Inspection Mode tion Mode.>.
WIRING DIAGRAM:
EN-00274
B22
E15
12
125678
131415169101112
34
17181920
12
2018
1828
B22
E3
E15
B135ECM CAMSHAFT
POSITION
SENSOR
7
B135
567
82 1
94
310
24 22 23 251112131415
26 27
281617181920 21
