5MT-103
MANUAL TRANSMISSION AND DIFFERENTIAL
Speedometer Gear
22.Speedometer Gear
A: REMOVAL
1) Remove the manual transmission assembly
from vehicle.
Transmission Assembly.>
2) Remove the back-up light switch and neutral po-
sition switch.
es and Harness.>
3) Remove the transfer case with extension case
assembly.
Case and Extension Case Assembly.>
4) Remove the transmission case.
62, REMOVAL, Transmission Case.>
5) Remove the vehicle speed sensor.
5MT-46, REMOVAL, Vehicle Speed Sensor.>
6) Remove the outer snap ring and pull out speed-
ometer driven gear. Next, remove the oil seal,
speedometer shaft and washer.
B: INSTALLATION
1) Install the washer and speedometer shaft, and
press fit the new oil seal with ST.
ST 899824100 or 499827000PRESS
2) Install the vehicle speed sensor.
46, INSTALLATION, Vehicle Speed Sensor.>
3) Install the speedometer driven gear and new
snap ring.
4) Install the transmission case.
INSTALLATION, Transmission Case.>
5) Install the transfer case with extension case as-
sembly.
fer Case and Extension Case Assembly.>
6) Install the back-up light switch and neutral posi-
tion switch.
Switches and Harness.>
7) Install the manual transmission assembly to ve-
hicle.
Transmission Assembly.>
C: INSPECTION
Check the speedometer gear, oil seal and speed-
ometer shaft for damage. Replace if damaged.
(A) Outer snap ring
(B) Speedometer driven gear
MT-00301
(A)(B)
(A) Outer snap ring
(B) Speedometer driven gear
MT-00301
(A)(B)
